Quick Start Guide

ENGLISH
Connect the power cable and press the
EN
1
power button.
Connect a computer using the yellow
2
Ethernet cable.
EN
3
Connect a broadband modem or router
(3-a) using an Ethernet cable. OR
Connect a DSL splitter (3-b) or directly to
the telephone wall outlet using the gray
telephone cable.
Connect a 3G dongle (optional).
4
EN
INTERNET LED
5
ON - The Internet connection is ready. Go
to Wireless Setup.
OFF - The Internet connection is not ready.
Go to Internet Setup.
Open a web browser and go to
6-1
http://192.168.1.1. Enter the default User Name
(admin) and Password (1234), and then click
Login.
A wizard runs. Follow the wizard prompts.
6-2
1/2
Dual-Band Wireless AC/N Combo
WAN Gigabit Gateway with USB

Hardware Connections

POWER
ON
3
WAN DSL
3-b
OR
3-a

Check the LEDs

5

Internet Setup

6-1
http://192.168.1.1
VMG3625-T20A
User Name :
admin
Password :
1234
(default)
VMG3625-T20A
VMG3625-T20A
Zyxel_XXXX
Default IP Address: 192.168.1.1
SSID(2.4G)
MAC Address
Power Rating: 12V
2A
XXXXXXXXXXXX
SSID(5G)
Zyxel_XXXX_5G
Power Consumption: 24 Watt max.
Zyxel Communications A/S
Wireless Key
XXXXXXXXXX
Serial Number
SYY41WWXXXXXX
Generatorvej 8D, 2860 S borg, Denmark.
POWER
LAN
1
2
4
ON
INTERNET
INTERNET
OFF
6-2
admin
User Name
1234
Password
Login
VMG3625
-T20A
Wizard (Quick Start)
Next

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VMG3625-T20A and is the answer not in the manual?

Questions and answers

Summary of Contents for ZyXEL Communications VMG3625-T20A

  • Page 1: Quick Start Guide

    Default IP Address: 192.168.1.1 SSID(2.4G) MAC Address Power Rating: 12V XXXXXXXXXXXX SSID(5G) Zyxel_XXXX_5G Power Consumption: 24 Watt max. Zyxel Communications A/S Wireless Key XXXXXXXXXX Serial Number SYY41WWXXXXXX Generatorvej 8D, 2860 S borg, Denmark. POWER Connect a broadband modem or router (3-a) using an Ethernet cable.
  • Page 2: Desktop Installation

    Attach the bracket to your VMG3625-T20A with the bracket holes facing down. Hang it on the screws. See the User’s Guide at www.zyxel.com for more information, including customer support and safety warnings. Copyright © 2017 Zyxel Communications Corp. All Rights Reserved.
