DESCRIPTION
INPUT CURRENT RESISTANCE INFORMATION
The Input Current (IC) resistance restricts the current maximum advertised by the EPC . The IC values are as described below:
MAX
no resistor (open, no resistor, IC not connected)
80A
9090 Ω resistor
79A
8060 Ω resistor
78A
7320 Ω resistor
77A
6650 Ω resistor
76A
6190 Ω resistor
75A
5620 Ω resistor
74A
5230 Ω resistor
73A
4870 Ω resistor
72A
4530 Ω resistor
71A
4220 Ω resistor
70A
4020 Ω resistor
69A
3740 Ω resistor
68A
3570 Ω resistor
67A
3320 Ω resistor
66A
3160 Ω resistor
65A
3010 Ω resistor
64A
2870 Ω resistor
63A
2670 Ω resistor
62A
2550 Ω resistor
61A
2430 Ω resistor
60A
2320 Ω resistor
Input resistance less than 100-Ω, MIN, will cause the EPC to reduce the advertised current capacity to 7A for five seconds after which
charging and the interlock will be disabled and the EPC will enter into a forced Status A until input current resistance is increased .
3.4 LED DISPLAY & TROUBLESHOOTING
LED DISPLAY
The EPC has a 3-color LED for displaying operating states and fault conditions . The LED can be lit in blue, green, or red . The meaning of
the individual displays is shown in the following tables:
OPERATING STATES:
LED
DESCRIPTION OF OPERATING STATE
COLOR
STATUS
NOT LIT
NOT LIT
BLUE
FLASHING (1 HZ)
BLUE
STEADY
GREEN
STEADY
RED
STEADY
RED
FLASHING (1 HZ)
8
59A
2210 Ω resistor
58A
2100 Ω resistor
57A
2050 Ω resistor
56A
1960 Ω resistor
55A
1870 Ω resistor
54A
1780 Ω resistor
53A
1690 Ω resistor
52A
1620 Ω resistor
51A
1580 Ω resistor
50A
1500 Ω resistor
49A
1430 Ω resistor
48A
1370 Ω resistor
47A
1330 Ω resistor
46A
1270 Ω resistor
45A
1210 Ω resistor
44A
1180 Ω resistor
43A
1130 Ω resistor
42A
1070 Ω resistor
41A
1050 Ω resistor
40A
1000 Ω resistor
Device is not active, switched off
• No power supply
• Device defective
Device is waiting to be connected to an electric vehicle (Status A)
Electric vehicle connected, electric vehicle not ready for charging (Status B)
Charging process active (Status C)
Electric vehicle requires ventilation, charging deactivated (Status D)
Communication fault detected, charging deactivated (Status F)
MIN
no resistor (no resistor, IC connected to ground)
39A
959 Ω resistor
38A
931 Ω resistor
37A
887 Ω resistor
36A
845 Ω resistor
35A
825 Ω resistor
34A
787 Ω resistor
33A
750 Ω resistor
32A
732 Ω resistor
31A
698 Ω resistor
30A
665 Ω resistor
29A
634 Ω resistor
28A
619 Ω resistor
27A
590 Ω resistor
26A
562 Ω resistor
25A
536 Ω resistor
24A
511 Ω resistor
23A
491 Ω resistor
22A
475 Ω resistor
21A
453 Ω resistor
20A
432 Ω resistor
19A
412 Ω resistor
18A
392 Ω resistor
17A
374 Ω resistor
16A
348 Ω resistor
15A
332 Ω resistor
14A
316 Ω resistor
13A
301 Ω resistor
12A
280 Ω resistor
11A
267 Ω resistor
10A
249 Ω resistor
9A
237 Ω resistor
8A
221 Ω resistor
7A
205 Ω resistor
6A
191 Ω resistor
