Intruder alarm system
Service mode
System setup
1
System setup
3 Zones
Advance to the next unlearned zone with keypad
Z01 Door
keys [Ü] or [7].
1 Name Door
Enable the wireless zone by changing Not used
Z01 Door
loop type to any other loop type. If the system uses a
3 Loop type NO/DEOL
keypad produced before 2014, an installer is
obligated to change the loop type to NO/DEOL or
Vibration.
Enter the zone address in MA_Z format, where MA
Z01 Door
is a module address in the system and Z is a zone
Address 06_1
3
number in the module.
Note: for wireless zones MA_1 – MA_8 the system
will automatically assign NO/DEOL loop type and
for wireless zones MA_9 – MA_16 the Vibration
loop type. Don't change the loop type of a zone!
Module address:
EXT116S - address 06 (default) or given during
the registration process;
Virtual module EXT116S address depends on the
control panel's type:
P16 - address 12;
P32 - address 12 and 13;
P64 - address 12, 13, 14 and 15.
Enter wireless detector's loop (zone) ID number
Z01 Door
and press the [ENT] key to start enrolling. This field
4 WL det. loop (zone) ID 201
may also be used for deleting the sensor from the
module.
When enrolment has started, immediately press the
Waiting for
detector's battery for a short period of time (~1 sec)
as shown in the picture. You will feel a light click after
WL detector
pressing the battery. The tamper switch is now
activated and the detector will transmit a tamper
message.
Wireless detector successfully enrolled. No
Done
additional transmissions are needed for
confirmation.
Kodinis Raktas UAB, manufacturer of SECOLINK Intruder Alarm System, offers a Warranty for a term of twenty-four months. It declares, that
product BK1 complies with essential EU directives and EU standards EN 50131-1, Grade 1, Environmental Class II;
EN 50131-2-6. For more information visit manufacturer's website www.kodinis.lt or www.secolink.eu for a complete text of declaration.
SECOLINK Intruder Alarm System is designed and manufactured in Lithuania.
Please act according to your local rules and do not dispose of your unusable alarm system or its components with other household waste. This
product utilization in EU is covered by European Directive 2002/96/EC.
Page 2
BK1, BK2, BK3, BV3, BK4 and BT1 Wireless detectors

ENROLLING

Use
Built-in reed switch
(used in conjunction
with a magnet)
Temperature
sensor
Normally closed
circuit contact loop
wired to ...
Roller detector
loop wired to ...
Vibration detector
loop wired to ...
Delete the detector
in a particular zone
Delete all
detectors in a
specific wireless
module
** wireless detector loop (zone) ID number for input 3 is not used.

SYSTEM COMPLIANCE AND WARRANTY

Wireless detector loop (zone) enrolling ID numbers
Supports Wireless detector loop (zone) ID number
BK1
BK4
BT1
BK2** ... input 1
BK3
210
BV3
Zone response (speed) time of 0,4 sec.
BK4
... input 1
211
212
BK2**
213
BK3
215
BK4
217
219
211 - last digit of identification code defines the
number of Roller pulses.
... input 1
111
112
...
BV3
118
119
111 - last digit of identification code number x 10
defines the zone response (speed) time (example: 1 x
10 = 10 msec).
All
All
Installation manual
201
200
... input 2 ... input 3
220 230
... input 2 ... input 3
221 231
222 232
223 233
225 235
227 237
229 239
... input 2 ... input 3
121 131
122 132
... ...
128 138
129 139
255
254
Rev.30/11/16_KF
