CONNECTION

5.2 230 V AC POWER SUPPLY

WIRING EXAMPLE 230 V AC
Hatch
Lock
Solenoid
(Control Pilot)
(N)
(L3)
WARNING: THE EXTERNAL CONTACT BLOCKS USED MUST BE FLOATING AND
SAFELY SEPARATED FROM UNSAFE CIRCUITS.
Failure to observe this can result in injury to persons or property damage .
L
N
ML MU HF
PP NC NC
Mainpine
(Proximity)
P3 P4 P5
P6 NC NC
(L1)
(L2)
16A
RCBO
N L
P2 P1 NC
A1 L1 L2 A2
16A
Contacter
L1 L2
RD GN BL
IC CP 0V
Input Current Resistor
32A 63A
RCBO RCBO
A1 L1 L2 A2 A1 L1 L2 A2
32A 63A
Contacter Contacter
L1 L2 L1 L2
13
