1) Product Description

beep&park

/vision™ is a reverse radar system that helps motorists to park safely

using a rearview camera providing drivers with audio and video information when

reversing.

Datasheet:

Control screen to place on the dashboard or close the central rear-

view mirror

• Colour LCD screen.

• Digital distance readout.

• Adjustable brightness and contrast.

• Detachable screen for protection from theft.

• Built-in diagnostics function

Four ultrasonic sensors

• Four rear sensors for an optimised and consistent detection area.

• Compact sensors for installation on all models and styling compatibility.

• Side-mounted metal clips for high resistance to vibrations.

One Rear camera

• Discreet mini-camera no bigger than a sensor.

• Horizontal wide angle.

• Also works in poor light (< 2 lux).

Loudspeaker

• With Adjustable volume

User Guide

1/4

Table of Contents

Do you have a question about the beep&park/vision and is the answer not in the manual?

Page 1 User Guide 1) Product Description ® beep&park /vision™ is a reverse radar system that helps motorists to park safely using a rearview camera providing drivers with audio and video information when reversing. Datasheet: Control screen to place on the dashboard or close the central rear- view mirror •...
Page 2 User Guide 2) beep&park /vision Functioning ™ ® 1) Parking Assistance System : • Each time you select the reverse gear, the 4 rear sensors are activated to detect the presence of obstacles at the rear of the vehicle, and the rear Camera transmits information ®...
Page 3 User Guide 3) beep&park /vision Settings ™ ® 1) Sensor Diagnostic Function : • Select reverse gear. The system tests the 4 rear sensors automatically: If all of the sensors are working, the system beeps once. If there is a problem with any of the sensors, the system beeps 3 times.
Page 4 If the system does not beep, check that the volume level is not set at minimum. • In case of a accident, spare parts are available through your usual distribution channel. Valeo may not be held responsible for the incorrect installation or misuse of the products.
