Regency I1200 Specification Sheet page 2

I1200 Wood Insert
Dimension Description
A Adjacent Side Wall (to side)
B Mantle (to top)**
C Top Facing (to top)
D Side Facing (to side)
E Minimum Hearth Extension*
F Minimum Heath Thickness*
G Minimum Hearth Side Extension
Side and Top facing is a maximum of 1-1/2" thick.
Floor protection must be non-combustible, insulating material with an
R value of 1.1 or greater.
* If the hearth extension is fl ush with the fl oor (F) it must extend
19-1/2" in front of the body face (E).
Note: Hearth Extension Width (G) is measured from edge of fuel
door to side of hearth.
** A non-combustible mantel may be installed at a lower height if the
framing is made of metal studs covered with a non-combustible
board.
188
Wood Inserts
I1200 Small Wood Insert
I1200
15" (381mm)
20" (508mm)
14" (356mm)
7-3/8" (187mm)
16" (406mm)
1-1/2" (38mm)
8" (203mm)
June 2007 Regency Product Specifi cations Book
