Chapter 1: Safety Guidelines Chapter 1 Safety Guidelines To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
Introduction to the BPN-SAS3-F418-B6N4 Backplane The BPN-SAS3-F418-B6N4 backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance. Always refer to the Supermicro Web site at www.supermicro.com for the latest updates, compatible parts, and supported configurations.
BPN-SAS3-F418-B6N4 Backplane User's Guide Front Connector Pin Definitions #1. - 2. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JPW0 4-Pin Connector JPW0 and JPW1, provide power to the back- Pin# Definition plane. See the tables on the right for pin...
Chapter 2: Connectors and Pin Definitions Front Jumper Locations and Pin Definitions ACTLED Figure 2-2. Front Jumpers Explanation of Jumpers To modify the operation of the backplane, Connector Pins jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with Jumper...
BPN-SAS3-F418-B6N4 Backplane User's Guide Rear Connectors and LED Indicators Figure 2-3. Rear SAS/SATA Connectors and LED Indicators SAS/SATA Connectors and LED Indicators HDD Activity Failure Connector Number and HDD Number Label LED (Blue) SAS #0 LED0 LED00** SAS #1 LED1...
