Armasight Prometheus C 336 2-8x25 User Manual page 12

ITEM
- ang. X (degrees)
Field of
View
- ang. Y (degrees)
Objective Focal Length
Objective F-number
Exit Pupil Diameter
Eye Relief
Focus Method
Focusing Range
Diopter Adjustment
Diopter Adjustment Range
ITEM
Battery
Current Consumption, maximum
Battery Life at 20°C (68 °F)
Extended Battery Pack (optional)
External Power Supply
ITEM
Overall Dimensions
Dimensions w/o Eyecup
Weight (w/o Batteries)
ITEM
Operating Temperature
Storage Temperature
Environmental Rating
12
TABLE 2-3. OPTICAL DATA
PROMETHEUS C 336 3-12×50
TABLE 2-4. ELECTRICAL DATA
Two CR123A 3V Lithium batteries or CR123 type rechargeable
batteries with voltage from 3.0V to 3.7V (2)
320 mA
Up to 4 hrs (up to 12 hrs with optional extended battery pack)
Two 18650 rechargeable batteries (3.7V), four CR123 rechargeable
batteries with voltage 3.7V max, or four standard CR123A 3V
Lithium batteries (operational time up to 8 hr)
6 VDC/ 600mA
TABLE 2-5. MECHANICAL DATA
TABLE 2-6. ENVIRONMENTAL DATA
-40 to +50°C (-40 to +122°F)
-50 to +70°C (-58 to +158°F)
Water and Fog-Resistant
PROMETHEUS C
ARMASIGHT by FLIR
PROMETHEUS C 640 2-16×50
13
10
25mm
1:1
5 mm
16 mm
Manual
0.25m to inf.
Manual
±5 diopter
DATA
DATA
192 × 90 × 57 mm (7.6 × 3.5 × 2.2 in)
142 × 90 × 52 mm (5.6 × 3.5 × 2.0 in)
0.4 kg (0.88 lbs)
DATA
25
20
U S E R M A N U A L
