1. Parts location

2. Specifications

Model
Type
Dry weight
Blade size
Blade pitch
Transmission
Reduction ratio
Engine
Carburetor
Spark plug
Fuel tank capacity
Durability period
Type
Mode
Displacement
Max. output
Idle speed
mixture(Gasoline 50 : Oil 1)(when using RedMax/ZENOAH genuine oil)
Fuel
1. Fuel tank
2. Starter
3. Throttle lever
4. Ignition switch
5. Throttle Cable
6. Muffler
7. Blade
8. Front handle
9. Rear handle
CHT2250
Reciprocating
double-sided dual blades
4.6(kg)/ 10.1(lbs)
550(mm)/ 22(in)
35(mm)/ 1.38(in)
Centrifugal clutch, Cam-crank
4.25
Air-cooled 2-stroke gasoline
G23LH
22.5(cm 3 )/ 1.37(cu-in)
- 1
0.68Hp(0.51kW)at 6500 / min
2800 ± 200 / min
- 1 (rpm)
Walbro Diaphragm type
CHAMPION RCJ6Y
0.59(litter)/ 20.0(fl.oz)
50(hrs.)
Specifications are subject to change without notice.
CHT2250
(rpm)
