ASSEMBLY AND CARE INSTRUCTIONS
VERSION: 8920108 (Revised 06/15)
SA Sport – Canada and International
135 Forestview Road, PO Box 40
Orillia, Ontario, Canada L3V 6H9
Toll-Free:
Telephone: (705) 325-2274
Fax:
info@spiethanderson.com
LEATHER POMMEL HORSE
SALES AND SERVICE
sasportonline.com
(800) 563-6479
(705) 325-1485
5141
SA Sport – USA
104 Nu Energy Drive, Suite 1
Aledo, Texas, USA 76008
Toll-Free:
Telephone: (817) 536-3366
Fax:
sales@sasportusa.com
(800) 331-8068
(817) 536-3006
Advertisement
Summary of Contents for SA Sport 5141
- Page 1 LEATHER POMMEL HORSE 5141 VERSION: 8920108 (Revised 06/15) SALES AND SERVICE sasportonline.com SA Sport – Canada and International SA Sport – USA 135 Forestview Road, PO Box 40 104 Nu Energy Drive, Suite 1 Orillia, Ontario, Canada L3V 6H9 Aledo, Texas, USA 76008...
- Page 2 5141 POMMEL HORSE Assembly Instructions Thank you for purchasing a 5141 - Pommel Horse from SA Sport. We appreciate your business and value you as a customer! Your horse is constructed with the finest quality raw materials. We are sure you will be pleased with its quality, durability and performance.
-
Page 3: Assembly Instructions
5141 POMMEL HORSE Assembly Instructions 1. Assembly Instructions 1.1. Layout of Area Required for the Pommel Horse 1.2. Assembly 1. Remove the Pedestal Base from its carton and set it on the floor. Ensure it is leveled. 2. Attach the Uprights Posts as shown below, using the three flat head screws for each post. - Page 4 5141 POMMEL HORSE Assembly Instructions 3. Turn the Locking Handles on the Pedestal Uprights counter-clockwise until they are completely loosened. Make sure the ‘V’ shape in the blocks faces towards the adjusting shaft. 4. Open the Horse Top carton and remove loose Pommels and Pommel hardware.
- Page 5 5141 POMMEL HORSE Assembly Instructions 9. Check to ensure that both Adjusting Tubes are locked at the same height. 10. Shake the Horse Top from the middle to center the body on the Adjusting Shafts. FULLY TIGHTEN THE MOUNTING PLATES ASSEMBLED IN STEP 6.
- Page 6 3. Slide Pommel Horse out of the way and install the Floor Anchor using the instructions on the next page of this manual. The Concrete Floor Anchor is not supplied with this package. They must be purchased separately. Concrete anchors are available at SA Sport under spare part #PEA1 (Set of 4 pieces). Page 6 of 9...
- Page 7 5141 POMMEL HORSE Assembly Instructions 1.5. Installing Concrete Anchors To determine anchor locations, please refer to the following section for your specific equipment to be anchored. Tools Required (customer supplied): • Tape measure • Anchor setting tool or punch with a ”...
-
Page 8: Adjustment Instructions
5141 POMMEL HORSE Assembly Instructions 2. Adjustment instructions 2.1. Height Adjustment 1. Have 2 people support the Horse Top from both ends. 2. Loosen both Locking Handles and pull the Snap Locks. (See Fig. 3) The Horse Top has the potential to drop at this stage. Injury can occur as a result of this dropping. - Page 9 5141 POMMEL HORSE Assembly Instructions 4. SAFETY WARNING Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death, from landing or falling on the neck, head, or other parts of the body.
