- Page 1 User’s Manual SMD REWORK STATION ASE-4509 Thank you for choosing AKTAKOM soldering station. www.tmatlantic.com...
- Page 2 1. Product information 1.1 Specifications • Rated power input 300W • Rated voltage range AC 220-240V, 50Hz // 110V- 130V 60Hz • Hot Air Temperature 100-500°C • Display LED Segment Displays 1.2 Features • The integrated tool offers an excellent solution to desoldering work.
- Page 3 2. Operating Instructions 2.1 Before Operation • Select the appropriate FP Pick-up Wire that matches the size of the IC. The Fp Pick-up has an S wire (14mm) attached to it, an L wire (30mm) may also be needed, depending on the size of the IC. •...
- Page 4 3. This item has sleep function. When you put the air pump on the racket, the item will stop heating, And the display shows“SLP”( means SLEEP) , when you pick up the air pump , the Item will get back to the set temperature.
- Page 5 2.4 QFP Soldering • Apply the solder paste Apply the proper quantity of solder paste and install the SMD on the PWB. • Preheat SMD Refer to the photo to preheat SMD. (Fig. I) • Soldering Heat the lead frame evenly. (Fig. II) •...
- Page 6 3. Precautions • Attaching the Nozzle Do not press the Nozzle or pull on the edge of the Nozzle by pliers. Also, do not retighten the screw too tightly • Thermal Protector Power will automatically be off when the unit exceeds a certain temperature.
- Page 7 4. WARNING: • Warning: this tool must be placed on its stand when not in use. • Soldering tools not in use should be stored in a dry location which is out of the reach of children. • Return to professional for cord replacement or service.
- Page 8 Visit www.tmatlantic.com for more information www.tmatlantic.com...
