JOIN THE UNITS TOGETHER AT THE TOP
Working the dual-installation top bracket in from the
1
side, line up the holes of the top bracket with the
threaded inserts at the top adjoining corners of the
appliances.
5 3
2 Insert four / -18 × /
16 4
bracket into the threaded inserts.
Tighten the bolts.
3
(Grilles
removed
for clarity)
SECURE THE GRILLE FRAMES TOGETHER
1 Secure the grilles together by inserting the #10-24 ×
1
2 / " machine screw into the upper rear holes in the
4
grille brackets.
2 Attach the #10-24 nut to the machine screw, and
tighten it.
Close the grilles.
3
" Tensilock bolts through the
#10-24 × 2 / "
1
4
Machine Screw
#10-24 Nut
Front View
Built-In Series Dual Installation Kit
Page 4 of 4
