Periodic maintenance and adjustment
Removing and installing pan-
els
The panels shown need to be removed
to perform some of the maintenance
jobs described in this chapter. Refer to
this section each time a panel needs to
be removed and installed.
1
2
1. Panel A
2. Panel B
9
Panel A
To remove the panel
1. Remove the screws and quick fas-
tener screw.
EAU18773
2
3
1
1. Panel A
2. Screw
3. Quick fastener screw
2. Extend the right passenger foot-
rest, and then pull the panel out-
ward.
To install the panel
1. Place the panel in the original po-
sition, and then install the screws
and quick fastener screw.
EAU77170
2 2
2. Retract the right passenger foot-
Panel B
To remove the panel
1. Remove panel A.
2. Remove the right floorboard mat
3. Remove the screws and bolts,
9-7
rest to its original position.
by pulling it up.
and then pull the panel outward.
