- Page 1 VDR-600 2 CH Capacity Vehicle HD Video Recorder User Guide Please read and follow all instructions and features before use. Save for future reference. For latest update and specs, please visit www.ventrainc.com Manual Ver 03 18...
-
Page 2: Table Of Contents
Table of Content PRODUCT INTRODUCTION .……………………………………………………………………………………………………………………………… 2 RECORDING TIME TABLE / FUNCTION .…………………………………………………………………………………………………….……..3 INFORMATION BEFORE INSTALLATION .…………………………………………………………………………………………………………….4 IMPORTANT INFORMATION BEFORE INSTALL .………………………………………………………………………………………………….5 WARNING SAFETY PRECAUTION .……………………………………………………………………………………………………………………….6 WARNING REGULATIONS.……..…………………………………………………………………………………………………………………………..7 MODEL / PRODUCT INFORMATION ..…………………………………………………….............8 SYSTEM LAYOUT OVERVIEW ……………………………………………………………………………………………………………………………9 SPECIFICATION .……............................……..10 INSTALLATION OVERVIEW ...........................11 INSTALLATION PROCEDURE ..........................12 INSTALLATION WIRING ............................13 SOFTWARE PC VIEWER OPERATION ..……………………………………………………………………………………………………………14... -
Page 3: Product Introduction
1. Product Information Overview The VDR-600 vehicle video recorder is a 2 CH (1 + 1) capacity, all-in-one system for safety, security and fleet management. Equipped with a built-in vandal resistant lock, the system offers enhanced security to prevent unauthorized access to power cable, SD Card and Camera Angle. -
Page 4: Recording Time Table / Function
Normal and Event Recording length will vary based on the size of Micro SD card. VDR-600 will automatically record once it is connected to the car battery/fuse or when the vehicle ignition is on. Recording can be stopped by unplugging the power cable from the VDR or turning off the engine (cigar plug connection). -
Page 5: Information Before Installation
The VDR-600 main camera is designed to be installed inside of the vehicle to record front and rear (or interior) with audio (can be disabled). This device is to encourage safe driving and provide video documentation. -
Page 6: Important Information Before Install
Altering and disassembling of the product may result in a fire or electric shock. Disassembling the product will void the warranty. Inquire with Ventra in the event the product needs repair Do not store the product in extreme high or low weather conditions. Exposure to sunlight for extended period of time could cause the product to malfunction ... -
Page 7: Warning Safety Precaution
If using the permanent battery power cable to connect the VDR-600 to the vehicle’s battery, please remember to disconnect the power plug from the unit. Vehicle battery will be drained if left unoperated for an extended period of time depending of the size and condition of the battery ... -
Page 8: Warning Regulations
Use of this product other than its intended purpose is strictly prohibited Ventra Technologies Inc. does not assume any responsibility for any fines, violation, penalties or damages that may be incurred as a result of the use of the product Ventra Technologies Inc. -
Page 9: Model / Product Information
1. Product Information Model Information Model: VDR-600 Model: VDR-600BT Included Components Included Components Main Camera & mounting bracket Main Camera & mounting bracket Permanent Power cable (Hardwired) Permanent Power cable (Hardwired) Key lock Key lock ... -
Page 10: System Layout Overview
Camera Angle Adjustment Screw • GPS Input • Power Input • Video Input – 2 Camera • Video Output If using optional EX6-OMIR expansion camera, connect camera PIN connector to VIDEO IN port on VDR-600 EX6-OMIR is powered by VDR-600 (5VDC) -
Page 11: Specification
Camera Angle (EX6-OMIR / Rear) Recording Resolution (EX6-OMIR / Rear) Analog HD 720P 1280x720 @ 30FPS Power consumption of (EX6-OMIR / Rear) 5V – Provided by the VDR-600 Main Camera Recording Mode Normal, Parking, Event, Pre-Event Video Out CVBS output (1V Vp-p 75ohm) -
Page 12: Installation Overview
Video Input port of the VDR-600 by using the provided extension cable. 4) Insert the micro SD memory card into the VDR-600. (Ensure that the micro SD memory card is properly inserted - will hear a click sound) -
Page 13: Installation Procedure
Allow sufficient room for access to Lock and SD Card Tuck the power cable between the windshield and Install VDR-600 on windshield - below or adjacent interior liner to the rear view mirror. Press the VDR against the... -
Page 14: Installation Wiring
Ventra is not responsible for any damages arising from installation Identify the proper fuse and location. Refer to vehicle owners manual. -
Page 15: Software Pc Viewer Operation
2. Operations and Functions of Viewer Insert the micro SD memory card directly to PC or use a memory card reader to connect the micro SD memory card to PC. Open the micro SD memory card folder and double click on [viewer.exe] file to run the VDR PC Manager program. -
Page 16: Software Pc Viewer Layout
2. Operations and Functions of Viewer (Cont.) [VDR PC Manager] 1) Playback Display Screen : It shows the playback of the recorded video data from the micro SD memory card. ① Enlarge Screen: Double click the mouse enlarges the display screen. Double click again returns to its original size ②... -
Page 17: Software Pc Viewer Function
2. Operations and Functions of Viewer (Cont.) 3) GPS Information : Displays the longitude, latitude, azimuth, date and time of the current playback 4) Playback Position Slider / Playback Time : Choose the position of playback data and displays current / the total time of playback 5) Control Button Jump to previous file Reverse playback search... -
Page 18: Software Pc Viewer Function (Cont'd)
1. Insert a BLANK micro SD memory card in to the computer 2. Download the updated firmware from Ventra website onto a BLANK micro SD card 3. Insert the micro SD card in to the VDR and power on the system. The LED lights will begin to flicker as the VDR automatically executes the firmware update. -
Page 19: Software Pc Viewer Function (Cont'd)
2. Operations and Functions of Viewer (Cont.) [Playing the recorded data] 1) Click the ‘OPEN’ button. Load the data from the micro SD memory card which is connected to PC. 2) [Select drive] window appears. Select the micro SD memory card drive and then click the ‘OK’... -
Page 20: Software Pc Viewer System Overview
2. Operations and Functions of Viewer (Cont.) [Setup configurations] 1)Click the ‘Configuration’ icon. 2)‘Configuration’ window appears. Select the desired function and settings, select Save and the updated settings will be saved to the micro SD card. Insert the micro SD memory card into the micro SD memory card slot of the VDR and turn the power on. -
Page 21: Recording Frame Rate, G-Sensor Level
2. Operations and Functions of Viewer (Cont.) • Recording Frame setting (default setting : maximum) - Maximum recording mode (Max. normal recording mode) This is the normal recording mode which records a total of 30 FPS (frames per second) for the entire system. The 30 FPS is shared between front which is 20 FPS for the front channel and... -
Page 22: Nd Camera
ALL local, state and federal laws and regulations • Connected Camera (default setting : both front and EX6-OMIR 2 expansion camera) - Record main VDR-600 camera and optional EX6-OMIR 2 camera... -
Page 23: Voice Guidance, Time Zone, Time And Date Settings
2. Operations and Functions of Viewer (Cont.) • Audio Guide Volume (default setting : 4) - Adjust the volume of audio announcement or operation status - Select the setting from 0 (off) to 4 (max) Time Zone : regional time setting (default setting : +9 *Seoul) Pacific = GMT –... -
Page 24: Voltage Check, Video Quality, Led Light Indicator
2. Operations and Functions of Viewer (Cont.) • Voltage Check (default setting : 12.0v) Voltage Check for both driving and parking mode. - Function for avoiding battery discharge and low battery protection - Off: it operates without battery protection mode (NOT Recommended) i.e. -
Page 25: Password, User / Vehicle Info, Auto Shut Off Timer
• Password - Password protection for playback and configurations - Please safeguard password. For privacy reason, Ventra does have or provide master code or password reset • Information - Input information such as company name, vehicle type, license plate and driver name or ID to be displayed on the screen or in backup screen shot •... -
Page 26: Event Selection, Sudden Start, Stop And Turn, Max Speed Limit
2. Operations and Functions of Viewer (Cont.) • Event Select - To select which types of occurrences or driving behaviors are recorded as an event. It shows the [letter] of an event for that playback period in the playback list. Adjustable sensitivity settings for different Event categories [I] Impact –... -
Page 27: Export Folder Directory, Video Playback Mode, Mirror Function
The updated settings are saved to the micro SD card. Insert the micro SD memory card into the VDR-600 and turn on the power. The VDR will load and update new settings. Please be aware of that if the [index.dat] file gets deleted from the micro SD memory card, it does not allow to save the configuration settings. -
Page 28: Export Folder Directory, Video Playback Mode, Mirror Function
2. Operations and Functions of Viewer (Cont.) • Select the folder for AVI, Snapshot and Smart Backup to be saved • Video display mode (default setting : Direct Draw) - DirectDraw – select this option if using a relatively high-quality graphic card - DIB –... -
Page 29: Save Image, Export Avi Video
2. Operations and Functions of Viewer (Cont.) [Printing the video image on display] 1) Click the ‘PRINT’ icon to open print option. Click the [OK] button. This prints a screenshot of the video image on display while viewing the playback. [AVI Backup] 1) This feature export and converts a specific video recording into an AVI media file. -
Page 30: Smart Video Export / Backup
2. Operations and Functions of Viewer (Cont.) [Smart backup] 1) This function exports / backup specific VDR-600 file recordings and time period. The recordings can only be viewed via the VDR-600 PC viewer - 1 : Playback list - 2 : Select / Export button... -
Page 31: Smart Video Export / Backup
Operations and Functions of Viewer (Cont.) [Saving the video image on display as jpg, png, bmp files] 1) Click the 'Capture‘ icon to open [Select Channel] window. Select the ‘Save Folder’ and file type such as JPG, PNG, BMP and click ‘OK’ button - 1 : Browse (folder) location - 2 : Enter the filename - 3 : Choose desired channel display type... -
Page 32: Troubleshooting
1. Check that the power of is properly connected on VDR and Vehicle. System does not start. 2. Use only the cable that is supplied by Ventra 1. Make sure the camera lens is clean and dust free Video is not as clear as it should be. -
Page 33: Warranty
During this period, Ventra’s liability for any defective product, or any product part, shall be limited to the repair or replacement of the product, at Ventra’s sole discretion. This warranty does not apply to defects or damages resulting from mishandling, accident, abuse, negligence, lightning, water/liquid, power surges, improper interfacing, operation outside of design limits, misapplication, improper repair, or unauthorized modification.
