Specifications - General MM1E User Manual

4. Conductive or metallic objects will always light the lowest
LED on the bar graph, regardless of the selected scale.
5. Measurements of wood are skewed by two variables:
ambient humidity and the density of the wood species.
The best way to compensate for the effect of these
variables is to develop your own moisture level curves,
based on your experience working with different species
of wood on a day-to-day basis.
6. The MM1E has no auto power off function. To avoid
discharging the battery, manually power off the meter after
each measurement session by sliding the Power/Scale
switch on the back to the OFF position.

SPECIFICATIONS

Measurement Range
Measurement Accuracy
Pin Length
Calibration Check Point
Low Battery Alarm Level
Operating Temperature
Storage Temperature
Current Consumption
Dimensions
Weight
Power Source
8
7 to 35% WME (Wood Moisture
Equivalent) over two scales: 7% to
15% (Low) and 16% to 35% (High)
±1 LED
3/8 in. (10mm)
20% ±2 LED
<7.5V
32° to 140°F (0° to 60°C)
@<80% R.H.
23° to 140°F (-5° to 60°C)
<15mADC
6.5 x 2.7 x 1 in. (164 x 69 x 26mm)
3.2 oz. (91g)
"9V" battery (included)
