FAX2050L
Operator Instruction Manuals
FAX2050L BASIC
FAX2050L ADVANCED
Five Dedrick Place • West Caldwell, NJ 07006
973-882-2000
Read this manual carefully before you use this product and keep it handy for future
reference. For safety, please follow the instructions in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAX2050L Advanced and is the answer not in the manual?

Questions and answers

Related Manuals for Ricoh FAX2050L Advanced

Summary of Contents for Ricoh FAX2050L Advanced

  • Page 1 FAX2050L Operator Instruction Manuals FAX2050L BASIC FAX2050L ADVANCED Five Dedrick Place • West Caldwell, NJ 07006 973-882-2000 Read this manual carefully before you use this product and keep it handy for future reference. For safety, please follow the instructions in this manual.
  • Page 3 FAX2050L Basic Features...
  • Page 5 For good copy quality, Ricoh recommends that you use genuine Ricoh toner. Ricoh shall not be responsible for any damage or expense that might result from the use of parts other than genuine Ricoh parts in your Ricoh office product.
  • Page 6 6. In the event of operation problems (document jam, copy jam, communication error indication), refer to the solving problems section in this manual. 7. If you cannot correct the problem, please contact the RICOH CORP. CUSTOMER SUPPORT DEPT. at 1-800-FASTFIX for repair and warranty information. If it is causing harm to the tele- phone network, the telephone company may request you to disconnect the equipment from the network until the problem is resolved.

  • Page 7: How To Read This Manual

    How to Read This Manual Symbols In this manual, the following symbols are used: R WARNING: This symbol indicates a potentially hazardous situation that might result in death or serious injury when you misuse the machine without following the in- structions under this symbol.

  • Page 8: Table Of Contents

    Manuals for this machine ... 1 Basic Features (This Manual) ... 1 Advanced Features ... 1 Part Names... 3 Operation Panel ... 5 Symbols and Conventions Used in This Manual... 7 Types of Transmission ... 9 Suitable Document Types... 10 Memory Transmission and Immediate Transmission...
  • Page 9 Loading Paper in the Main Cassette... 31 Adjusting the Volume and Sounds the Machine Makes (Function 92)... 34 If an Indicator Lights on the Operation Panel... 36 Communication Problems ... 37 Clearing a Document Jam ... 38 Clearing a Copy, Fax, or Print Jam ... 39 Main Machine...

  • Page 11: Basic Features (This Manual)

    There are the Basic Features manual and the Advanced Features manual for this machine. Please consult the manual that suits your needs. Basic Features (This Manual) The Basic Features manual explains the most frequently used fax functions and operations. Advanced Features The Advanced Features manual describes more advanced functions, and also explains settings for key operators.
  • Page 12 ❖ Chapter 8 Troubleshooting Explains about clearing a Jam in the optional second cassette, and reading er- ror reports. When these reports are printed out, check the report and take the appropriate action. ❖ Chapter 9 Maintaining Your Machine Explains about loading paper in the optional multipurpose feeder, cleaning the rollers and scanner and so on.
  • Page 13 TSTH060N.eps Second Paper Cassette (Option) The optional Second paper cassette holds more paper. Main Paper Cassette The main paper cassette holds copy pa- per. Print Delivery Tray Copies, incoming faxes, and prints are delivered here. Document Delivery Tray Scanned documents are stacked on the document delivery tray.

  • Page 14: Operation Panel

    Introduction Main Switch The main switch turns your machine on and off. Operation Panel Key panel for operating the machine. Handset (Option) Document Guide Match the document guide to the size of your original documents. Document Table Document table holds up to 30 sheets which are fed one at a time.
  • Page 15 TSTS020N.eps Add Paper indicator Lights when a cassette is empty. Add Toner indicator Blinks when toner is about to run out and lights continuously when toner has run out. Check Display indicator The Check Display indicator lights to tell you to read the display. Receive File indicator The Receive File indicator lights when an incoming message was received into...
  • Page 16 Introduction Manual Receive indicator. Lights when the reception mode is Tele- phone. {Energy Saver} key Hold the button a few seconds to start or end the energy saver mode. {Copy} key Press this to copy the document now in the feeder. {Reception Mode} key Press this to select the reception mode (Tel or Fax).

  • Page 17: Symbols And Conventions Used In This Manual

    ❖ Documents: A document is anything you put on the feed table of your machine whether you are faxing it or copy- ing it. ❖ Prints: A print is anything that comes out of the machine: a fax message you received or a copy you made.
  • Page 18 Introduction...

  • Page 19: Types Of Transmission

    There are two types of transmission. ❖ Memory Transmission When a fax message is stored in memory , then transmission starts automati- cally. It is convenient when you would like to take documents back in a hurry. You can send the same message to more than one destination in a single op- eration.
  • Page 20 Faxing Do not place damaged pages in the automatic document feeder. • If pages are curled or dog eared, flatten them. • If pages are stuck together, shuffle the stack. • If pages are folded, torn, or patched together, make copies. •...

  • Page 21: Memory Transmission And Immediate Transmission

    There are two ways to send a fax mes- sage. • Memory Transmission • Immediate Transmission Memory Transmission A Memory Transmission is conve- nient because: • Fax messages can be scanned much more quickly (you can take your document away from the fax machine without waiting too long).
  • Page 22 Faxing Insert the document face down into the feeder until the machine beeps. Then adjust the guides to match the width of the document. TSTH110N.eps Note ❒ You can dial before you set the document. Place the document after you dial the number and go to step G.
  • Page 23 Reference Programming Quick Dial: see P.22 “Storing and Editing Fax Numbers (Functions 31 & 32)”. Programming Speed Dial: see P.22 “Storing and Editing Fax Numbers (Functions 31 & 32)”. Programming Group Dial: see P.25 “Storing and Editing a Group of Fax Numbers (Function 33)”. Programming Group key: see P.28 “Programming the Group Key”.

  • Page 24: Canceling A Memory Transmission

    Faxing Canceling a Memory Transmission Before start is pressed Press the {Stop} key, or remove the document You have set. While the document is being scanned in Press the {Stop} key. The fax message which has already been scanned in is cancelled. During Transmission Press the {Stop} key during com- munication.

  • Page 25: Immediate Transmission

    Immediate Transmission Immediate Transmission is conve- nient when: • You wish to quickly check whether you have successfully connected with the other party's fax machine. • Your machine's memory is getting full. The machine dials immediately after you press the {Start} key (or at the specified time, if you used a time-de- lay feature like Send Later).

  • Page 26: Resolution And Shading

    Faxing So that text, diagrams and images stand out clearly in your document, the machine automatically detects the image density (contrast) and makes a compensation. However, if you need to send a docu- ment which requires optimum clari- t y, sele ct the resolution se tting appropriate to your needs.

  • Page 27: Reception Modes

    The machine can treat incoming fax messages and telephone calls in three ways. ❖ Auto mode Use this mode if your line is shared by a fax machine and telephone. When a call comes in, the machine will ring a number of times to give you the chance to pick up the handset.
  • Page 28 Faxing...

  • Page 29: Initial Settings (Function 61)

    Before you connect your machine to the telephone system, you must enter a few settings and make a few adjust- ments. ❖ Own Number : The phone number used by your fax line. ❖ OWN NAME: This should be your name or com- pany name, in 20 characters or less.
  • Page 30 Setup Press {Function} {6} and enter the access code {2} {2} {2} {2}, and then press {6} {1} and the {Yes} key. SET OWN NUMBER Press the {Yes} key. OWN NO. kkkkkkkkkkkkkkkkkkkk Enter your phone number. OWN NO. 0111212-5551234kkkkk Note ❒...

  • Page 31: Fax Number

    Press the {No} key to keep the FAX HEADER as is. Y/NEXTi SET FAX NUMBER Press the {Yes} key. FAX NUMBER kkkkkkkkkkkkkkkkkkkk Enter your phone number includ- ing the country and area codes, (but no pauses). FAX NUMBER KPAD/Y/N 12125551234kkkkkkkkk Press the {Yes} key.

  • Page 32: Storing, Editing And Erasing Quick Dial Numbers (Function 31)

    Setup You can store numbers that you often use in the machine's memory. A stored number will remain in memo- ry even if the power is cut. You can store numbers in two ways. ❖ Quick Dials The number is assigned to its own key.

  • Page 33: Storing And Editing Fax Numbers (Functions 31 & 32)

    Enter or edit the label using the Quick Dial keys and the ten key pad. See P.29 “Entering Charac- ters” ABC Y/N NEW YORK OFFICEkkkkk Press the {Yes} key. LABEL SET ONiOFF Press W or V to select whether the label for this Quick Dial will be printed on top of messages that you send to this destination.
  • Page 34 Setup Press the {Yes} key. kkkkkkkkkkkkkkkkkkkk Do one of the following: •Enter the fax number you wish to store in this Speed Dial using the ten key pad. Then press {Yes} key. 212551234kkkkkkkkkkk •To clear the number, press {No}, and go to step J. Do one of the following: •If you wish to enter or edit a label for this Speed Dial, press the {Yes}...

  • Page 35: Storing And Editing A Group Of Fax Numbers (Function 33)

    ❖ Groups If you often broadcast messages to the same set of destinations, you can combine these numbers into a group. Then just select the group and each number will be dialed in sequence automatically. You can register the following items in a Group: •...
  • Page 36 Setup Registered items Quick Dial: [01], [02], [03] Speed Dial: [01], [02], [03] Ten Key: 0312345678 Quick Dial: [04], [05] Speed Dial: [04], [05], [06] Ten Key: 0312345678, 0451119999 This section describes how to pro- gram or edit a Group. You can also get a printout of numbers that are al- ready stored.

  • Page 37: Erasing Groups

    Enter a fax number. Note ❒ Enter a number in one of these ways. • Press a Quick Dial key. • Press the Speed Dial key fol- lowed by two digits. • Enter a number on the ten key pad. Press the {Yes} key.

  • Page 38: Programming The Group Key

    Setup Programming the Group Key You can program 5 groups. However, if there is no room in Quick Dial keys, this group key is helpful. You can use Quick Dial 30 or one of User Function keys (F1 or F2) as the group key. How to transmit using the group key, see P.11 “Memory Transmission”.

  • Page 39: Entering Characters

    Use the ten key pad for entering num- bers. Use Quick Dial keys 1 to 26 for entering letters, and Quick Dial key 27 for spaces and Quick Dial key 28 for other characters. If at any time you make a mistake when entering a character or digit, press the {Clear} key to erase it.
  • Page 40 Setup...
  • Page 41 Pull out the paper cassette and place it on a flat surface. Note ❒ Remove any paper that may have dropped inside the machine in the area vacated by the paper cassette. TSTC200E.eps Lift up the cassette cover and remove it. TSTC100N.eps Remove any remaining paper.
  • Page 42 Troubleshooting If the metal base plate is raised, push it firmly down until it locks into place. TSTC050N.eps Prepare a stack of blank paper. For smoother operation, square the edges. TSTS010N.eps Load the paper into the cassette. TSTC210N.eps TSTC050N...

  • Page 43: Loading Paper In The Main Cassette

    Replace the cassette cover. Note ❒ The frosted side of the cover must be face up when closed. TSTC220N.eps Replace the cassette. Push it in firmly until it locks into place. TSTC230E.eps Loading Paper in the Main Cassette TSTC220N...
  • Page 44 Troubleshooting You can change the beeper (monitor) volume of the desired feature. TRANS MONITOR RECV MONITOR ONHOOK MONITOR DIAL MONITOR BUZZER Press {Function} {6} and enter the access number {2} {2} {2} {2}. Then press {9} {2}. ADJUSTMENT 92 ADJUST VOLUME Press the {Yes} key.

  • Page 45: Adjusting The Volume And Sounds The Machine Makes (Function 92)

    Adjust the dial monitor volume with the W and V keys, and then press the {Yes} key when finished. DIAL MONITOR MIN iii Adjust the BUZZER monitor volume with the W and V keys, and then press the {Yes} key when finished. BUZZER Y/N/hi MIN iii...
  • Page 46 Troubleshooting ❖ PRESS STOP KEY Press the {Stop} key. ❖ The Receive File indicator is lit: You have received a fax message which is now stored in the memory. See Chapter 4, ”Printing Message That Have Been Received into Memory (Substi- tute Reception)”in the Advanced Features manual.

  • Page 47: Communication Problems

    appears in the ERROR PRESS STOP display: Press the {Stop} key. ERROR PRESS STOP KEY Causes: • A poor line caused the communi- cation to fail. • The line is noisy. Try to transmit the fax message again. • The other machine is out of order. Ask the other party to check their machine.
  • Page 48 Troubleshooting When an original is jammed, CLEAR ORIGINAL is displayed, follow this pro- cedure to solve the problem. Note ❒ If copies, fax message or prints are jammed, follow the next procedure. Open the operation panel to an angle of about 45°. TSTJ030N.eps Remove the original.

  • Page 49: Clearing A Copy, Fax, Or Print Jam

    When CLEAR COPY is displayed, follow this procedure to solve the problem. For clearing original jams, see the previous procedure. Main Machine Pull the front cover release lever towards you and open the front cover. Note ❒ If you do not pull the lever, only the upper unit will open. TSTC380N.eps TSTC330N.eps Remove the toner cassette.
  • Page 50 Troubleshooting Remove any jammed paper underneath. TSTJ170N.eps Replace the toner cassette. Zaxt010n.eps Close the front cover. TSTC390N.eps...

  • Page 51: Cassette Entrance

    Cassette Entrance Remove the main cassette and place it on a flat surface. TSTC200E.eps Remove any paper from inside the machine. TSTJ080N.eps Push down the paper so that the base plate locks into place. TSTJ090N.eps Clearing a Copy, Fax, or Print Jam TSTJ090N...

  • Page 52: Upper Rear Unit

    Troubleshooting Replace the main cassette. TSTC230E.eps Upper Rear Unit Lift back the document table. TSTF050N.eps Open the upper rear cover. TSTJ120N.eps TSTJ120N...
  • Page 53 Pull out any jammed paper. TSTJ110N.eps Close the upper rear cover. TSTJ130N.eps Clearing a Copy, Fax, or Print Jam TSTJ110N TSTJ130N...
  • Page 54 Troubleshooting The following messages may appear while you are operating or programming the machine. CHECK AUTO-DIALING NO FILE EXISTS TOO MANY DEST. USED AS GROUPDIAL USED AS PROGRAM USED AS DIAL USED AS GROUP KEY NOT PROGRAMMED ALREADY PROGRAMMED PLEASE SET PAUSE ADD TONER CLEAR ORIGINAL CLEAR COPY...

  • Page 55: Error Messages

    CLOSE COVER UNABLE USE PRINTER SERVICE CALLk-kk USED AS DIAL OPTION WCHECK PAPER SIZE IN USE A cover is not closed properly. Check that all covers are closed. Machine cannot print a list/file, because the heater is not warm enough or printer is not ready.
  • Page 56 Troubleshooting Problem STANDBY MODE Nothing happens when the switch is turned on. SET DOC. OR DIAL NO. not displayed. The display does not show the Ready condition, or the machine stops during an operation. TRANSMISSION The original is not pulled into the auto document feeder.

  • Page 57: Solutions To Common Problems

    Problem The original is not pulled into the auto document feeder. Frequent original misfeeds (Multifeeds) Frequent original misfeeds (Non-feeds) Required Action The dialed number does not contain an PSTN access code or a pause. Include the PSTN access number and a pause before the tele- phone number.
  • Page 58 Troubleshooting Problem Transmission cannot take place; appears. CLEAR ORIGINAL Transmission cannot take place. Before taking action, wait until the machine is standby mode, and then press the {Stop} key. Consistent difficulty in commu- nicating with a particular termi- Consistent poor image quality when communicating with a particular terminal RECEPTION...
  • Page 59 Problem Copy paper misfeeds occur fre- quently. Stripes on copies. TELEPHONING You cannot receive phone calls; the unit only rings once then goes into receive mode. You cannot receive phone calls; the unit does not ring. Required Action Is the proper paper in the paper cassette? Paper size and weight must be within the standards set for this machine.
  • Page 60 Add Paper indicator , 5 Add Toner indicator , 5 Arrow keys , 5 Auto Mode , 17 Canceling a Memory Transmission , 14 Before start is pressed , 14 During Transmission , 14 While the document is being scanned in , 14 While the message is awaiting transmission (Functions 21) , 14 Canceling an Immediate Transmission , 15...
  • Page 61 Main Paper Cassette , 3 Main switch , 4 Manual Receive indicator , 6 , 17 Memory indicator , 5 Memory Transmission , 11 Multi-purpose Feeder , 4 On Hook Dial key , 6 Operation Panel , 4 , 5 OWN NAME , 19 Own number , 19 Paper , 31...
  • Page 62 USA H546...
