1
F-Series Camera Installation
1.4.2
The F-Series camera includes these standard components:
Fixed Camera Unit
Cable Glands and Spare Parts kit
1.4.3
The installer will need to supply the following items, which are specific to the installation.
24 V Power supply
Electrical wire, for system power; up to 100' (3-conductor, shielded, gauge determined by cable
length and supply voltage. Refer to
Camera grounding strap
Coaxial RG59U video cables (BNC connector at the camera end) for analog video
Shielded Category 6 Ethernet cable for control, streaming video, and for software upgrades.
Optional serial cable for serial communications
Miscellaneous electrical hardware, camera mount, connectors, and tools
1.5
The camera will require connections for power, communications (IP Ethernet, and/or serial
communications), and video.
Install cameras with an easily accessible Ethernet connection to support future software updates.
Ensure that cable distances do not exceed the specifications and that cables adhere to all local and
Industry Standards, Codes, and Best Practices.
If the camera is to be mounted on a pole, tower, or other hard-to-reach location, connect and
operate the camera as a bench test prior to mounting the camera in its final location.
1.5.1
Connect the power, video, serial, and Ethernet connections and confirm that the video is displayed on
a monitor when the power is turned on. For configuration and basic setup information using the
onboard web server, refer to
1.5.2
When selecting a mounting location for the F-Series camera, consider cable lengths and cable routing.
Ensure the cables are long enough, given the proposed mounting locations and cable routing
requirements, and route the cables before you install the components.
Use cables that have sufficient dimensions to ensure safety (for power cables) and adequate signal
strength (for video and communications).
427-0030-00-12 Version 180

Supplied Components

Required Components

Location Considerations

Bench Testing

Camera Bench Test, pg.

Prior to Cutting/Drilling Holes

Camera Connections, pg.
Important Note
Important Note
16.
March 2018
9.
6
