Chef RRE635W Installation Manual

Slideout rangehoods

Advertisement

slideout rangehood dimensions

80mm
34mm

slideout rangehood fixing distance

Minimum distance
of hood above hob

slideout rangehood exhaust options

Rear Exhaust
to atmosphere
* In recirculating mode you must use carbon filters to elminate cooking smells. (Model No. ARCFD)
† RRE635 models are supplied with carbon filters and 70mm fascia.
All measurements in millimetres.
Current as at Dec 2006.
© 2006 Electrolux Home Products Pty Ltd. ERANIDSLIDE90/70 05/06
100mm
470mm
550mm
598mm
GAS:
650mm
ELECTRIC:
600mm
Side Exhaust
Top Exhaust
to atmosphere
to atmosphere
installation guide
chef slideout rangehoods
models: RRE635W, RRE635S
121
210mm
175mm
42mm
page 1 of 2
70mm
20mm
158mm
458mm
280mm
Front Recirculating
*
Exhaust
