4.1 MOUNTING ONTO STANDARD RAIL

1. Clip the device (a) vertically onto the horizontal DIN rail (b) .
2. Swing the device downward until the unlocking slider on the DIN rail clicks into place .
.
1.
(a)
(b)
Figure: Mounting onto standard rail
2.
9
