Component installation
Factory location
A
behind door panel
Vehicles that have premium
sound systems will often
have separate tweeters in
a dash or door location.
Try to use this location for
mounting the component
tweeter if possible.
Custom location
B
If there is not a suitable
factory location for woofer
or tweeter to be mounted,
custom mounting may be
necessary. Before making
any permanent changes to
your vehicle make sure there
is adequate mounting depth.
Tweeter mounting
C
There are two primary
ways the tweeter can be
mounted. Surface and Flush
mounting. The flush mount
configuration is shown here.
Crossover wiring
D
The crossover is necessary for the proper operation of
the component speaker system. Secure the crossover
to a surface that is free of interference from window
mechanisms and excessive moisture.
Quick Start
Installation Guide
ZS35CX - ZS4CX
ZS46CX - ZS525CX
ZS5768CX - ZS65CXS
ZS65C - ZS653
ZS693
