NEC Pinwriter P5200/P5300

Error Codes

Error codes and status codes flashed in the PITCH window on the
control panel are on a reference card which pulls out from the
underside of the printer.
Common Problems and Fixes
The printer will not print and the power light is off - Check that the
printer is securely plugged into a working circuit.
The printer does not print and the SELECT light is off - The printer is
offline. Press the SELECT key.
The printing does not start at the top of the page - The top-of-form is
not set correctly. Move paper to the top of page and re-set the
top-of-form.
Print is faded - The ribbon is not installed correctly, or needs to be
replaced. Reinstall, or replace the ribbon cartridge.
Printout is smudged - The copy control lever is set incorrectly. Adjust
the copy control lever.
Field Replaceable Units
DESCRIPTION
Platen Asm.
Tractor Unit
Ribbon Base
Print Head
Sheet Guide Asm.
PCB Asm.
Connector Cover
Knob
Card Holder Asm.
Control Unit
Power Supply
Note: Be sure to print a menu/configuration list before
swapping the printer.
© Copyright International Business Machines Corporation
March 1995.
OEMP/N
NEC 5200 136-209716-101- D
136-209718-101-B
136-209731-101-B
136-209742-102-A
136-212389-101-A
136-434739-001-A
136-824469-001-A
136-824482-002-A
136-824570-001-E
808-812323-301-B
808-891067-002-A
IBM P/N IBM machine type
31F0772 (P5200) 1515-N14 (P5200)
1515-N25 (P5200)
1515-N26 (P5200/P5300)
Tech Support 800-877-7764
IBM/TSS Internal use only
