Range Specifications
MEGOHMMETER RANGES
Range
4MΩ
40MΩ
400MΩ
4000MΩ
10GΩ
Analog Bar Graph
Nominal Current
Circuit Protection
AC VOLTAGE (40Hz-500Hz)
Range Res.
999VAC 1V
DC VOLTAGE
Range Res.
999VDC 1V
RESISTANCE & CONTINUITY
Range
Resistance: 999.9Ω
Continuity
LOW RESISTANCE Ω
Range Res.
40Ω 0.01Ω
Test Voltages
250V (+30% ~ -0%)
500V (+30% ~ -0%)
1000V (+30% ~ -0%)
0 to 10GΩ
≧ 1mA
Test inhibited if input ≧ 30V AC or DC
Accuracy
±2% + 2d
Accuracy
±1% + 2d
Res.
0.1Ω
Accuracy
±2% + 2d
3
Resolution
0.001MΩ
0.01MΩ
0.1MΩ
1MΩ
23
00.01GΩ
Input impedance
9MΩ
Input impedance
9MΩ
Accuracy Max. open circuit
Volt
±1% + 3d 3V
100Ω ± 80Ω)
Max. open
circuit Volt
6V
Model 380363 Version 2.0 July 2005
Accuracy
3%+5 (<1000M)
5%+5 (>1000M)
(% reading + digits at
o o
C ± 5 C < 80% RH)
Overload
Protection
1000Vrms
Overload
Protection
1000Vrms
Overload
Protect.
1000Vrms
Overload
Protection
>30V AC/DC
