4 Repair
4.16.2 Replacement of system power supply
4.16.2 Replacement of system power supply
Location
The following illustration shows the location of the system power supply.
xx0900000600
A
Required equipment
Equipment
System power supply
Removal
Use the following procedure to remove the system power supply.
1
2
Continues on next page
144
System power supply
Action
DANGER
Before commencing any work inside the cabinet,
please observe the safety information in section
DANGER - Make sure that the main power has been
switched off! on page
29.
Remove the top cover and left side cover of the
cabinet.
© Copyright 2009-2013 ABB. All rights reserved.
Note
DSQC 661
See
Controller system parts on page
Note/Illustration
See
Removing the top cover on
page 67
and
Removing the left
side cover on page
3HAC035738-001 Revision: E
157.
67.
