Stanley 77-030 Manual

77-030
Caution: The electrode pins are very sharp.
MOISTURE METER
Handle instrument carefully. Keep pins covered
when not in use.
A
A Replaceable Electrodes
B
B Flip-Off Protective Cap with Battery and
Resistance Test sockets
C On/Off Switch
D Rubber Hand Grips
E Backlit LCD Screen
C
D
Ready
E
B
Wood Scale
Stanley Moisture Meter
The Stanley Moisture Meter detects moisture in
wood and common building materials including,
but not limited to, drywall, plaster, concrete and
cement board.
T
+
T
SPECIFICATIONS
Display LCD with dual measuring
scales
With green Backlight
Range, Wood 6 to 44% ± 2%
Range, Building Materials 0.2 to 2.0% ± 0.1%
Auto Power Off 3 minutes
Operating Temperature 32° to 122°F (0 to 50°C)
Operating % Humidity 80% Max.
Relative Humidity
Power Supply (3) CR-2032 Button Cells
Electrode Pins (2) 0.3" (8mm),
Replaceable
Accessories Carry Pouch w/ Belt Clip
OPERATING INSTRUCTIONS
Testing Batteries:
Use
1. With the protective cap in place over electrodes
1. Slide power switch to "ON" position.
2. Lift protective cap 1, then pivot to position 2.
3. Press electrodes into the material to be tested.
2. Push down on cap. LCD should display 44%
A. Press carefully, but as deeply as possible to get
good contact.
If the display is not at 44% or the battery icon appears
Low Battery
B. In wood, take measurements across the grain.
on the LCD, replace the batteries.
Icon
C. Take several readings to get a better idea of the
general moisture content of the material.
1
Building
Materials
2
Scale
Testing Moisture Scale Accuracy:
1. With the protective cap in place over electrodes
SL
SI
BUL
T
+
Wood Grain 2. Push down on cap. LCD should display 27.5% ±2%
reading on "Wood" scale.
If the reading is not within the limits, the unit may
require repair.
Replacing Batteries:
Push in 1, Then lift door 2, 3 push in on tab and battery
will pop up.
and unit power "ON", rotate cap until battery icon
aligns with arrow.
1
reading on "Wood" scale.
T
and unit power "ON", rotate cap until the "T"
aligns with arrow.
T
T
+
+
+
WARRANTY
One Year Warranty
Deficient products will be repaired or replaced, at
Stanley Tools' option, if sent together with proof of
purchase to:
Stanley UK Sales Limited,
Gowerton Road,
Brackmills,
T
Northampton
NN4 7BW
This Warranty does not cover deficiencies caused
by accidental damage, wear and tear, use other than
in accordance with the manufacturer's instructions
or repair or alteration of this product not authorized
by Stanley Tools. Repairs or replacement under
this Warranty does not affect the expiry date of the
Warranty.
To the extent permitted by law, Stanley Tools shall
not be liable under this Warranty for indirect or
+
consequential loss resulting from deficiencies in this
2
product. T
This Warranty may not be varied without the
T
authorization of Stanley Tools.
This Warranty does not affect the statutory rights of
consumer purchasers of the product.
This Warranty shall be governed by and construed in
accordance with the laws of England and Stanley Tools
and the purchaser each irrevocably agrees to submit to
+
the exclusive jurisdiction of the courts of England over
any claim or matter arising under or in connection with
this Warranty.
IMPORTANT NOTE:
The customer is responsible for the correct use and
+
care of the instrument. Moreover he is completely
3
responsible for checking the job along its prosecution,
and therefore for the calibration of the instrument.
Calibration and care are not covered by Warranty.
Subject to change without notice
