  • Page 1: Operating Instructions

    Operating instructions Adora SLQ Washing machine...

  • Page 2: Safety Precautions

    ▪ If connected to the water mains by de- tachable hoses, the new hose set sup- ently installed electrical in- plied with the appliance must be used. stallation in accordance with Do not reuse old hose sets. © V-ZUG Ltd, CH-6301 Zug, 2017...

  • Page 3: Correct Use

    Safety precautions ▪ Ensure ready access to the power Correct use socket being used. The appliance is only suitable for washing ▪ Any repairs, modifications or manipula- home textiles with water and regular wash- tions to the appliance, especially any ing machine detergent.

  • Page 4: Using For The First Time

    These operating in- ance) in order to avoid damage to structions apply to: the appliance (see installation in- structions). Appliance Adora SLQ designation Running the first wash cycle without Type WAASLQZ any washing Product family 11013 ▸...

  • Page 5: Table Of Contents

    Contents Opening the appliance door in the event Appliance description  6 of a power failure.......... 34 Appliance construction ........ 6 Trouble-shooting  35 Indicator lights and button state .... 6 Error messages.......... 35 Operating and display elements.... 7 Other possible problems...... 37 Programme overview  8 Unsatisfactory wash results ...... 39 Whites and coloureds programmes.... 8 Spare parts  41...

  • Page 6: Appliance Description Appliance Construction

    Appliance description Appliance construction Detergent dispenser drawer (2) Drain tray (5) Pivoting operating panel Fabric conditioner, compartment Detergent dispenser drawer Liquid detergent flap / drain tray opener Appliance door 10 Siphon for fabric conditioner Circulation nozzle 11 Emergency door release tool Drain tray 12 Foreign body trap Pre-wash detergent, compartment I...

  • Page 7: Operating And Display Elements

    1 Appliance description Operating and display elements Coloureds Select temperature cold Door opener Programmes for 60°C Coloureds 60°C Coloureds 1 h 00 1 h 00 End 16 : 13 End 16 : 13 TouchDisplay normally soiled Fabric types cotton load and Start/Pause extra programmes Fast forward/...

  • Page 8: Programme Overview

    2 Programme overview Programme overview To select the right programme, please follow the fabric care symbols on the laundry labels, e.g. . woollens and textiles with the fabric care label may only be washed using the additional function «Hand wash». Whites and coloureds programmes Buttons Programmes Fabric care...

  • Page 9: Extra Programmes

    2 Programme overview Extra programmes Buttons Programmes Fabric care Load symbols capacity Steam anti-crease: Dry washing is partially 1–1.5 kg uncreased and made damp, ready to iron. Proofing: For starching or proofing laundry, add the agent 1–3 kg to the fabric conditioner compartment. Appliance hygiene: Steam cleaning without laundry.
  • Page 10 2 Programme overview Baby garments: Very thorough rinsing for the protection 1–5 kg of sensitive baby skin. If 95 °C is selected as the temper- ature, a pre-wash is included. Denim: Optimized for colour run from denim. 1–4 kg WetClean: For all fabrics labelled as washable. Most 1–1.5 kg gentle treatment possible through applying a gentle rock- ing motion and a fine spray of water.

  • Page 11: Additional Functions

    2 Programme overview Additional functions Buttons Additional functions Load capacity Eco: Large energy savings due to reduced wash temperature. The extended wash- ing time ensures the washing performance is maintained. Depending on pro- gramme, energy savings of about 10%-40%, extension of the washing times by 25– 60 minutes and water savings of about 10%-20%.

  • Page 12: Ecomanagement

    2 Programme overview Buttons Additional functions Delayed start: For using cheap-rate electricity (setting range of up to 24 hours). The programme starts automatically when the set time is reached. OptiTime: If a programme end time has been selected, OptiTime calculates the most energy-efficient programme that can be carried out in the time remaining to programme end.

  • Page 13: Operating The Appliance Preparations

    3 Operating the appliance Operating the appliance Preparations ▸ Check the foreign body trap is inserted correctly. ▸ Insert the mains plug into a suitable mains socket. ▸ Turn on water tap. ▸ Press the button to open the appliance door. Loading the washing ▸...

  • Page 14: Adding Washing Detergent

    3 Operating the appliance Adding washing detergent Liquid detergent Powder detergent ▸ Pull the detergent dis- ▸ Pull the detergent dis- penser drawer out as far penser drawer out as far as it will go. as it will go. ▸ Pull flap a upwards and ▸...

  • Page 15: Detergent Dosage

    3 Operating the appliance Detergent dosage Adding too much washing detergent can cause excess foaming, The con- sequences: poor wash results, damage to the appliance in the worst case. The correct dosage depends on the degree of soiling, the wash load, the water hardness and the product used.
  • Page 16 3 Operating the appliance ▸ Touch the button for the de- 60°C Coloureds 1 h 00 sired programme. End 16 : 13 The programme selected, the expected duration, the expec- ted programme end time and the selectable additional func- tions are displayed. The indic- ator light for the selectable 1200 button flashes.

  • Page 17: Selecting Additional Functions

    3 Operating the appliance Extra programmes ▸ Close the appliance door. Extra 10° Standard Steam anti-cr. ▸ Touch the button. The adjacent TouchDisplay ap- 40° Standard Proofing pears. ▸ Touch the button for the de- Spinning App. hygiene sired extra programme. ▸...

  • Page 18: Delayed Start

    3 Operating the appliance Delayed start Selecting programme end time The option «Programme end, OptiTime off» must be enabled in the user settings under «Pro- gramming delayed start / OptiTime» (see page 29). ▸ Touch the button for the de- sired programme.

  • Page 19: Optitime

    3 Operating the appliance OptiTime The option «Programme end, OptiTime on» must be enabled in the user settings under «Pro- gramming delayed start / OptiTime» (see page 29). ▸ Touch the button for the de- sired programme. ▸ Touch the button. Progr.

  • Page 20: Bio Wash / Soap Wash

    3 Operating the appliance 3.11 Bio wash / Soap wash To start Bio or Soap wash, «Multi-component detergent» must be enabled in the user settings (see page 30). Ensure the alkaline detergent or soap detergent are added to the correct compartment (see page 14).

  • Page 21: With Childproof Lock Activated

    3 Operating the appliance 3.14 With childproof lock activated Selecting programme How to turn the childproof lock on/off is described in «User settings». ▸ Close the appliance door. Childproof lock The adjacent TouchDisplay ap- pears. Code ▸ Touch the digits 7, 3, 1 in se- quence.

  • Page 22: Opening The Appliance Door During Washing

    3 Operating the appliance 3.15 Opening the appliance door during washing The appliance door can only be opened if the indicator light for the button is illuminated. ▸ Touch the button. The appliance door opens. Laundry can be added or removed. ▸...

  • Page 23: Hygiene Recommendation

    3 Operating the appliance «Automatic door opener OFF» and «EcoManagement ON» When the programme has finished, the adjacent 60°C Coloureds display appears for about 20 minutes. 0 h 00 ▸ Touch the button to open the appliance door and unload the End of programme washing at any time.

  • Page 24: Ecomanagement Statistics

    3 Operating the appliance 3.17 EcoManagement statistics Energy and water consumption can be displayed before a programme starts or after a programme ends. Displaying the last programme ▸ Touch the button. Last programme The energy and water con- sumption of the last pro- gramme run is displayed.

  • Page 25: Favourites

    4 Favourites Favourites Simple start to frequently used programmes. Note: The appliance door has to be open to define, change or delete a fa- vourite. Defining favourites ▸ Touch the button. ▸ Touch one of the favourite buttons. empty ▸ Select programme and ad- ditional functions.

  • Page 26: Deleting Favourites

    4 Favourites Deleting favourites ▸ Touch the button. ▸ Select the favourite programme to be deleted. 60°C ▸ Touch the button. Clear The favourite programme is deleted. Starting favourites ▸ Close the appliance door. ▸ Touch the button. ▸ Select the desired favourite programme. 60°C ▸...

  • Page 27: User Settings

    5 User settings User settings Providing no programme is running and no error message is displayed, the user settings can be changed. Preparations ▸ Touch the button. Extra The adjacent TouchDisplay ap- pears. 10° Standard Steam anti-cr. ▸ Touch the button. ▸...

  • Page 28: Spin Speed

    5 User settings Spin speed An increase in the spin speed is only as- signed to suitable programmes. A reduc- tion in the spin speed is assigned to all programmes. 1600 AquaPlus ▪ Standard: Normal water level. Standard ▪ more water: Increased water level. ▪...

  • Page 29: Childproof Lock

    5 User settings Hygiene info When the function is turned on, a wash of at least 60 °C is recommended for Hygiene hygiene reasons whenever the formation info Off of foul smelling coatings in the appliance is to be prevented. Childproof lock The childproof lock prevents a pro- gramme from being started accidentally.
  • Page 30 5 User settings 5.13 Multi-component detergent When the function is turned on, the de- sired type of wash can be selected un- Multi-comp. der the additional function «Pre-wash». detergent Off 5.14 Silent When the function is turned on, pro- grammes with the additional function «Eco»...

  • Page 31: Care And Maintenance

    6 Care and maintenance 5.18 Button tone The button tone can be turned on and off. The button tone for the buttons cannot be turned off. Off 5.19 Factory settings Restore The factory settings can be restored. The language if changed is not reset to the factory setting.

  • Page 32: Cleaning The Water Inlet Filter

    6 Care and maintenance Cleaning the water inlet filter Test the water inlet for leaks following maintenance work. ▸ To avoid blockages, periodically check and, if necessary, clean the water inlet filter 1. Emergency draining The water in the appliance may be hot. Scalding hazard! Allow to cool down be- fore emergency draining.

  • Page 33: Cleaning The Foreign Body Trap

    6 Care and maintenance Cleaning the foreign body trap Note: Clean the foreign body trap at regular intervals as well as after washing, for instance, pet blankets or other wash items that cause a thick build-up of fluff. ▸ Open the appliance door. ▸...

  • Page 34: Opening The Appliance Door In The Event Of A Power Failure

    6 Care and maintenance Opening the appliance door in the event of a power failure Wait until the washing drum is completely stationary. A washing drum that is still rotating poses a risk of serious injury. ▸ Close the water tap and disconnect the appliance from the mains. ▸...

  • Page 35: Trouble-Shooting

    7 Trouble-shooting Trouble-shooting You may be able to trouble-shoot the following errors yourself. If not, note down the error message in full (message, F and E numbers) and call Customer Services. Error messages Display Possible cause Solution ▪ The foreign body trap is ▸...
  • Page 36 7 Trouble-shooting Display Possible cause Solution F6/E77 ▪ Anti-leak protection was ▸ Turn off water tap. triggered. see instructions ▸ Note down error message in full and FN XXXXX XXXXXX appliance's FN. ▸ Touch the button. ▸ Call Customer Services. FXX/EXX ▪...

  • Page 37: Other Possible Problems

    7 Trouble-shooting Display Possible cause Solution Hygiene recom- ▪ No wash cycle has been ▸ With one of the next wash cycles carry mend. carried out at a temperat- out a wash with at least 60° C. ure of at least 60 °C for a longer period of time.
  • Page 38 7 Trouble-shooting Problem Possible cause Solution At the end of the ▪ The appliance door is ▸ Press hard against the lock side of the programme, the ap- stuck. appliance door (i.e. front edge of ap- pliance door can- pliance door). not be opened with ▸...

  • Page 39: Unsatisfactory Wash Results

    7 Trouble-shooting Problem Possible cause Solution Laundry is still dry ▪ «Demo mode» is turned ▸ Open the appliance door. after programme ▸ Hold the buttons de- has finished – no pressed. error message. ▸ Simultaneously touch the button. In the display appears: «Demo mode status: On"...
  • Page 40 7 Trouble-shooting Result Possible cause Solution Unsatisfactory ▪ Liquid detergent does not ▸ Use washing detergent containing wash result using li- contain bleach. bleach (see page 14). quid detergent Soap deposits on ▪ Water hardness is too ▸ Soap detergent should only be used if washing high.

  • Page 41: Spare Parts

    8 Spare parts Spare parts Please give product family and exact designation when ordering parts. Drain hose 1.5 m / Emergency door re- Foreign body trap Drain tray 4.0 m lease tool Siphon Detergent dis- Liquid detergent penser drawer flap Technical data Dimensions Spin speed Height...

  • Page 42: Note For Testing Institutes

    9 Technical data Note for testing institutes Set to the standard programmes according to AS/NZS 2040.2:2005 : Programme Load capacity 40 °C Coloureds normal 8 kg ▸ Touch the button. ▸ Touch the button. ▸ Touch the button. 10 °C Coloureds normal 8 kg ▸...

  • Page 43: Vas Vibration Absorbing System

    9 Technical data Extra programmes Programme Load Spin speed ¹ Duration Water Energy hrs./mins. Litres Steam anti-crease 1–1.5 0h23 Proofing 20 °C 1–3 0h28 Appliance hygiene 0h30 Factory setting Fabric types Programme Load Spin speed ¹ Duration Water Energy kg/items hrs./mins. Litres Shirts 40 °C max. 7 items...

  • Page 44: Water And Energy Economy

    10 Washing tips Water and energy economy During the first few minutes of a programme running, sensors automatically determine the type and the size of the load being washed. Water levels are then optimally adjusted to the wash load so that only the strict amount of wa- ter needed is used.

  • Page 45: Avoiding Damage

    10 Washing tips 10.2 Avoiding damage ▪ Follow the fabric care symbols on garment labels. ▪ The wash temperature selected should agree with the recommended temperature range of the washing detergent to ensure the washing detergent is at its most effective. ▪...
  • Page 46 11 Disposal Disposal 11.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 11.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
  • Page 47 Notes...

  • Page 48: Quick Instructions

    (FN) and ap- agreement pliance designation to register your appli- V-ZUG will be happy to help you with any ance. You will find them on the identifica- general administrative or technical queries, tion plate of your appliance.
