Keyspan:Mini Port Replicator for Windows-v3.2 User Manual
7.1.c.01 - Palm Desktop

Before you begin...

This Configuration Example assumes that you have already done the following:
1. installed the Keyspan serial port hardware and software
2. installed the Palm Desktop software
3. connected the Palm Serial Cradle hardware to a Keyspan serial port
If you have not performed any of the steps mentioned above, please do so before proceeding.
Step 1
-
Check the Keyspan Serial Assistant
Before proceeding, you should check to see if the Keyspan serial port is installed correctly.
To do this, open the Keyspan Serial Assistant
Port Replicator -> Keyspan Serial Assistant)
Keyspan Serial Assistant, you will see a window similar to the one shown below:
If your Keyspan hardware and software are installed correctly, you will see your adapter in the
'Adapter Status' tab box. You should also see the COM port number (ie COM1, COM2, etc.)
and the COM Port Status.(IDLE or BUSY).
If you see either of these messages, note the Keyspan COM port number (ie COM1, COM2, etc.)
and its COM Port Status.(IDLE or BUSY). Proceed to Step 2.
This User Manual applies to the Keyspan Mini Port Replicator Software for Windows.
(in Start menu -> Programs -> Keyspan Mini
the Keyspan Serial Assistant window
(rev 02jun19JA)
Page 30
. When you open the
