MAXSA 44150-SL Assembly & Operating Instructions

Motion-activated 150 led solar security light
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Model #: 44150-SL
ASSEMBLY & OPERATING INSTRUCTIONS
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE USE
ABOUT YOUR SOLAR SECURITY LIGHT
During the day, the solar panel included with this MAXSA Solar Security Light converts
sunlight into electricity, recharging the pre-installed battery. Using this stored energy,
the 150 LED lights turn on automatically at night when motion is detected, producing
787.5 lumens. This MAXSA Solar Security Light has an adjustable TIME dial that allows
light duration of up to 60 seconds. When the battery is fully charged, this Solar Security
Light can light up for up to 80 minutes, which is equivalent to 80 one-minute cycles when
the TIME dial is set to the maximum (+) position.
The unit includes a rechargeable 3.7V / 4.4Ah Lithium Ion battery pack and will need to
be replaced when the charging ability is decreased.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 44150-SL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAXSA 44150-SL

  • Page 1 IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE USE ABOUT YOUR SOLAR SECURITY LIGHT During the day, the solar panel included with this MAXSA Solar Security Light converts sunlight into electricity, recharging the pre-installed battery. Using this stored energy, the 150 LED lights turn on automatically at night when motion is detected, producing 787.5 lumens.
  • Page 2 Carefully remove and identify all the parts from their protective packaging and lay Carefully remove and identify all the parts from their protective packaging and lay them them out in front of you. out in front of you. INCLUDED PARTS: INCLUDED PARTS: Once you have identified all parts, connect the solar panel to your Solar Security Light by plugging the 15 foot cord into the cord attached to...
  • Page 3 CHOOSING A LOCATION FOR YOUR SOLAR SECURITY LIGHT This Solar Security Light comes complete with a solar panel attached to a 15 foot power cord. For optimum sun exposure and longer light output, place the solar panel in a position that receives at least 6-8 hours of direct sunlight per day. Placing the solar panel in a shaded location or even behind a window will not allow the battery to charge fully, reducing the number of hours the light will operate per evening.
  • Page 4 TOOLS REQUIRED FOR INSTALL If mounting on a wood or softer surface, you only need a Phillips-head screwdriver! If mounting on concrete, brick, or a harder surface, a drill should be used to create the mounting holes first BEFORE FIRST USE OF YOUR SOLAR SECURITY LIGHT Ensure the power switch on the main body of your Security Light is in the OFF position.
  • Page 5: Replacing The Battery Pack

    Carefully remove the battery pack and replace with a new 3.7V / 4.4Ah Lithium Ion battery pack obtained from MAXSA Innovations. The plug will only fit in one orientation. Do not force the plug into place as this may damage the unit. If it does not fit, rotate...
  • Page 6: Maintenance Tips

    Consult your local regulations for correct disposal of Lithium-Ion batteries. The battery pack may also be returned to MAXSA Innova-tions at 8412 Cathedral Forest Dr., Fairfax Station, VA 22039. Do not take apart the battery pack since they contain corrosive chemicals.
  • Page 7: Troubleshooting

    If the light still switches on, please contact MAXSA for further assistance. • Battery charge may be low. Turn the power switch to the OFF position and charge the battery for three (3) sunny days with...
  • Page 8: One-Year Limited Warranty

    Fairfax Station, VA 22039; USA within the warranty period, and if the product is defective, MAXSA Innovations, LLC will at its option repair or replace such. This warranty shall constitute the sole liability of MAXSA Innovations, LLC concerning the product. MAXSA...
  • Page 9 Modelo #: 44150-SL LUZ SOLAR DE SEGURIDAD ACTIVADO POR EL MOVIMIENTO INSTRUCCIONES GENERALES DE INSTALACIÓN Y FUNCIONAMIENTO PARA EL MODELO 44150-SL IMPORTANTE: LEA TODAS LAS INSTRUCCIONES CUIDADOSAMENTE ANTES DE USAR. ACERCA DE SU LUZ SOLAR DE SEGURIDAD Durante el día, el panel solar incluido en esta unidad de seguridad recarga la batería.
  • Page 10: Piezas Incluidas

    Retire con cuidado e identifique todas las piezas del envase protectiva y ponlas en frente de usted. PIEZAS INCLUIDAS: Para el ajustamiento de montaje El panel solar soporte de Tornillos y tacos montaje para montaje en panel solar Cable de Unidad de la alimentacíon batería principal...
  • Page 11 ELIGIENDO UN LUGAR PARA LA LUZ SOLAR DE SEGURIDAD Esta luz solar de seguridad viene con un panel solar conectado a un cable de 15 pies. Para una óptima exposición solar y una máxima iluminación de luz, coloque el panel solar en una posición que recibe por lo menos 6-8 horas de luz solar al día.
  • Page 12: Herramientas Necesarias Para La Instalación

    HERRAMIENTAS NECESARIAS PARA LA INSTALACIÓN Instalación sencilla con sólo un destornillador Phillips! Taladro eléctrico opcional. ANTES DE USAR LA UNIDAD DE SEGURIDAD PRIMERO Asegúrese de que el interruptor en el cuerpo principal de la luz de seguridad está en la posición OFF. En esta posición, el panel solar cargará la batería sin que se active la unidad.
  • Page 13 AJUSTE DEL SENSOR DE MOVIMIENTO (SENS) El sensor de movimiento en esta luz solar de seguridad es sensible a la temperatura. Si las temperaturas son mas frías, más sensible será el sensor de movimiento. Utilice el botón giratorio SENS para ajustar la sensibilidad del sensor de movimiento para compensar los cambios de temperatura del medio ambiente.
  • Page 14: Consejos De Mantenimiento

    Con cuidado, retire las pilas y buelva a colocar con nuevas pilas 4.4 p de 3,7 V / Ah Lithium Ion obtenida de MAXSA. El enchufe sólo encajará en una orientación. No force el conector en su lugar ya que esto puede dañar la unidad. Si no encaja, gira el tapón hasta que coincida con el extremo receptor de la placa de circuito.
  • Page 15 Si la luz todavía se enciende, póngase en contacto con MAXSA para obtener más ayuda. • Carga de la batería puede ser baja. Gire el interruptor a la La luz se posición OFF y cargue la batería durante tres (3) días de sol...
  • Page 16: Un Año De Garantía Limitada

    La obligación del fabricante, bajo esta garantía, se limita a reparar y sustituir piezas defectuosas cuando la unidad se devuelva a las Innovaciones MAXSA, la unidad se devuela a las Innovaciones MAXSA, 8412 Cathedra Forest Dr, Fairfax Sation, VA 22039, flete pre-pagado durante el período de garantía.
