Yamaha XCITY VP125 Owner's Manual

Hide thumbs Also See for XCITY VP125:
Table of Contents

Advertisement

Quick Links

Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
VP125
16P-F8199-E1

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XCITY VP125

Summary of Contents for Yamaha XCITY VP125

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL VP125 16P-F8199-E1...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product:...
  • Page 3 EAU10113 Welcome to the Yamaha world of motorcycling! As the owner of the VP125, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAUM1010 VP125 OWNER’S MANUAL ©2008 by MBK INDUSTRIE 1st edition, July 2008 All rights reserved Any reprinting or unauthorized use without the written permission of MBK INDUSTRIE is expressly prohibited. Printed in France.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Ignition circuit cut-off system ..3-17 Valve clearance ......6-15 Further safe-riding points ....1-5 Tires ..........6-15 FOR YOUR SAFETY – Cast wheels ......... 6-17 DESCRIPTION ........2-1 PRE-OPERATION CHECKS ..... 4-1 Front and rear brake lever free Left view ..........2-1 play ...........
  • Page 7 TABLE OF CONTENTS Troubleshooting ......6-29 Troubleshooting charts ....6-30 SCOOTER CARE AND STORAGE ...7-1 Care ..........7-1 Storage ...........7-3 SPECIFICATIONS ......8-1 CONSUMER INFORMATION.....9-1 Identification numbers ....9-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10263 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly...
  • Page 9 SAFETY INFORMATION cessive speed or undercornering This scooter is designed for on- A passenger should also observe (insufficient lean angle for the road use only. It is not suitable for the above precautions. speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective apparel...
  • Page 10 Yamaha accessories, which are avail- the scooter is changed. To avoid the imize imbalance or instability. able only from a Yamaha dealer, have possibility of an accident, use extreme Shifting weights can create a sud- been designed, tested, and approved caution when adding cargo or accesso- den imbalance.

  • Page 11: Specifications

    • Accessories fitted to the handle- Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories...

  • Page 12: Further Safe-Riding Points

    SAFETY INFORMATION EAU10372 Always wear a helmet, gloves, Further safe-riding points trousers (tapered around the cuff Be sure to signal clearly when and ankle so they do not flap), and making turns. a bright colored jacket. Braking can be extremely difficult Do not carry too much luggage on on a wet road.

  • Page 13: Description

    DESCRIPTION EAU32220 Left view 1. Rear storage compartment (page 3-13) 9. Front brake pads (page 6-18) 2. Shock absorber assembly spring preload adjusting ring (page 3-15) 3. Final transmission oil filler cap (page 6-11) 4. Air filter element (page 6-13) 5.

  • Page 14: Right View

    DESCRIPTION EAU32230 Right view 1. Grab bar (page 5-2) 2. Main fuse/fuse box (page 6-24) 3. Battery (page 6-23) 4. Coolant reservoir cap (page 6-12) 5. Fuel tank cap (page 3-10) 6. Engine oil filler cap (page 6-8) 7. Centerstand (page 6-21) 8.

  • Page 15: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 7 8 9 1. Rear brake lever (page 3-9) 9. Front brake lever (page 3-9) 2. Left handlebar switches (page 3-8) 3. Front storage compartment (page 3-13) 4. Speedometer/Multi-function display (page 3-4/page 3-5) 5. Luggage hook (page 3-16) 6.

  • Page 16: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 17: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10471 EAU34121 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary lights come on, and the engine can be start- ed.

  • Page 18: Indicator And Warning Lights

    The key can be re- lem is detected in the electrical circuit moved. monitoring the engine. If this occurs, have a Yamaha dealer check the self- To lock the steering diagnosis system. 1. Turn the handlebars all the way to The electrical circuit of the warning light the left.

  • Page 19: Speedometer

    If the immobilizer system is not Yamaha dealer and have the stan- working correctly, the indicator light will dard keys re-registered. start flashing a pattern when the key is turned to “ON”.

  • Page 20: Fuel Gauge

    INSTRUMENT AND CONTROL FUNCTIONS EAUM1471 EAU12172 EAUM2252 Fuel gauge Coolant temperature gauge Multi-function display ZAUM0639 ZAUM0640 ZAUM0638 1. Fuel gauge 1. Red zone 1. “MODE” button 2. Fuel level warning light 2. Multi-function display With the key in the “ON” position, the 3.
  • Page 21 INSTRUMENT AND CONTROL FUNCTIONS Trip 1 or Trip 2 → Time 1 or 2 → Aver- two tripmeters (which show the Odometer and tripmeter modes age speed 1 or 2 → Trip 1 or Trip 2 distance traveled since they were Pushing the “MODE”...
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Ambient temperature display ZAUM0393 ZAUM0394 ZAUM0396 To reset a tripmeter, select it by push- 3. Push the “MODE” button, and the 1. Frost warning indicator “ ” ing the “MODE” button, and then push minute digits will start flashing. 2.

  • Page 23: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS Oil change indicator “OIL” EAU12347 Handlebar switches The oil change indicator will come Left on at the initial 1000 km (600 mi), 5000 km (3000 mi) after the initial 1000 km (600 mi) and every 6000 km (3600 mi) thereafter.

  • Page 24: Front Brake Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAUS1020 EAU12900 EAU12950 Dimmer switch “ ” Front brake lever Rear brake lever Set this switch to “ ” for the high beam and to “ ” for the low beam. With the headlight on low beam, press this switch downwards to flash the headlight.

  • Page 25: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAUM2161 EWA11091 EAU13212 Fuel tank cap Fuel WARNING Make sure there is sufficient gasoline in Make sure that the fuel tank cap is To open the fuel tank cap the tank. properly closed after filling fuel. EWA10881 Leaking fuel is a fire hazard.
  • Page 26 Gasoline is poisonous and can cause injury or death. Handle gaso- Your Yamaha engine has been de- line with care. Never siphon gaso- signed to use premium unleaded gaso- line by mouth. If you should swallow...

  • Page 27: Catalytic Converters

    INSTRUMENT AND CONTROL FUNCTIONS EAU13445 ECA10701 EAU13932 Catalytic converters Seat NOTICE This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. To open the seat of leaded gasoline will cause unre- 1. Place the scooter on the center- EWA10862 pairable damage to the catalytic WARNING...

  • Page 28: Storage Compartments

    INSTRUMENT AND CONTROL FUNCTIONS 2. Remove the key from the main EAUM2521 EWA11191 Storage compartments WARNING switch if the scooter will be left un- attended. Do not exceed the load limit of 1 Front storage compartment kg (2 lb) for the front storage compartment.

  • Page 29: Windshield

    INSTRUMENT AND CONTROL FUNCTIONS Do not exceed the maximum To store a helmet in the storage com- EAUM2490 Windshield load of 185 kg (408 lb) for the ve- partment, place the helmet with the To suit the rider’s preference, the wind- hicle.

  • Page 30: Adjusting The Shock Absorber Assemblies

    INSTRUMENT AND CONTROL FUNCTIONS EWA10920 EAU14881 EWA10210 Adjusting the shock absorber WARNING WARNING assemblies After adjusting the windshield: Always adjust both shock absorber Securely tighten the windshield assemblies equally, otherwise poor bolts. handling and loss of stability may Turn the handlebar to the left result.

  • Page 31: Carrier

    INSTRUMENT AND CONTROL FUNCTIONS EAU15112 EAUT1072 EAU15301 Carrier Luggage hook Sidestand EWA10171 EWAT1031 WARNING WARNING Do not exceed the load limit of 5 Do not exceed the load limit of 3 kg (11 lb) for the carrier. kg (7 lb) for the luggage hook. Do not exceed the maximum Do not exceed the maximum load of 185 kg (408 lb) for the ve-...

  • Page 32: Ignition Circuit Cut-Off System

    It prevents starting when either this system regularly as described brake is applied, but the sidestand below and have a Yamaha dealer re- is still down. pair it if it does not function proper- It cuts the running engine when the sidestand is moved down.
  • Page 33 WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is turned on. dealer check the system before riding. 3. Turn the key on.

  • Page 34: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-12 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 35 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-14, 6-20 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Check for damage. • Check tire condition and tread depth.

  • Page 36: Operation And Important Riding Points

    See page 5-4 for engine break-in in- gle sensor to stop the engine in case of understand, ask your Yamaha dealer. structions prior to operating the ve- a turnover. To start the engine after a EWA10271 hicle for the first time.

  • Page 37: Starting Off

    OPERATION AND IMPORTANT RIDING POINTS 3. Start the engine by pushing the EAU16761 EAU16780 Starting off Acceleration and deceleration start switch while applying the front or rear brake. NOTICE: For maxi- mum engine life, never acceler- Before starting off, allow the engine to ate hard when the engine is warm up.

  • Page 38: Braking

    OPERATION AND IMPORTANT RIDING POINTS EAU16793 EAU16820 Braking Tips for reducing fuel con- EWA10300 sumption WARNING Fuel consumption depends largely on Avoid braking hard or suddenly your riding style. Consider the following (especially when leaning over to tips to reduce fuel consumption: one side), otherwise the scooter Avoid high engine speeds during may skid or overturn.

  • Page 39: Engine Break-In

    Since the engine is brand new, do not Since the engine and exhaust immediately have a Yamaha dealer put an excessive load on it for the first system can become very hot, check the vehicle.

  • Page 40: Periodic Maintenance And Adjustment

    If you do not have the tools or experi- weather, terrain, geographical location, formation about carbon monox- ence required for a particular job, have and individual use, the maintenance in- ide. a Yamaha dealer perform it for you. tervals may need to be shortened. EWA10330 EWA10321 WARNING WARNING...

  • Page 41: Periodic Maintenance And Lubrication Chart

    From 30000 km (17500 mi), repeat the maintenance intervals starting from 6000 km (3500 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 42 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 6000 km 12000 km 18000 km 24000 km CHECK (600 mi) (3500 mi) (7000 mi) (10500 mi) (14000 mi) √ √ √ √ √ • Check for cracks or damage. 8 * Brake hoses •...
  • Page 43 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 6000 km 12000 km 18000 km 24000 km CHECK (600 mi) (3500 mi) (7000 mi) (10500 mi) (14000 mi) When the oil change indicator light comes on [5000 km (3000 mi) √...
  • Page 44 PERIODIC MAINTENANCE AND ADJUSTMENT EAU18670 The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.

  • Page 45: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18712 Removing and installing cowl- ings and panels The cowlings and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a cowling or panel needs to be re- moved and installed.

  • Page 46: Checking The Spark Plug

    Do not attempt to diagnose Place the panel in the original position, such problems yourself. Instead, have and then install the screws. a Yamaha dealer check the vehicle. If the spark plug shows signs of elec- trode erosion and excessive carbon or ZAUM0656 other deposits, it should be replaced.

  • Page 47: Engine Oil

    PERIODIC MAINTENANCE AND ADJUSTMENT Before installing a spark plug, the spark EAUM2271 Engine oil plug gap should be measured with a If a torque wrench is not available when The engine oil level should be checked wire thickness gauge and, if necessary, installing a spark plug, a good estimate before each ride.
  • Page 48 PERIODIC MAINTENANCE AND ADJUSTMENT 3. Remove the engine oil filler cap and the engine oil drain bolt to Skip steps 5–9 if the oil filter element is drain the oil from the crankcase. not being replaced. 5. Remove the oil filter element cover by removing the bolts.
  • Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT 10. Install the washer and the engine ECA11670 NOTICE oil drain bolt, and then tighten the drain bolt to the specified torque. Do not use oils with a diesel specification of “CD” or oils of a Tightening torque: higher quality than specified.

  • Page 50: Final Transmission Oil

    WARNING! Make ride. If any leakage is found, have a sure that no foreign material en- Yamaha dealer check and repair the ters the final transmission case. scooter. In addition, the final transmis- Make sure that no oil gets on the sion oil must be changed as follows at tire or wheel.

  • Page 51: Coolant

    If water has been before each ride. In addition, the cool- added to the coolant, have a ant must be changed at the intervals Yamaha dealer check the anti- specified in the periodic maintenance freeze content of the coolant as and lubrication chart.

  • Page 52: Air Filter And V-Belt Case Air Filter Elements

    5. Install the air filter case cover by in- nance and lubrication chart. Have a placed and the V-belt case air filter ele- stalling the screws. Yamaha dealer change the coolant. ment should be cleaned at the intervals WARNING! Never attempt to remove specified in the periodic maintenance...

  • Page 53: Checking The Throttle Cable Free Play

    3.0–5.0 mm (0.12–0.20 in) at the throttle grip. Periodically check the throttle cable free play and, if neces- sary, have a Yamaha dealer adjust it. ZAUM0706 1. V-belt case air filter element 3. Check the air filter element for damage and replace it if neces- sary.

  • Page 54: Valve Clearance

    The tire air pressure must be ad- must be adjusted by a Yamaha dealer justed in accordance with the at the intervals specified in the periodic Tire air pressure riding speed and with the total maintenance and lubrication chart.
  • Page 55 This model is equipped with tubeless edge and experience. tires. After extensive tests, only the tires list- ed below have been approved for this model by Yamaha Motor Co., Ltd. Front tire: Size: 120/70-16 M/C 57P Manufacturer/model: ZAUM0054 PIRELLI/SPORT DEMON FRONT 1.

  • Page 56: Cast Wheels

    The wheel rims should be checked Yamaha dealer bleed the system be- for cracks, bends or warpage be- fore operating the vehicle. Air in the fore each ride. If any damage is...

  • Page 57: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level peared, have a Yamaha dealer replace brake pads the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 58: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...

  • Page 59: Checking And Lubricating The Cables

    If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. WARNING! Damage to the outer sheath may interfere with proper ca- ZAUM0061...

  • Page 60: Checking And Lubricating The Centerstand And Sidestand

    If the centerstand or sidestand does Check the inner tubes for scratches, not move up and down smoothly, damage and excessive oil leakage. have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or To check the operation sidestand could contact the ground ZAUM0667 1.

  • Page 61: Checking The Steering

    2. Hold the lower ends of the front fork does not operate smoothly, fork legs and try to move them for- have a Yamaha dealer check or re- ward and backward. If any free pair it. play can be felt, have a Yamaha dealer check or repair the steering.

  • Page 62: Battery

    To charge the battery 2. If the battery will be stored for more Electrolyte is poisonous and Have a Yamaha dealer charge the bat- than two months, check it at least dangerous since it contains sul- tery as soon as possible if it seems to...

  • Page 63: Replacing The Fuses

    PERIODIC MAINTENANCE AND ADJUSTMENT 3. Fully charge the battery before in- EAU23526 Replacing the fuses 4 5 6 7 stallation. ECA16530 NOTICE Always keep the battery charged. 9 10 Storing a discharged battery can cause permanent battery damage. ZAUM0709 1. Fuse box ZAUM0708 2.

  • Page 64: Replacing A Headlight Bulb

    4. If the fuse immediately blows using a cloth moistened with al- again, have a Yamaha dealer cohol or thinner. check the electrical system. Headlight lens Do not affix any type of tinted film or stickers to the headlight lens.
  • Page 65 6. Connect the headlight coupler. 7. Install the headlight bulb cover. 8. Install the cowling. 9. Have a Yamaha dealer adjust the headlight beam if necessary. ZAUM0677 1. Headlight bulb cover 3. Disconnect the headlight coupler.

  • Page 66: Replacing A Front Turn Signal Light Bulb

    6. Install the socket (together with the NOTICE bulb) by turning it clockwise. 1. Place the vehicle on the center- It is advisable to have a Yamaha 7. Install the cowling. stand. dealer perform this job. 2. Remove panel B. (See page 6-6.) 3.

  • Page 67: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAUM2201 EAUM2212 Replacing the license plate Replacing an auxiliary light light bulb bulb 1. Remove the socket (together with This model is equipped with two auxil- the bulb) by pulling it out. iary lights. If an auxiliary light bulb burns out, replace it as follows.

  • Page 68: Troubleshooting

    However, should your scooter re- quire any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the scooter prop- erly.

  • Page 69: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 70 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 71: Scooter Care And Storage

    SCOOTER CARE AND STORAGE EAU26093 ucts onto seals, gaskets and wheel off any detergent residue using Care axles. Always rinse the dirt and de- plenty of water, as it is harmful While the open design of a scooter re- greaser off with water. to plastic parts.
  • Page 72 SCOOTER CARE AND STORAGE Test the product on a small hid- 3. To prevent corrosion, it is recom- den part of the windshield to mended to apply a corrosion pro- Salt sprayed on roads in the winter may make sure that it does not leave tection spray metal,...

  • Page 73: Storage

    Turn the engine over several To prevent corrosion, avoid Consult a Yamaha dealer for ad- times with the starter. (This will damp cellars, stables (because vice on what products to use.
  • Page 74 SCOOTER CARE AND STORAGE 5. Check and, if necessary, correct the tire air pressure, and then lift the scooter so that both of its wheels are off the ground. Alterna- tively, turn the wheels a little every month in order to prevent the tires from becoming degraded in one spot.

  • Page 75: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Air filter: Overall length: Type: Air filter element: 2175 mm (85.6 in) SAE 10W-30, SAE 10W-40, SAE 15W-40, Oil-coated paper element Overall width: SAE 20W-40 or SAE 20W-50 Fuel: 785 mm (30.9 in) Recommended fuel: Overall height: Regular unleaded gasoline only -20 -10 10 20 30 40 50 ˚C...
  • Page 76 SPECIFICATIONS Transmission type: Front: Front suspension: V-belt automatic 170 kPa (1.70 kgf/cm², 25 psi) Type: Operation: Rear: Telescopic fork Centrifugal automatic type 190 kPa (1.90 kgf/cm², 28 psi) Spring/shock absorber type: Chassis: Loading condition: Coil spring/oil damper 90–185 kg (198–408 lb) Frame type: Wheel travel: Front:...
  • Page 77 SPECIFICATIONS Front turn signal light: Backup fuse: 12 V, 10.0 W × 2 5.0 A Rear turn signal light: 12 V, 10.0 W × 2 Auxiliary light: 12 V, 5.0 W × 2 License plate light: 12 V, 5.0 W × 1 Meter lighting: High beam indicator light: Turn signal indicator light:...

  • Page 78: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: ZAUM0683 1.
  • Page 79 1. Model label The model label is affixed to the bottom of the seat. (See page 3-12.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 80 INDEX Front and rear brake pads, checking..6-18 Seat............3-12 Front fork, checking ......6-21 Shock absorber assemblies, Acceleration and deceleration....5-2 Fuel............3-10 adjusting ..........3-15 Air filter and V-belt case air filter Fuel consumption, tips for reducing..5-3 Sidestand ..........3-16 elements ..........
  • Page 82 YAMAHA MOTOR CO., LTD. PRINTED IN FRANCE 2008.07 (E)
