NOTES:
Navigate through sub-menu items by pushing buttons (1) and (2), except where otherwise indicated.
After a menu item is selected, push button (3) to activate the selected function. The function will
either be activated or will show <> symbols.
When <> symbols are shown on the menu, the left and the right actions are required. Use button (1)
to increase (>) the value, and button (2) to decrease (<) the value. To enter the value and disable left
and right navigation, press button (3).
Select EXIT and push button (3) to return to the MAIN MENU.
PALETTE MENU
The PALETTE menu (Figure 3-6 and Figure 3-7) allows you to select from a range of temperature imaging
modes: White Hot, Black Hot, Fusion, Rainbow, Globow, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2,
Ice-Fire, Rain, and OEM Custom.
NOTE:
To navigate through the items on the two-page PALETTE menu, hold down button (1) or button (2).
The palettes act as color templates for visualization of temperature changes.
To navigate through the items on the PALETTE menu, press buttons (1) or (2).
PROMETHEUS C
ARMASIGHT by FLIR
PALETTE
> EXIT
WHITE HOT
BLACK HOT
FUSION
RAINBOW
GLOBOW
IRONBOW 1
IRONBOW 2
FIGURE 3-6. PALETTE MENU
PALETTE
> EXIT
SEPIA
COLOR 1
COLOR 2
ICE-FIRE
RAIN
OEM CUSTOM
FIGURE 3-7. PALETTE MENU. CONTINUED
