Hifonics HS35CX Quick Start Installation Manual

Component installation

Factory location
A
behind door panel
Vehicles that have premium
sound systems will often
have separate tweeters in
a dash or door location.
Try to use this location for
mounting the component
tweeter if possible.
Custom location
B
If there is not a suitable
factory location for woofer
or tweeter to be mounted,
custom mounting may be
necessary. Before making
any permanent changes to
your vehicle make sure there
is adequate mounting depth.
Tweeter mounting
C
There are three primary
ways the tweeter can be
mounted. Surface, Flush
and Custom mounting. The
flush mount configuration is
shown here.
Crossover wiring
D
The crossover is necessary
for the proper operation of the
component speaker system.
IN WF TW
Make sure the wires are securely
attached and that there are no
stray strands of wire contacting
other terminals. Mount the
crossover to a secure surface
Tweeter
that is free of interference
Amplificador Amplifier
Woofer
from window mechanisms and
excessive moisture.
