3. Setting and operation of shock monitoring
function

3.1 Related parameters

Set items and conditions of detection using parameters.
Title
f590
Shock monitoring
Shock monitoring trip/alarm
f591
selection
Shock monitoring detection
f592
direction selection
f593
Shock monitoring detection level
f595
Shock monitoring detection time
Shock monitoring detection
f596
hysteresis
Shock monitoring detection start
f597
waiting time
Shock monitoring detection action
f598
selection

3.2 Operation

1) Over-current/ torque detection
<Example>
Select object of detection with f590: f590=1 (Current detection), 2(Torque detection)
f591=0 (Alarm only)
f592=0 (Over-current/ torque detection)
Output terminal function: 182 (SUPA) Shock monitoring pre-alarm signal
Alarm signal output
f593
f593-f596
Output current/ torque (%)
When setting f591=1 (Tripping), inverter trips after low-current/ torque is detected for the period of
time set with f595. Then, alarm signal remains ON.
Function
0: Disabled
1: Current detection
2: Torque detection
0: Alarm only
1: Tripping
0: Over-current/ torque detection
1: Low-current/ torque detection
0-250 (%)
0.0-10.0 (s)
0-100 (%)
0.0-300.0 (s)
0: During operation
1: During operation (except acceleration/
deceleration)
3
Adjustment range
OFF
less than
f595
f595
E6581875
Default setting
0
0
0
150
0.5
10
0.0
0
ON
OFF
