Specifications; Installation Instructions - Altronix VertiLine33D Installation Manual

Altronix VertiLine Rack Mount Power Supplies provide sixteen (16) filtered and electronically regulated power outputs
in a space saving 1U EIA 19" rack mount chassis. The units are available with either 12VDC or 24VDC power outputs.
Vertiline Rack Mount Power Supplies are also available with eight (8) outputs.
Agency Listing:
• CE European Conformity.
Input:
• 115VAC 60 Hz.
Output:
• Filtered and electronically regulated outputs.
VertiLine33D, VertiLine33TD:
• Sixteen (16) PTC protected 12VDC power outputs.
VertiLine63D, VertiLine63TD:
• Sixteen (16) PTC protected 24VDC power outputs.
Sixteen (16) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
VertiLine33D
VertiLine33TD
VertiLine63D
VertilLine63TD
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This
installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes.
1. Attach mounting brackets to Vertiline unit for rack or wall mount installation (Figs. 3-4, pg. 7).
Affix rubber pads to Vertiline for shelf installation (Fig. 5, pg. 7).
2. Secure the unit into rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at least 3"
from any video monitors). When installing the unit in a rack allow for one half U spacing above the unit
for ventilation.
3. Insert and secure removable terminal blocks to unit (Fig. 1e, pg. 4).
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the Vertiline unit (Fig. 1d, pg. 4).
Insert the plug end of the line cord into a grounded AC receptacle.
5. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 1c, pg. 4).
6. Measure output voltage before connecting cameras/devices. This helps avoiding potential damage.
7. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 1c, pg. 4).
8. Connect the power output of terminals marked [+ 1 --- ] to the power input of device (Fig. 1b, pg. 4).
Repeat this step for each additional device (Outputs 2-16).
9. Upon completion of wiring, set illuminated master power disconnect circuit breaker to the
ON (RESET) position (Fig. 1c, pg. 4).
- 2 -
Specifica tions:
Total Output
Output Current
Voltage (Power)
12VDC 8A
12VDC 16A
24VDC 8A
24VDC 16A

Installation Instructions:

Overview:
Features:
• Sixteen (16) power LED indicators.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm).
Number of PTC Output
Outputs Protection
16
16
16
16
Current (max.
per output)
PTC 2.5A
PTC 2.5A
PTC 2.5A
PTC 2.5A
Vertiline33D/VertiLine33TD/Vertiline63D/VertiLine63TD
115VAC 60Hz
Input Current
1.5A
3A
3A
6A
