Page 1: Quick Installation Guide
Quick Installation Guide BTG771AM-0T1 Business Cellular Gateway (with GSM/3G voice) FW: 00KG0.1005 UM: V1.2_20140724... -
Page 2: Chapter 1 Introduction
Business Cellular Gateway Chapter 1 Introduction Congratulations on your purchase of this outstanding product: Business Cellular Gateway with GSM/3G voice. This device is specifically designed for SMB mobile office. No matter offices are located at wire unreachable area or on the move, it can connect to Intranet of headquarter instantly. - Page 3 Business Cellular Gateway Support multiple sessions IPSec, L2TP and PPTP VPN pass-through Support QoS mechanism for efficiently prioritizing the various type of traffics Phone Calls via GSM/UMTS Network Support voice over GSM/UMTS circuit-switched network Logs for incoming calls, outgoing calls, and missed calls ...
-
Page 4: Hardware Installation
Business Cellular Gateway RJ45 Cable 1pcs 1pcs 1.2 Hardware Installation 1.2.1 WARNING Do not use the product in high humidity or high temperatures. Only use the power adapter that comes with the package. Using a different voltage rating power adaptor is dangerous and may damage the product. -
Page 5: Hardware Configuration
Business Cellular Gateway An installed Ethernet adapter Browser Requirements: Internet Explorer 6.0 or higher Chrome 2.0 or higher Firefox 3.0 or higher Safari 3.0 or higher Computer with the following: ® ® Windows 7, Vista , or XP with Service ... -
Page 6: Led Indication
Business Cellular Gateway Front View: BTG771-0T1 3G/ 4G Antenna Reset Button 3G/ 4G Antenna 1.2.4 LED Indication BTG771-0T1 LED Icon Description Flash per second: System is powered on, and working normally Green and steady on: A problem occurred with system Status operation OFF: System is powered off, or a problem occurred with... - Page 7 Business Cellular Gateway OFF: No Ethernet cable attached Green: Ethernet connection is established Green in flash: Data packet are transferred via Ethernet OFF: No Ethernet cable attached or device is not linked LAN1 ~ LAN4 Green: Ethernet connection is established Green in flash: Data packet are transferred via Ethernet OFF: Wireless Radio is disabled Green and steady on: Wireless Radio is enabled...
-
Page 8: Chapter 2 Getting Started
Business Cellular Gateway Chapter 2 Getting Started 2.1 Connect Your Device Before you can use this product, you need to connect your PC or device to this gateway first. You can connect your PC to one of LAN1~LAN4 ports through an Ethernet cable. Otherwise, your device can also connect to it through WiFi. - Page 9 Business Cellular Gateway 2.2.1 Wizard Select “Wizard” for basic network settings and VPN settings in a simple way. Or, you can go to Basic Network / Advanced Network / Applications / System to setup the configuration by your own selection. A.
- Page 10 Business Cellular Gateway Step 3: Time Zone Time Zone Configuration: It will detect your time zone automatically. If the result of auto detection is not correct, you can press “Detect Again” button or select manually. Press “Next” to continue. Step 4: WAN WAN Interface Configuration: Choose type of WAN connection.
- Page 11 Business Cellular Gateway Step 4-3: Ethernet (PPPoE) If choosing Ethernet->PPP over Ethernet (so-called PPPoE), you need to input account and password that you get from ISP. For other fields, you can leave them as blank in most cases. This option is usually chosen when you use ADSL for WAN connection.
- Page 12 Business Cellular Gateway Step 5: Ethernet LAN LAN Interface Configuration: Change the LAN IP address and subnet mask of this gateway. You can keep the default setting and go to next step. Press “Next” to continue. Step 6: WiFi LAN WiFi LAN Interface Configuration: Change SSID, Channel...
- Page 13 Business Cellular Gateway Step 1 The VPN setup wizard will guide you to finish profiles of IPSec, PPTP, and L2TP VPN connection quickly. Press “Next” to start the wizard. Step 2: VPN Type Select type of VPN connection you want to create.
- Page 14 Business Cellular Gateway Step 2-2: PPTP If choosing PPTP, there are two options of mode can be chosen. Choose “Client” if you want this device to connect to another PPTP server. Or choose “Server” if you want other PPTP clients to connect to it.
- Page 15 Business Cellular Gateway Step 2-3: L2TP If choosing L2TP, there are two options of mode can be chosen. Choose “Client” if you want this device to connect to another L2TP server. Or choose “Server” if you want other L2TP clients to connect to it.
- Page 16 Business Cellular Gateway Step 3: Confirm and Apply Confirm new settings. If all new settings are correct, please press “Apply” button to save these new settings and take them effective. BTG771 Quick Installation Guide...
