Installation Manual
Mission Series
R410a Models
Indoor Unit Model
MSMBAU-09HRDN1-QRD0GW(B)
MSMBBU-12HRDN1-QRD0GW(B)
MSMBCU-18HRDN1-QRD0GW(B)
MSMBDU-24HRDN1-QRD0GW(B) MOCA01-24HFN1-QRD0GW
R32 Models
Indoor Unit Model
MSMBBU-09HRDN8-QRD06W
MSMBBU-12HRDN8-QRD6GW
MSMBCU-18HRDN8-QRD6GW
MSMBDU-24HRDN8-QRD6GW
Outdoor Unit Model
MOBA02-09HFN1-QRD0GW
MOB03-12HFN1-QRD0GW
MOB02-18HFN1-QRD0GW
Outdoor Unit Model
MOB01-09HFN8-QRD6GW
MOB01-12HFN8-QRD6GW
MOB02-18HFN8-QRD6GW
MOCA01-24HFN8-QRD6GW
Advertisement
Table of Contents
Related Manuals for Midea MSMBAU-09HRDN1-QRD0GW(B)
Summary of Contents for Midea MSMBAU-09HRDN1-QRD0GW(B)
-
Page 1: Installation Manual
Installation Manual Mission Series R410a Models Indoor Unit Model Outdoor Unit Model MSMBAU-09HRDN1-QRD0GW(B) MOBA02-09HFN1-QRD0GW MSMBBU-12HRDN1-QRD0GW(B) MOB03-12HFN1-QRD0GW MSMBCU-18HRDN1-QRD0GW(B) MOB02-18HFN1-QRD0GW MSMBDU-24HRDN1-QRD0GW(B) MOCA01-24HFN1-QRD0GW R32 Models Indoor Unit Model Outdoor Unit Model MSMBBU-09HRDN8-QRD06W MOB01-09HFN8-QRD6GW MSMBBU-12HRDN8-QRD6GW MOB01-12HFN8-QRD6GW MSMBCU-18HRDN8-QRD6GW MOB02-18HFN8-QRD6GW MSMBDU-24HRDN8-QRD6GW MOCA01-24HFN8-QRD6GW... -
Page 2: Table Of Contents
Table of Contents Installation Manual Installation Manual Accessories ..........Safety Precautions ......Installation Overview ....... Indoor Unit Installation ......a. Indoor Unit Parts ..........b. Indoor Unit Installation Instructions ....Outdoor Unit Installation ......a. Outdoor Unit Installation Instructions ....b. - Page 3 Installation Manual Installation Manual Refrigerant Piping Connection ....A. Notes on Pipe Length and Elevation ....17 ..B. Refrigerant Piping Connection Instructions..18 Wiring ..........a. Outdoor Unit Wiring ......20 b. Indoor Unit Wiring ......21 c. Power Specifications ......22 d. Wiring Diagram........23 Caution: Risk of fire (for R32 Pressure test and evacuation...
-
Page 4: Accessories
Accessories The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and fire, or cause the equipment to fail. ... -
Page 5: Safety Precautions
Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. Failure to observe a warning may result in death. The appliance must be installed in accordance with national regulations. -
Page 6: Installation Overview
Installation Overview INSTALLATION ORDER Page 6... -
Page 7: Indoor Unit Installation
Indoor Unit Installation Safety Precautions CAUTION WARNING • Install the indoor and outdoor units, cables and • Securely install the indoor unit on a structure that wires at least 1m from televisions or radios can sustain its weight. If the structure is too weak to prevent static or image distortion. - Page 8 Indoor Unit Installation Page 8...
- Page 9 Indoor Unit Installation For MSMBAU-09HRFN1-QRD0GW: For MSMBBU-12HRFN1-QRD0GW: For MSMBCU-18HRFN1-QRD0GW: For MSMBDU-24HRFN1-QRD0GW: Page 9...
- Page 10 Indoor Unit Installation Page 10...
-
Page 11: Outdoor Unit Installation
Outdoor Unit Installation Outdoor Unit Installation Instructions Step 1: Select installation location. If the location is exposed to strong winds the unit must be placed against the wall to shelter it from The outdoor unit should be installed in the location that the wind. - Page 12 Outdoor Unit Installation Instructions For MOB01-09HFN1-QRD0GW, MOB01-12HFN1-QRD0GW, MOB01-18HFN1-QRD0GW, NOTE Since the gravity center of the unit is not at its physical center, so please be careful when lifting it with a sling. Never hold the inlet of the outdoor unit to prevent it from deforming. Do not touch the fan with hands or other objects.
- Page 13 Outdoor Unit Installation Instructions For MOB02-18HFN1-QRD0GW 815 W3 5 1 4 333 D 8 0 0 70 W2 62 B1 D2 D3 20 A1 61.6 A2 Page...
- Page 14 Outdoor Unit Installation Instructions For MOCA02-24HFN1-QRD0GW, 845mm 700mm 560mm 320mm 845mm 908mm 320mm 335mm Page...
-
Page 15: Notes On Drilling Hole In Wall
NOTE: The minimum distance between the outdoor Notes On Drilling Hole In Wall unit and walls described in the installation guide does not apply to airtight rooms. Be sure to keep the unit unobstructed in at least two of the three directions (M, N, P) (See Fig. -
Page 16: Drainpipe Installation
Drainpipe Installation 16 Page... -
Page 17: Refrigerant Piping Connection
Refrigerant Piping Connection Refrigerant Piping Connection Instructions WARNING • All field piping must be completed by a licensed technician and must comply with the local and national regulations. • When the air conditioner is installed in a small Step1: Cut pipes room, measures must be taken to prevent the When preparing refrigerant pipes, take extra care refrigerant concentration in the room from... - Page 18 Refrigerant Piping Connection CAUTION Step 3: Flare pipe ends gas- tight seal Proper flaring is essential to achieve an DO NOT deform pipe while cutting. Be extra careful not to damage, dent, or deform the pipe while cutting. This After removing burrs from cut pipe, seal the ends will drastically reduce the heating efficiency of the unit.
- Page 19 Place flaring tool onto the form. Step 4: Connect pipes Turn the handle of the flaring tool clockwise until Connect the copper pipes to the indoor unit first, then the pipe is fully flared. Flare the pipe in accordance connect it to the outdoor unit. You should first connect the with the dimensions shown in table 7-3.
-
Page 20: Wiring
Wiring Follow these instructions to prevent distortion when the Safety Precautions compressor starts: • The unit must be connected to the main outlet. Normally, the power supply must have a low output WARNING impedance of 32 ohms. • Be sure to disconnect the power supply before •... -
Page 21: Indoor Unit Wiring
b. Using wire strippers, strip the rubber jacket from both ends of signal cable to reveal about 15cm Terminal block of the wires inside. Wire cover c. Strip the insulation from the ends of the wires. d. Using a wire crimper, crimp u-lugs on the ends of the wires. -
Page 22: Power Specifications
Power Specifications Indoor Power Supply Specifications MODEL PHASE 1 Phase 1 Phase 1 Phase 1 Phase POWER FREQUENCY 220-240V 220-240V 220-240V 220-240V AND VOLT CIRCUIT BREAKER/ POWER FROM OUTDOOR UNIT FUSE(A) Outdoor Inverter Power Supply Specifications MODEL PHASE 1 Phase 1 Phase 1 Phase 1 Phase... -
Page 23: Wiring Diagram
Wiring Diagrams Indoor Unit NOTE: If used as MONO unit, for the standby control needs, the cross section area of cable connected to W, 1(L) must be sufficient for the maximum system current. The maximum system current is equal to the sum of indoor unit and outdoor unit rated current. -
Page 24: Pressure Test And Evacuation
Pressure Test Instructions Systems are pressure tested to ensure they are: Safe – for this test a pressure above the system’s maximum allowable pressure (PS i ) is used Leak tight – this test is at PS i . Pressure testing is hazardous and should be carried out carefully: The nitrogen used for pressure testing is an asphyxiant, so the area around the system should be well-ventilated High pressures are used, so all non-essential personal should be evacuated... - Page 25 Air Evacuation 4. Turn on the vacuum pump to evacuate the system. Safety Precautions 5. Run the vacuum for at least 15 minutes, or until the Gauge reads -76cmHG (-1x105Pa). 6. Close the Low Pressure side of the manifold gauge, and CAUTION turn off the vacuum pump.
-
Page 26: Refrigerant Additional Charge
Refrigerant Additional Charge CAUTION • Refrigerant charging must be performed after wiring, vacuuming and the leak test. • DO NOT exceed the maximum allowable quantity of refrigerant or overcharge the system. Doing so can damage or impact the unit’ s function. •... -
Page 27: Test Run
Test Run Check to see that the drainage system is Before Test Run unimpeded and draining smoothly. g. Ensure there is no vibration or abnormal noise A test run must be performed after the entire system has during operation. been completely installed. Confirm the following points 5. -
Page 28: Service Info
Servicing Info (Required for the units adopt R32 Refrigerant only) 1. Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system. - Page 29 the charge size is in accordance with the room size within which the refrigerant containing parts are installed; the ventilation machinery and outlets are operating adequately and are not obstructed; if an indirect refrigerating circuit is being used, the secondary circuits shall be checked for the presence of refrigerant;...
- Page 30 11. Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinscially safe components are the only types that can be worked on while live in the presence of a flammable atmosphere.
- Page 31 When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place. This operation is absolutely vital if brazing operations on the pipe-work are to take place. Ensure that the outlet for the vacuum pump is not closed to any ignition sources and there is ventilation available.
- Page 32 18. Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and signed. Ensure that there are labels on the equipment stating the equipment contains flammable refrigerant. 19. Recovery When removing refrigerant from a system, either for service or decommissioning, it is recommended good practice that all refrigerants are removed safely.
-
Page 33: Quick Step Installation Guide
Step 13: Complete your warranty card document and e-mail this with dated photo of outdoor serial number to: warranty@fgeuropeuk.co.uk Note: Installation videos can also be found on the Midea UK YouTube channel. Please contact your Midea support team if you have any issues during the installation and commissioning process. Tel: 02074 092009 E-Mail: technical@fgeuropeuk.co.uk... -
Page 34: Display Board, Fault Codes
Display Board & Fault Codes 8.1 Indoor Unit Error Display Operation Timer lamp Display LED STATUS lamp 1 time Indoor unit EEPROM parameter error 2 times Indoor / outdoor units communication error 4 times Indoor fan speed has been out of control Indoor room temperature sensor T1 open circuit or short 5 times circuit... -
Page 35: 4 Service Documents
Service Documents Mi Indoor Maintenance Checklist 17 Old Park Lane, London, W1K 1QT Tel: + 44 (0) 2074 092009 Customer Contact Information Company Name: Contact Name: Contact Number: E-Mail Address: Site Reference Date of Visit: Indoor Details Location Served Model No. Serial No. - Page 36 Mi Outdoor Maintenance Checklist 17 Old Park Lane, London, W1K 1QT Tel: + 44 (0) 2074 092009 Customer Contact Information Company Name: Contact Name: Contact Number: E-Mail Address: Site Reference Date of Visit: Outdoor Details Location Served Model No. Serial No. 3 ☐...
- Page 37 Mi Commissioning & Installation Checklist 17 Old Park Lane, London, W1K 1QT Tel: + 44 (0) 2074 092009 Customer Contact Information Company Name: Contact Name: Contact Number: E-Mail Address: Site Reference Date of Visit: Site Address County/Region: Postcode: System Details Indoor Model No.
- Page 38 WARRANTY CLAIM REQUEST FORM 17 Old Park Lane, London, W1K 1QT Tel: + 44 (0) 2074 092009 Once this from is completed please return to: warranty@fgeuropeuk.co.uk Customer Contact Information Company Name: Contact Name: Contact Number: E-Mail Address: Site Reference: Date: Parts to Be Claimed Model No.
- Page 39 17 Old Park Lane, London, W1K 1QT Tel: + 44 (0) 2074 092009...
