4 Quick Start Guide

4.1 Instrument operation

For examples of Transformer connections; See next page
1. Power on the instrument
3. Press start button
5. Press stop button
Instruction Manual Winding Resistance Meter
Type WR50, WR14, Version 2.01
2. Select the Test Current:
press Range or Setup / Range
4. Get the results
WARNING!
Wait until the green light shows
"Safe" before disconnecting the
cables
