Before Using the Product
This product must be charged before use.
Use the included USB cable to charge.
It takes about two hours before charging is completed. If the LED lamp does not turn off after 2 hours, immediately
disconnect the charging cable and stop charging. Charging for more than two hours can shorten the battery life and may lead
to device failure.
Connect the charging cable to the product.
Connect the charging connector of the supplied USB charging cable to the earphone.
Connect the USB charging cable to your PC.
Connect the series A connector of the USB charging cable to the USB port of your PC, etc.
* If the PC is not connected to a power source, it will not output charging power.
The LED lamp lights red when charging.
Charging is completed when the LED lamp
turns off.
[Charging connection]
Earphone
Open the rubber cover and connect the
charging connector.
Charging
Series A
connector USB charging cable
connector
Red light turns on while charging.
Be careful of the connector
The light turns off when charging is
orientation with connecting.
completed.
(Cannot be connected in reverse.)
Setting the Headset (Pairing Mode)
Enter the headset into pairing mode
With the power of this product turned OFF, press and hold the multi-function button for
8 seconds or more. When the LED lamp begins alternately blinking red and blue, the
device has entered pairing mode.
* If the headset does not have pairing information, the device enters pairing mode when
the power is turned on (4 seconds of holding down the multi-function button).
If the pairing occurs with an unintended device, turn off that device and perform this step again.
If any devices which have already been paired are nearby, you can take your finger off of the button as soon as the
LED lamp turns on.
If the device's automatic re-connection setting is enabled, connection is automatically re-established with that device.
Some devices may require prior operation to allow communication with LBT-HS350.
Searching for the headset from the connecting device
Search for this product from the mobile phone (smartphone) you want to pair it with. How to search varies depending
on the device used.
For operations on the connecting device, please refer to the user's manual provided for your mobile phone (smartphone).
Search for the headset from your mobile phone.
PC
Settings
Wireless controls
To PC USB port
Call settings
Sound
Display
If the PC is not connected to a power source, it
will not output charging power. Multimedia
Eco-mode setting
USB cigarette charger
Location & security
To cigarette
Applications
To USB terminal
socket
Tap on [Wireless controls]
on the Settings screen.
Register the headset with the device with
which you want to perform pairing.
USB AC adapter
When this product is detected by a mobile phone (smartphone), it
shows up as [LBT-HS350] on the scanned device list. Select and
To USB terminal
register this item.
To AC wall
When the pairing is completed, the LED lamp will blink blue slowly
outlet
(approx. once every 5 seconds).
Other USB-AC adapters and USB cigarette
If a message appears prompting you to enter a link key, enter [0000] (four zeros). Depending on the device (Bluetooth 2.1 or later), registration may
chargers can also be used for charging.
complete without having to enter a link key.
Depending on the device, it may be necessary to perform a [Connection] procedure after pairing is completed. Please refer to the manual of your mobile
device for information, and perform a [Connection] procedure if necessary.
The example is for an Android smartphone.
Select and register LBT-HS350.
Wireless controls Wireless controls Wireless controls Wireless controls Wireless controls Wireless controls
Airplane mode
Blu etoot h
Bluetooth
Disable all wireless connections
Wi-Fi Dev ic e n am e
Device name
Turn on Wi-Fi T-01C
T-01C
Wi-Fi settings Disc o v er a ble
Discoverable
Set up &d manage wireless access points 可能
Make device discoverable
Receive infrared Scan for devices
Scan for devices
B lueto o th dev ic es
Scanning Bluetooth devices Bluetooth devices
Bluetooth
LB T -X XX X LBT-XXXX
Bluetooth settings Pairing
Pair with this device
Manage connections, set device name &
discoverability
VPN settings
Set up & manage Virtual Private Networks
(VPN)
Mobile networks
Set options for roaming, networks, APNs
Tap on [Bluetooth] from Check [Bluetooth] at the From the list of scanned When the pairing is
[Wireless controls]. top of the screen. devices, tap on the successful, [Connected to
Tap on [Scan for devices] device to connect to. mobile phone voice] shows
at the bottom of the screen. up below the product name.
Blinks alternately red/blue
(waiting for pairing)
Slowly blinks blue
(pairing completed)
Connection Check and Calling Test
Check the
connection.
Connected
Press HERE
properly?
Check! The LED lamp will blink blue in a loose pattern
(approx. once every 5 seconds)
If the LED lamp blinks
twice in 5 seconds, redo
the pairing steps.
Setup (pairing) is completed.
Once registered, the device will be automatically connected from next use.
Make a call from the mobile phone.
Receiving a call
When you hear the ringtone
Wireless controls Wireless controls
from the headset, press the
Bluetooth
multi-function button once.
Device name
* Due to the device
T-01C
specifications, you cannot set
Discoverable
incoming call ringtone on the
Make device discoverable Press HERE
Bluetooth headset.
Scan for devices
LBT-XXXX For Subsequent Connections
Connected to mobile phone voice
Turn on the power to activate the product
While the product is turned
off, press and hold the
multi-function button for 4
seconds. The LED lamp
will blink in blue 3 times
and the power will turn on.
How the product behaves after the power has been turned on
depends on the connection condition.
1. If the paired device is nearby
 Automatically re-connects to the device (blue light blinking
every 5 seconds)
2. If the paired device is not nearby
 Not connected (blue light blinking twice every 5 seconds)
3. If there is no pairing information
 Enters pairing mode right after turning on the power.
(Red/Blue alternate blinking)
Hanging up the call
When in conversation, press the multi-function button once.
Re-dialling (Calling the last-called number)
While the mobile phone is in standby mode, press and
hold the [+] volume button.
* The re-dialling function does not dial back the number from which you
received a call.
* For re-dialling when the multi-point function is in use, please refer to [About
Placing a Call (Re-dialling)] under [How to Set the Multi-Point Function].
Placing a call
To call any number, use your mobile phone to place a call
and then switch the output.
Operation
Type
iPhone: After placing a call, select (LBT-HS350) as the sound output
device.
Android: After placing a call, press the [Bluetooth] button on the screen.
* For information on switching the sound output on your mobile device,
please refer to the manual of that device.
Adjusting the volume
Perform using the volume button on this product. If you
cannot achieve the desired level of volume using the
volume button on this product even when it is at maximum,
adjust the volume on the paired device.
Turn power OFF
Press and hold the multi-function button for 4 seconds
or more. The LED lamp blinks red and then turns off,
and the product turns OFF.
If the connection cannot be established, resetting the headset
settings may improve the condition. To reset, while the power
is on, press the multi-function button, and the [+] and [-] volume
buttons at the same time until the LED lamp blinks red 5 times.
About the auto power-off function
If there is no power or signal from a connected device or no
paired devices detected within approx. 5 minutes after turning
this product on, this product will automatically turn OFF.
