Quick Start Guide
ENGLISH
Press the WPS button until the WiFi 2.4G and 5G LEDs
1
light up in amber.
Press the WPS button on the client. If the WPS method fails,
2
perform the Using SSID method.
Open a web browser and go to http://192.168.1.1.
Enter the default User Name (admin) and admin login pass-
word (on the device label), and then click Login.
A wizard runs. Follow the wizard prompts to complete the
setup.
(Optional) Drill two holes at the distance of 105mm apart.
Insert screw anchors and screws (not provided) into the
holes. Attach the bracket to your VMG3625-T20A with the
bracket holes facing down. Hang it on the screws.
See the User's Guide at www.zyxel.com for more information, including customer support and safety warnings.
2/2
Dual-Band Wireless AC/N Combo
WAN Gigabit Gateway with USB
WiFi Connection
/ Using WPS
1
WLAN
WPS
More than 5 seconds
WiFi 2.4G ON
WiFi 5G ON
Quick Start Wizard
http://192.168.1.1
User Name : admin
Password : Refer to the device label
(default)
VMG3625-T20A
User Name
admin
xxxxxxxx
Password
Login
Wall Mounting (Optional)
x 2 x2
VMG3625-T20A
2
WiFi
ZyXEL VMG3625-T20A
within
2
minutes
WiFi
setup
Android Only
Device Label
Welcome to Quick Start wizard
Time Zone
Back
Copyright © 2017 Zyxel Communications Corp. All Rights Reserved.
Connect
OR
WPS
Next Close
