Sibelmed DATOSPIR touch Quick Start Manual

CALIBRATION
(C) Making a calibration:
1.
Press
2.
Press
3.
Press
Repeat points 2 and 3 of the previous section
4.
Once the calibration cycles are completed, the device
should display the "CALIBRATED !!!" message.
5.
Press
The difference in this mode is that the device not only checks the calibration,
but also stores the new calibration factors.
0197
Class IIa product according to 93/42/CEE Medical Device Directive
SIBEL S.A. Rosselló 500 Bajos, 08026 Barcelona
National sales: Tel. 93 436 00 08 · e-mail: comercial@sibelmed.com
International sales: Tel. +34 93 436 00 07 · e-mail: export@sibelmed.com
SIBEL S.A. is a member of
After-sales Service: Tel. +34 93 433 54 50 · e-mail: sat@sibelmed.com
www.sibelgroup.com
Fax: +34 93 436 16 11
in the main menu.
in the setup menu.
in the calibration menu.
(B).
to save the calibration.
www.sibelmed.com
Quick start guide
DATOSPIR
Congratulations, you have acquired a SIBELMED spirometer, a leading brand in the
industry.
Please read the USER MANUAL in order to maximize its using.
The spirometer is a compact device based in different types of
DATOSPIR touch
transducers: Fleisch, Turbine or disposable Lilly, a wide color touch screen, a built-in
temperature sensor and a thermal printer. An internal database is used to store the
tests and an external printer can be connected via USB or Bluetooth.
SETUP
When placing the spirometer make sure that the following conditions are meet:
- Mains connection: 100 to 240V AC.
- Operating temperature: 5 to 40º C
- Relative humidity: < 85 % (without condensation).
- Pressure: 850 to 1060 hPa. (638 to 795 mmHg / 1500 to 0 m aprox.)
- Keep away from splashing water or other liquids.
Note: Read the user's manual for a safe use of the device.
Use mouthpieces certified acording to Directive 93/42/EEC to
ensure the patient safety and the quality of spirometry.
touch
