SECTION 3
OPERATING INSTRUCTIONS

3.1 INSTALLATION AND CONNECTING

3.1.1 BATTERY INSTALLATION
CAUTION:
Verify that the equipment is OFF before installing the batteries.
To install two CR123A batteries (refer to Figure 3-1):
1. Unscrew the battery cap (A).
2. Insert the batteries (B) into the battery compartment. Align the polarity symbols on the batteries
with the polarity symbols on the unit body (C).
3. Replace the battery cap.
3.1.2 CONNECTING AN ADDITIONAL EQUIPMENT
CAUTION:
Turn off the Prometheus C before you begin connecting/ disconnecting any external equipment and
before removing the batteries.
16
C
FIGURE 3-1. BATTERY INSTALLATION
PROMETHEUS C
ARMASIGHT by FLIR
B
A
