Summary of Contents for Keyspan USA-49WLC
- Page 2 Adapter Software for Mac OS 8.6 - 9.x and covers the features and use of this software on that platform. For Mac OS X information and instructions, please read the Keyspan USB Serial Software for Mac OS X User Manual or visit Keyspan's web page <http://www.keyspan.com>...
- Page 3 Note: You can only have one PRINTER port and one MODEM port on any given computer. In order for the Keyspan adapter to emulate either of these ports, the MODEM or PRINTER ports must not be 'in use' or registered by other software or hardware. For example, PRINTER/MODEM port emulation is not available on a Mac that already has a MODEM and PRINTER port builtin (any pre-USB Mac).
- Page 4 ON by using the Advanced Setting's screen. P#2USA49Wyyxx P#3USA49Wyyxx Note: If you install more than one Keyspan USB 4-Port Serial Adapters on your Mac, Ports 1 - 4 on subsequent adapters will have different names (please contact Keyspan for details). P#1USA49Wyyxx...
- Page 5 Note: These instructions apply to installing the Keyspan USB 4-Port Serial Adapter on Mac OS 8.6 through 9.x. If you are installing this software on Mac OS X via CLASSIC, please read the Keyspan USB Serial Software for Mac OS X User Manual or visit Keyspan's...
- Page 13 You should only access this option if your serial device requires that you turn on an advanced option on or if you are sure of what you are doing. In most cases, you will not need to change any of the adapter's advanced options.
- Page 15 Please Note: Using the High Power (high speed) requires that your Keyspan adapter be connected to a built in USB port on your computer or a self-powered USB Hub.
- Page 17 Note: This option is only available on Macs that do not have a built-in Modem or Printer (ie "Blue and White" G3s, iMacs, iBooks, etc.). On Keyspan Adapters that only have ONE serial port, you can only emulate the Printer port.
- Page 19 Note: This option is DISABLED on the Keyspan USB 4-Port Serial Adapter and Keyspan USB PDA Adapter...
- Page 25 Legend Compatibility List for Mac OS (8.6 - 9.x) Product Graphic Tablets Wacom Tablets (serial) PDAs and PDA Software Palm Digital Cameras and Digital Camera Software CamerAid USA19Qi USA19Q USA19QW Guide USA19 USA19W USA49W...
- Page 26 Olympus Digital Cameras (serial) Modems and Modem Software Remote Access software (Apple) AOL software Modems (serial - any model) Compatibility List for Mac OS - Notes...
- Page 30 Please note: The name(s) of your Keyspan serial port(s) vary from Keyspan product to product. Please check the section in...
- Page 31 Keyspan product's user manual for the specific port names.
- Page 32 Name DB9 Female Loopback plug Pin(s) Signal Designation Data Carrier Detect (Input) Received Data (Input) Transmitted Data (Output) Data Terminal Ready (Output) Ground Data Set Ready (Input) Request To Send (Output) Clear To Send (Input) Ring Indicator (Input) Wired to Pin(s) <->...
- Page 33 The Keyspan adapter software and hardware are working properly. The Keyspan serial port is available for use. The Keyspan serial port is 'in use' by an application on your computer and is ready to send and receive data to and from your serial device.
- Page 35 COMMAND...
- Page 36 integer( (baud / (totalBitsPerCharacter * 1000) ) + 0.5)
