Aaeon SBC-556/L Manual

Half-size cpu card with lcd, ethernet, & ssd
Hide thumbs
Table of Contents

Advertisement

Quick Links

SBC-556/L
Half-size CPU Card with
LCD, Ethernet, & SSD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBC-556/L and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon SBC-556/L

Summary of Contents for Aaeon SBC-556/L

  • Page 1 SBC-556/L Half-size CPU Card with LCD, Ethernet, & SSD...

  • Page 2: Fcc Statement

    FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERA- TION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFER- ENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

  • Page 3: Copyright Notice

    Copyright Notice This document is copyrighted, 1999, by AAEON Technology Inc. All rights are reserved. AAEON Technology Inc. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of AAEON Technology Inc.

  • Page 4: Packing List

    Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 SBC-556/L CPU card • 1 Quick Installation Guide • 1 6-pin mini-DIN dual outlet adapter for keyboard and PS/2 mouse •...
  • Page 5 Notice Dear Customer, Thank you for purchasing the SBC-556/L board. The user manual is designed to help you to get the most out of the SBC-556/ L, please read it thoroughly before you install and use the board. The product that you have purchased comes with a two years warranty, but AAEON cannot be responsible for misuse of the product.

  • Page 6: Table Of Contents

    Contents Chapter 1: General Information ....... 1 Introduction ................2 Features .................. 3 Specifications ................. 4 Board layout ................6 Card dimensions ..............7 Chapter 2: Installation ........9 Jumpers and connectors ............ 10 Locating jumpers and connectors ........12 Setting jumpers ..............
  • Page 7 Display connectors (CN9, CN15) ........38 Serial ports connectors (CN10, CN14) ......41 USB connectors (dual-port) (CN11) ......... 42 Ethernet connector (CN12) ..........43 Power connectors (P8 & P9)(CN13) ........ 44 KB & PS/2 Mouse connector (CN17) ......45 DiskOnChip socket ............47 Chapter 3: Award BIOS Setup ......
  • Page 8 Exit without saving ............. 75 Chpater 4: Flat Panel/CRT Controller Display Drivers and Utilities ...... 77 Software drivers ..............78 Hardware configuration ............78 Necessary prerequisites ............79 Before you begin ..............79 95 95 95 95 95 .............................................

  • Page 9: Chapter 1: General Information

    General Information This chapter provides background information for the SBC-556/L. Sections include: • Card specifications • Board layout Chapter 1 General Information...

  • Page 10: Introduction

    LCD types, includ- ing TFT, DSTN, MONO, and EL. Another feature of the SBC-556/L is the inclusion of a high speed, local bus IDE controller. This controller supports (through ATA PIO) mode 3 and mode 4 hard disks, and Ultra DMA/33, enabling data transfer rates up to 33 MB/second.

  • Page 11: Features

    Features • DiskOnChip (SSD) up to 144MB • C&T 69000 LCD controller supports 36-bit TFT panels. • 100Base-T Fast Ethernet • PC/104 expansion connector • Optional function to support LVDS (Low Voltage Differential Signaling) for high-speed and low-power data transfer. Chapter 1 General Information...

  • Page 12: Specifications

    USB connectors: Dual USB connectors onboard Battery: Lithium battery for Watchdog Timer: Can generate a system reset, IRQ15 or NMI. Supports Win95, Win3.1. Software selectable timeout interval (1 sec. ~ 255 sec., 1sec./step). DMA channels: 7 Interrupt levels: 15 SBC-556/L User Manual...

  • Page 13: Ethernet Interface

    Power management: I/O peripheral devices support power saving and doze/ standby/suspend modes. APM 1.2 compliant. PC/104 connector: 104-pin connector for a 16-bit bus Ethernet interface Chipset: Realtek RTL8139A 100/10 Base-Tx Fast Ethernet controller. Ethernet interface: Onboard 100/10 Base-T RJ-45 connector. Flat panel VGA interface Chipset: C&T 69000 Display memory: 2 MB SDRAM built in Chip...

  • Page 14: Mechanical And Environmental

    Power Requirement (with Pentium MMX): +5V @ 6A Power Requirement (with K6-233): +5V @ 10A Operating temperature: 32 to 140 F ( 0 to 60 Board size: 7.3" (L) x 4.8" (W) (185 mm x 122 mm) Board weight: 1.32 lb. (0.6 Kg) SBC-556/L User Manual...

  • Page 15: Board Layout

    Board layout Chapter 1 General Information...

  • Page 16: Card Dimensions

    Card dimensions 98.50 19.50 122.00 SBC-556/L User Manual...

  • Page 17: Chapter 2: Installation

    Installation This chapter explains set-up procedures for the SBC-556/L hardware, including instructions on setting jumpers and connecting peripherals, switches, and indicators. Be sure to read all safety precautions before you begin the installa- tion procedure. Chapter 2 Installation...

  • Page 18: Jumpers And Connectors

    CPU VIO voltage setting IR connector (Reserved) CPU external clock select CPU Vcore voltage select DOC address select Ethernet RX signal LED connector JP10 Ethernet Linkage signal LED connector JP11 Externet TX signal LED connector JP12 Clear CMOS data SBC-556/L User Manual...
  • Page 19 connector Label Function LCD inverter power connector Powe LED & keylock connector IDE LED connector Hardware reset connector IDE hard drive connector Fan power connector Floppy drive connector Parallel (Printer) port connector LCD panel connector CN10 RS-232/422/485 connector (COM2) CN11 USB connectors (dual-port) CN12 Ethernet connector...

  • Page 20: Locating Jumpers And Connectors

    Locating jumpers and connectors CN14 CN12 CN15 JP11 CN13 JP10 CN17 CN16 CN11 CN10 JP12 SBC-556/L User Manual...

  • Page 21: Setting Jumpers

    Setting jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To close a jumper you connect the pins with the clip.

  • Page 22: Safety Precautions

    Installing the CPU The SBC-556/L CPU card supports most Pentiums and their compatible CPUs. The system's performance depends on the CPU you choose. You can install or upgrade the CPU in the board's PGA socket by following the procedures outlined below.

  • Page 23: Installing A Cpu

    Installing a CPU To install the CPU, follow the instructions that came with it. If no documentation was provided, the general procedures for installing a CPU are outlined below: 1. Lubricate the pins on the CPU with lubricant for PGA devices. This makes the CPU slide in much easier and greatly reduces the chance of damaging the pins and other components.

  • Page 24: Cpu Clock Ratio (Jp1)

    CPU Clock Ratio (JP1) P54C x1.5 P54C x2.0 P54C x3.0 P54C x2.5 P55C x3.5 P55C x2.0 P55C x3.0 P55C x2.5 AMD-K6 x3.5 AMD-K6 x2.0 AMD-K6 x3.0 AMD-K6 x2.5 AMD-K6 x5.5 AMD-K6 x4.0 AMD-K6 x5.0 AMD-K6 x4.5 *default SBC-556/L User Manual...

  • Page 25: Dram Voltage Setting (Jp2)

    LCD driving voltage setting (JP2) JP2 allows users to select the LCD driving voltage. The configurations as belows: B A T D i s k O n C h i p LCD driving voltage setting (JP2) 5 V * 3.3V *default Chapter 2 Installation...

  • Page 26: Rs-232/422/485 Select (Com2)(Jp3)

    1 3 5 B A T D i s k O n C h i p RS-232* RS-422 RS-485 2 4 6 2 4 6 2 4 6 1 3 5 1 3 5 1 3 5 *default SBC-556/L User Manual...

  • Page 27: Cpu Vio Voltage Setting (Jp4)

    CPU VIO voltage setting (JP4) JP4 must be set to match the CPU type. The chart below shows the proper jumper settings for their respective CPU I/O voltage: B A T D i s k O n C h i p CPU VIO voltage setting (JP4) 3.5 V 3.3 V*...

  • Page 28: Ir Connector (Reserved)(Jp5)

    If it is installed, you must set the IR Transfer Mode in the Peripheral section of the CMOS setup utility. 1 2 3 4 B A T D i s k O n C h i p IR connector (JP5) Function SBC-556/L User Manual...

  • Page 29: Cpu External Clock Select (Jp6)

    CPU external clock select (JP6) The JP6 is used to sychronize the system clock with the CPU type. You may need to adjust the CPU clock according the base CPU speed. B A T D i s k O n C h i p 2 4 6 1 3 5 Chapter 2 Installation...
  • Page 30 2 4 6 83.8M 33.3M 1 3 5 2 4 6 68.5M 34.5M 1 3 5 2 4 6 83.8M 41.65M 1 3 5 2 4 6 1 3 5 2 4 6 1 3 5 *default SBC-556/L User Manual...

  • Page 31: Cpu Vcore Voltage Select (Jp7)

    CPU Vcore voltage select (JP7) The JP7 must be set to match the CPU type. The chart below shows the proper jumper settings for their respective Vcc. B A T D i s k O n C h i p 2 4 6 8 1 3 5 7 Note:...
  • Page 32 3.4 V 2 4 6 8 2 4 6 8 2 4 6 8 1 3 5 7 1 3 5 7 1 3 5 7 3.5 V 2 4 6 8 1 3 5 7 *default SBC-556/L User Manual...

  • Page 33: Doc Address Select (Jp8)

    DOC address select (JP8) The DiskOnChip 2000 occupies an 8 K byte window in the upper memory address range of CC00 to DC00. You should ensure this does not conflict with any other device's memory address. B A T D i s k O n C h i p Address CC00 D000...

  • Page 34: Ethernet Active/Link Signal Led (Jp9)(Jp10)(Jp11)

    B A T D i s k O n C h i p Note: Please be kindly reminded that all related network function and warning temperature described in this user manual are only valid for the SBC-556. SBC-556/L User Manual...

  • Page 35: Clear Cmos Data (Jp12)

    Clear CMOS data (JP12) You can connect an external jumper cap or switch to clear CMOS. Clear CMOS procedure: 1. Disconnect all power source. 2. Move JP12 from 1-2 to 2-3 for few seconds. 3. Move JP12 back to 1-2. B A T D i s k O n C h i p 3 2 1...

  • Page 36: Lcd Inverter Connector (Cn1)

    CN1 offers LCD backlight control signals for your applications. The pin assignments are as follows: 5 4 3 2 1 B A T D i s k O n C h i p LCD inverter power connector (CN1) Function +12V SBC-556/L User Manual...

  • Page 37: Power Led And Keylock Connector (Cn2)

    Power LED and keylock connector (CN2) You can connect an LED to indicate when the CPU card is on. Pin 1 of CN2 supplies power to the LED; Pin 3 is the ground. You can use a switch (or a lock) to disable the keyboard. In this state, the PC will not respond to any input.

  • Page 38: Ide Led Connector (Cn3)

    You can connect an LED to indicate that an IDE device is in use.The pin assignments for this connector are as follows: B A T D i s k O n C h i p IDE LED connector (CN3) Function -R/W IDE Pull high (Vcc) SBC-556/L User Manual...

  • Page 39: Hardware Reset Connector (Cn4)

    Hardware reset connector (CN4) You can connect an LED to indicate that an IDE device is in use. The pin assignments for this connector are as follows: B A T D i s k O n C h i p Hardware reset connector (CN4) Function Reset...

  • Page 40: Ide Hard Drive Connector (Cn5)

    If you install two drives, you will need to set one as the master and one as the slave by using jumpers on the drives. If you install just one drive, set it as the master. SBC-556/L User Manual...
  • Page 41 DATA 14 DATA 0 DATA 15 SIGNAL GND IO WRITE IO READ IO CHANNEL READY 28 IRQ14 IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE MGND MVCC 33 SBC-556/L USER MANUAL...

  • Page 42: Fan Power Connector (Cn6)

    Fan power connector (CN6) The SBC-556/L onboard offer +12V voltage for the CPU cooler fan used. B A T D i s k O n C h i p Fan power connector (CN6) Signal Speed Detect +12V SBC-556/L User Manual...

  • Page 43: Floppy Drive Connector (Cn7)

    Floppy drive connector (CN7) You can attach up to two floppy disks to the SBC-556/L onboard controller. You can use any combination of 5¼” (360 KB and 1.2 MB) and/or 3½” (720 KB, 1.44 MB, and 2.88 MB) drives. A 34-pin daisy-chain drive connector cable is required for a dual- drive system.
  • Page 44 1~33 (odd) GND High density 4, 6 Unused Index Motor enable A Driver select B Driver select A Motor enable B Direction Step pulse Write data Write enable Track 0 Write protect Read data Select head Disk change SBC-556/L User Manual...

  • Page 45: Parallel (Printer) Port Connector (Cn8)

    D i s k O n C h i p Parallel port IRQ The SBC-556/L supports one parallel port. The port is designated as LPT1 and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup.

  • Page 46: Display Connectors (Cn9, Cn15)

    Display connectors (CN9, CN15) The SBC-556/L’s PCI SVGA interface can drive conventional CRT displays and is capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD and active LCD displays. The card has two connectors to support these displays, one for standard CRT VGA monitors(CN15) and one for flat panel displays(CN9).
  • Page 47 LCD connector (CN9) Function Function +12VDC +12VDC +5VDC +5VDC ENAVEE SHFCLK FLM (V SYS) LP (H SYS) ENABKL Chapter 2 Installation...
  • Page 48 SVGA connector (CN15) Signal Red video Green video Blue video Not used Red return (GND) Green return (GND) Blue return (GND) Key (no pin) Sync return (GND) Monitor ID (not used) Monitor ID Horizontal sync Vertical sync Not used SBC-556/L User Manual...

  • Page 49: Serial Ports Connectors (Cn10, Cn14)

    Serial ports connectors (CN10, CN14) The SBC-556/L offers one RE-232 serial port and one selectable RS- 232/422/485 serial ports. You can enable or disable the address for each port within the BIOS Peripheral Setup Menu. The card mounting bracket holds COM1(CN14), the DB-9 serial port connector for the first port For COM2(CN10) selection, please refer to Jumper settings one the previous page.

  • Page 50: Usb Connectors (Dual-Port) (Cn11)

    USB devices. If the USB ports are installed, the USB setting in the CMOS setup should be set to “Enabled”. The USB ports also require operating system support for USB devices. B A T D i s k O n C h i p SBC-556/L User Manual...

  • Page 51: Ethernet Connector (Cn12)

    Ethernet connector (CN12) The Ethernet interface on the SBC-556/L via an standard RJ-45 connector for 100/10 Base-T operation. B A T D i s k O n C h i p Note: Please be kindly reminded that all related network function and warning temperature described in this user manual are only valid for the SBC-556.

  • Page 52: Power Connectors (P8 & P9)(Cn13)

    Power connectors (P8 & P9)(CN13) In single board computer (non-passive backplane) application. You will need to connect the power directly to the SBC-556/L board using CN13. This connector is fully compatible with the standard PC PS/2 power supply connector, P8 & P9. see the following table...

  • Page 53: Kb & Ps/2 Mouse Connector (Cn17)

    KB & PS/2 Mouse connector (CN17) The SBC-556/L board provides two 6-pin mini-DIN connectors (KB/ PS/2 MOUSE) on the card mounting bracket supports single board computer applications. The card comes with an adapter to convert the 6-pin mini-DIN connector, used for the mouse, to the standard DIN connector for the keyboard.

  • Page 54: Keyboard Connector

    Keyboard connector Function K.B. clock K.B. data N.C. +5 V DC Keyboard & PS/2 mouse connector Function K.B. data PS/2 mouse data +5 V DC K.B. clock PS/2 mouse clock SBC-556/L User Manual...

  • Page 55: Diskonchip Socket

    DiskOnChip socket The DiskOnChip 2000 family of products provides a single chip solid-state flash disk in a standard 32-pin DIP package. The DiskOnChip 2000 is a solid-state disk with no moving parts, resulting in a significant reduction in power consumption and an increase in reliability.
  • Page 56 Pow er Ground Note 1: Pins A13 through A16 are not used by the MD2200. They are kept for socket backward compatibility with ED 1100 (DiskOnChip 1000) Note 2: Pins 1 and 30 are not used by MD2200 SBC-556/L User Manual...

  • Page 57: Chapter 3: Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data. Chapter 3 Award BIOS Setup...

  • Page 58: System Test And Initialization

    The SBC-556/L s CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit. SBC-556/L User Manual...

  • Page 59: Award Bios Setup

    AWARD BIOS setup Entering setup Power up the computer and press <Del> immediately. This will allow you to enter Setup. Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of informa- tion is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.

  • Page 60: Standard Cmos Setup

    1 1 1 1 1 5 5 5 5 5 2 2 2 2 2 6 6 6 6 6 3 3 3 3 3 7 7 7 7 7 4 4 4 4 4 8 8 8 8 8 SBC-556/L User Manual...

  • Page 61: Bios Features Setup

    BIOS features setup By choosing the BIOS FEATURES SETUP option from the INITIAL SETUP SCREEN menu, the screen below is displayed. The following configurations are based on the manufacturer's SETUP DEFAULTS settings. Chapter 3 Award BIOS Setup...

  • Page 62: Virus Warning

    POST. Boot Sequence This category determines which drive to search first for the disk operating system (i.e., DOS). Swap Floppy Drive This item allows you to determine whether you want to swap floppy drive or not. SBC-556/L User Manual...
  • Page 63 Boot Up Floppy Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360K type is 40 tracks while 760K, 1.2 M and 1.44M are all 80 tracks. Boot Up NumLock Status This allows you to determine the default state of the numeric keypad.

  • Page 64: Chipset Features Setup

    Chipset features setup SBC-556/L User Manual...
  • Page 65 This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache. It also coordinates communica- tions between the conventional ISA bus and the PCI bus. It must be stated that these items should never need to be altered.

  • Page 66: Power Management Setup

    Power management setup By choosing the POWER MANAGEMENT SETUP option from the INITIAL SETUP SCREEN menu, the screen below is dis- played. The following configurations are the setup menu on the screen. SBC-556/L User Manual...
  • Page 67 Power Management There are four selections for Power Management, Disabled, Min Saving, Max Saving, User Define. Except Disabled, three of above selections have fixed mode settings. When PM is set Disabled, the pre-defined items will become show only. PM Control by APM When enabled, an Advanced Power Management device will be activated to enhance the Max.

  • Page 68: Pm Timers

    Suspend Mode When enabled and after the set time of system inactivity, all devices except the CPU will be shut off. SBC-556/L User Manual...

  • Page 69: Pm Events

    PM Events PM events are I/O events whose occurrence can prevent the system from entering a power-saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything which occurs to a device which is configured as En- abled, even when the system is in a power down mode.

  • Page 70: Pnp/Pci Configuration Setup

    This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. The following configurations are based on the manufacturer's SETUP DEFAULTS Settings. SBC-556/L User Manual...
  • Page 71 Resource Controlled by The Award Plug and Play BIOS has the capacity to automatically configure all of the boot, Plug and Play compatible devices. However, this capability means absolutely nothing unless you are ® using a Plug and Play operating system such as Windows Reset Configuration data This item allows you to determine whether to reset the configura- tion data or not.
  • Page 72 Again, you will note that the primary has a lower interrupt than the secondary. Selecting PCI Auto allows the system to automatically determine how your IDE disk system is configured. Primary IDE INT# Refer to the above description of PCI IDE IRQ. SBC-556/L User Manual...

  • Page 73: Load Bios Default / Load Setup Defaults

    Load BIOS DEFAULTS / LOAD SETUP DEFAULTS LOAD BIOS DEFAULTS loads the default system values directly from ROM. The BIOS DEFAULTS provide the most stable settings, though they do not provide optimal performance. LOAD SETUP DEFAULTS, on the other hand, provides for maximum system performance.

  • Page 74: Integrated Peripherals

    INTEGRATED PERIPHERALS icon from the INITIAL SETUP SCREEN. This section sets the IDE transfer mode for all IDE channels. It also configures the other onboard ports. The following configurations are based on the manufacturer's SETUP DEFAULTS settings. SBC-556/L User Manual...
  • Page 75 Internal PCI/IDE You can choose Disable to terminate the onboard PCI/IDE controller and then support external HDD devices. When the setting is Primary, users can set up IDE Mode or UltraDMA mode depending on the respective HDD drive. IDE Primary Master/Slave PIO These four lines set the hard disk PIO transfer mode, which affects the hard disk data transfer rate.
  • Page 76 COM1/3F8 (Default of onboard serial port) COM2/2F8 (Default of onboard serial port) COM3/3E8 COM4/2E8 Onboard Parallel Port Sets the I/O address for the onboard parallel port. The setting options are: 378H/IRQ7 (default) Disabled 278H/IRQ5 3BCH/IRQ7 SBC-556/L User Manual...
  • Page 77 Onboard Parallel mode Selects the parallel port mode. The setting options are: SPP (default) ECP+EPP EPP +SPP If you set this option to 'SPP' or 'EPP', the 'ECP Mode Use DMA' option will not appear on the screen. If you set this option to 'SPP' or 'ECP', the 'Parallel Port EPP Type' option will not appear on the screen.

  • Page 78: Supervisor/User Password Setting

    : can only enter but does not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password. ENTER PASSWORD: SBC-556/L User Manual...
  • Page 79 ENTER PASSWORD: Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from the CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>.

  • Page 80: Auto Detect Hard Disk

    35535 Select Drive C Option (N=Skip) : N OPTION Size CYLS HEADS PRECOMP LANDZONE SECTORS MODE 1 (Y) NORMAL Notes: Some OSes (line SCO-UNIX) Must use "NORMAL" for installation ESC = SKIP IDE HDD auto detection screen SBC-556/L User Manual...

  • Page 81: Hdd Low Level Format

    HDD low level format Selecting this utility allows you to execute HDD low level formatting. This Award Low-Level-Format Utility is designed as a tool to save you time formatting your hard disk. The Utility automatically looks for the necessary information of the drive you selected.

  • Page 82: Save & Exit Setup

    CMOS memory. The microprocessor will check this every time you turn on your system on and compare this to what it finds as it checks the system. This record is required for the system to operate. SBC-556/L User Manual...

  • Page 83: Exit Without Saving

    Exit without saving Selecting this option and pressing <Enter> lets you exit the Setup program without recording any new values or changing old ones. Chapter 3 Award BIOS Setup...
  • Page 84 SBC-556/L User Manual...

  • Page 85: Drivers And Utilities

    Flat Panel/CRT Controller Display Drivers and Utilities This chapter provides information about: • Driver types and installation Chapter 4 Driver Installation...

  • Page 86: Software Drivers

    2. If a high-resolution mode is not supported on your system, try using a lower-resolution mode. For example, 1024 x 768 mode will not work on some systems, but 800 x 600 mode is supported on most. SBC-556/L User Manual...

  • Page 87: Necessary Prerequisites

    Necessary prerequisites The instructions in this manual assume that you understand elementa- ry concepts of MS-DOS and the IBM Personal Computer. Before you attempt to install any driver from the Supporting CD-ROM, you should: • Know how to copy files from a CD-ROM to a directory on the hard disk •...

  • Page 88: Windows® 95

    95 as you normally would for a VGA display. Click the Start button, go to Settings and click on Control Panel. Choose the Display icon and double click on the icon. In the Display Properties window, show as figure 1: figure 1 SBC-556/L User Manual...
  • Page 89 Click the setting buttom, then click the Advanced Properties icon into the Advanced Display properties windows, show as figure2: figure 2 Chapter 4 Driver Installation...
  • Page 90 Change Display Type. In the Change Display Type window, click on the Change button under Adapter Type into the select Device window show as figure 3: This will bring up the Select Device window. figure 3 SBC-556/L User Manual...
  • Page 91 2. Place the Supporting CD-ROM in your CD-ROM drive. figure 4 In the Select Device window, click on Have Disk, Select Browse, and find the Win95 driver "chips95.inf" in the Supporting CD- ROM: cd-rom: \CD ROM\model name\driver\vga driver \win95\chips95.inf and then click OK. "cd-rom"...
  • Page 92 The name of the Chips And Tech "69000 PCI " driver will appear highlighted in the Models list boxfhow as figure. Click OK to start the driver installation show as figure 5: figure 5 SBC-556/L User Manual...
  • Page 93 3. Once the installation is complete, the Advanced display Properties window will reappear. Show as figure 6: figure 6 Chapter 4 Driver Installation...
  • Page 94 Click on close to close the window. Then the Display Properties window will reappear. Show as figure 7: figure 7 SBC-556/L User Manual...
  • Page 95 Click on Apply. Restart the system for the new settings to take effect, show as figure 8: figure 8 Chapter 4 Driver Installation...

  • Page 96: Windows® 3.1

    For proper operation, the drivers must be installed in the Windows subdirectory. 3. Press <ENTER> to complete the installation. Once completed, you can find the icon Chips CPL under the Control Panel. The icon allows you to select and load the installed drivers. SBC-556/L User Manual...

  • Page 97: Os/2

    OS/2 These drivers are designed to function with the OS/2 Version 4.0, 3.0 and 2.11 operating systems. To install this driver, do the following steps: 1. Open an OS/2 full screen or windowed session. 2. Place the Supporting CD-ROM into your CD-ROM drive. 3.
  • Page 98 6. When the installation is complete, you will need to shut down and then restart the system for the changes to take effect. Make sure to remove the installation diskette before restarting the system. SBC-556/L User Manual...

  • Page 99: Windows

    Windows® NT 3.51   These drivers are designed to work with Microsoft Windows Driver installation  1. Install Windows NT 3.51 as you normally would for a VGA display. Click the Star buttom, go to Settings and click on Control Panel icon.

  • Page 100: Windows Nt4.0

    3. Once the installation is complete, the Change Display Type window will reappear. Click on close to close the window. Then the Display Properties window will reappear. Click on Apply. Restart the system for the new settings to take effect. SBC-556/L User Manual...

  • Page 101: Chapter 5: Ethernet Software Configuration

    Watchdog Timer...

  • Page 102: Watchdog Timer

    Watchdog Timer SBC-556/L contains a watchdog timer reset pin. (GP12) All reference material can be found on the following pages. SBC-556 User's Manual...

  • Page 103: Appendix A: Programming The Watchdog Timer

    #include <dos.h> #include <io.h> #include <bios.h> #include <stdio.h> #include <stdlib.h> #include <conio.h> /* Set I/O Address : 370/371 or 3F0/3F1 */ #define IO_INDEX_PORT 0x3f0 #define IO_DATA_PORT 0x3f1 /* Set Watchdog reset pin : 12/13/16 */ #define watch_dog_output_GP 12 #define UNLOCK_DATA 0x87 #define LOCK_DATA 0xAA...

  • Page 104: Programming The Watchdog Timer

    void SelectDevice(unsigned char device) outportb(IO_INDEX_PORT, DEVICE_REGISTER); outportb(IO_DATA_PORT, device); unsigned char ReadAData(short int reg) outportb(IO_INDEX_PORT, reg); return (inportb(IO_DATA_PORT)); void WriteAData(unsigned char reg, unsigned char data) outportb(IO_INDEX_PORT, reg outportb(IO_DATA_PORT, data); void SetWatchDogTime(unsigned char time_val) EnterConfigMode(); SelectDevice(8); //Set Register F2 //Set Watch-Dog Timer 1~ 256 WriteAData(0xF2, time_val);...

  • Page 105: Demo Program

    void init_w83977tf_aw_watchdog() short int value; //Enter W83977 Configure Mode EnterConfigMode(); //Select Device 7 SelectDevice(7); //Set Device Active WriteAData(0x30, 0x01); //caution:skip this step will be a mistake!! if (watch_dog_output_GP==12) //Set Register E2 to define GP12 WriteAData(0xE2, 0x0A); else if(watch_dog_output_GP==13) //Set Register E3 to define GP13 WriteAData(0xE3, 0x0A);...
  • Page 106 //Exit W83977 Configure mode ExitConfigMode(); void main(int argc, char* argv[]) int time_value=0; char *ptr; printf(“WinBond 83977 WatchDog Timer Setup Utility Version 1.0 \n”); printf(“Copyright (c) 2000 AAEON Technology Inc.\n”); printf(“This version only for W83977 that using GP%d to SBC-556 User's Manual...
  • Page 107 Reset System.\n”,watch_dog_output_GP); if (argc == 1) printf(“\n Syntax: WATCHDOG [time] \n”); printf(“ time range : 1 ~ 256 \n\n”); return ; if (argc > 1) ptr = argv[1]; time_value = atoi(ptr); if (time_value > 0 && time_value < 256) SetWatchDogTime((unsigned char) time_value);...
  • Page 108 Ethernet Software Configuration This chapter describes how to configure the Etherent interface to match your application requirements. Chapter 5 Software Configuration...

  • Page 109: Ethernet Software Configuration

    The Ethernet Setup Menu also offers three very useful diagnos- tic functions. These are: 1. Run EEPROM test 2. Run Diagnostics on Board 3. Run Diagnostics on Network Each option has its own display screen which shows the format and result of any diagnostic tests undertaken. SBC-556/L User Manual...

  • Page 110: Appendix B: Installing Pc/104 Modules

    Installing PC/104 modules The SBC-556/L's PC/104 connectors give you the flexibility to attach PC/104 expansion modules. These modules perform the functions of traditional plug-in expansion cards, but save space and valuable slots. Modules include: • PCM-3110B PCMCIA Module (one-slot) • PCM-3115B PCMCIA Module (two-slot) •...

  • Page 111: Installing Pc/104 Modules

    Installing these modules on the SBC-556/L is a quick and simple operation. The following steps show how to mount the PC/104 modules: Step1 Remove the SBC-556/L from your system, paying particular attention to the safety instructions already mentioned above. Step2 Make any jumper or link changes required to the CPU card now.
  • Page 112 0.300 3.250 3.775 3.575 3.575 0.200 0.200 3.350 0.200 3.550 PC/104 module dimenstions (inches ±5%) SBC-556/L User Manual...
