Omega DP41-B Operation Manual

4

Output Specifications:

Relay Output: Form -C, SPDT Relays
Power Rating for
Resistive Loads: Two relays at P6 and P7
250 Vac or 30 Vdc @ 5 A
Two relays at P18
250 Vac or 30 Vdc @ 3 A
Isolation: Power to Input/Relay Outputs:
2500 Vac per 1 min. test
Relays to Inputs / Analog,
Comm, & Ethernet Outputs:
2500 Vac per 1 min. test
It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations
that apply. OMEGA is constantly pursuing certification of its products to the European
New Approach Directives. OMEGA will add the CE mark to every appropriate device
upon certification.
This device is marked with the international hazard symbol. It is important to
read the Setup Guide before installing or commissioning this device as it con-
tains important information relating to safety and EMC.
WARNING: These products are not designed for use in, and should not be used
for, patient connected applications.
The information contained in this document is believed to be correct but OMEGA
Engineering, Inc. accepts no liability for any errors it contains, and reserves the right to
alter specifications without notice.
