Galaxy Audio HS4 Quick Start Manual

GAL A X Y AUDIO
Included Components
1.
HS4 x1
2.
SA-1 Stand Adapter x1
3. Quick Start Guide x1
Setup
1
Connect one end of a 1/4" cable to
either 1/4" input, and the other end to
your powered amplifier.
Stand Mounting
(Optional)
1
Attach the SA-1 to the mic stand
1.
5.33 Ohms for 3 Hot Spots
8 Ohms for 2 Hot Spots
2
To Daisy Chain:
Connect one end of a 1/4" cable to either 1/4" input, and the other end to either 1/4" input on the other HS4. Repeat for any other HS4's being Daisy Chained.
2
Lift the HS4 over the stand, align it up
with the hole.
2. 3.
GAL A X Y AUDIO
Included Components
1. HS4 x1 1. 2. 3.
2. SA-1 Stand Adapter x1
3. Quick Start Guide x1
4 Ohms for 4 Hot Spots
(The Total Load)
5.33 Ohms for 3 Hot Spots
Setup 8 Ohms for 2 Hot Spots
1 2
Connect one end of a 1/4" cable to
either 1/4" input, and the other end to
your powered amplifier.
To Daisy Chain:
Connect one end of a 1/4" cable to either 1/4" input, and the other end to either 1/4" input on the other HS4. Repeat for any other HS4's being Daisy Chained.
Stand Mounting (Optional)
1 2 3
Attach the SA-1 to the mic stand Lift the HS4 over the stand, align it up Bring the HS4 down onto the stand
with the hole. gently until secure.
4 Ohms for 4 Hot Spots
(The Total Load)
3
Bring the HS4 down onto the stand
gently until secure.
Q uick Start Guide
For more details on
Ohm's Law, Scan Here:
Quick Start Guide
For more details on
Ohm's Law, Scan Here:
