OWNER / OPERATOR MANUAL
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
APPLICABLE SERIAL NUMBERS :
HT2300A
CUTTING UNIT 900532 and up
HT2300L
CUTTING UNIT 900101 and up
CHT2300B
CUTTING UNIT 901223 and up
CHT2300L
CUTTING UNIT 900504 and up
HEDGE-TRIMMERS
HT2300A
HT2300L
CHT2300B
CHT2300L
Thank you for purchasing a RedMax
product.
Before using our hedge-trimmers,
please read this manual carefully to
understand the proper use of your unit.
ENGINE UNIT 968060 and up
ENGINE UNIT 968060 and up
ENGINE UNIT 972833 and up
ENGINE UNIT 972833 and up
6833-93112(103)
Advertisement
Table of Contents
Related Manuals for RedMax CHT2300B
Summary of Contents for RedMax CHT2300B
- Page 1 OWNER / OPERATOR MANUAL HEDGE-TRIMMERS HT2300A HT2300L CHT2300B CHT2300L WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. APPLICABLE SERIAL NUMBERS : HT2300A CUTTING UNIT 900532 and up...
-
Page 2: Safety First
Read this manual carefully to understand all safety precautions, controls, proper operation and maintenance of your RedMax hedge- trimmers. Failure to do so could result in serious injury. Instructions contained in warnings within this manual marked with a concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 3: Table Of Contents
HT2300A/HT2300L CHT2300B/CHT2300L FUEL · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 9... -
Page 4: Safety Precautions
Safety Precautions IN ORDER TO ENSURE PROPER AND SAFE OPERATION OF YOUR HEDGE-TRIMMER • Read this Owner/Operator Manual carefully. Be sure you understand how to operate this unit properly before you use it. Failure to do so could result in serious injury. -
Page 5: Work Gear And Clothing
Safety Precautions WORK GEAR AND CLOTHING • When using your hedge-trimmer, always be sure to wear strong, durable, work clothing; shirts should be long-sleeved shirts and pants should be full-length pants reaching down to the ankles. • Always be sure to wear and helmet and face protector when using your hedge- trimmer. -
Page 6: Things To Check Before Using Your Hedge-Trimmer
Safety Precautions THINGS TO CHECK BEFORE USING YOUR HEDGE-TRIMMER • Before beginning work, look around carefully to get a feel for the shape of the land, the trees, or hedges to be trimmed, and whether or not there are any obstacles which might get in the way while working, and remove any obstacles which can be cleared away before beginning work. -
Page 7: Things To Be Careful About When Using Your Hedge-Trimmer
Safety Precautions THINGS TO BE CAREFUL ABOUT WHEN USING YOUR HEDGE-TRIMMER • When using your hedge-trimmer, grip the handles of the hedge-trimmer firmly with both hands, place your feet slightly apart (slightly further apart than the width of your shoulders) so that your weight is distributed evenly across both legs, and always be sure to maintain a steady, even posture while working. -
Page 8: Notes On Care And Maintenance Of Your Hedge-Trimmer
Safety Precautions NOTES ON CARE AND MAINTENANCE OF YOUR HEDGE-TRIMMER • In order to maintain your hedge-trimmer in proper working order, perform the maintenance and checking operations described in this manual at regular intervals. In the event that any parts must be replaced or any maintenance or repair work not described in this manual must be performed, please contact a representative... -
Page 9: Set Up
Set up HT2300A/HT2300L 1. Join the engine unit to the clutch housing of the cutter unit, with the fuel tank on the blade side. 2. Align the mounting holes and tighten the engine securely with the 3 screws. 3. Remove the right handle mounting screw, nut, and washer casually attached on the blade beam. -
Page 10: Cht2300B/Cht2300L
Set up CHT2300B/CHT2300L 1. Attach the engine to the clutch housing of the cutter unit. Casually fix the front 2 points with the screws(.55" long)(15mm long). 2. After connecting the ground wire, install the rear handle to the clutch housing with the screw(2"... -
Page 11: Fuel
Fuel WARNING • Gasoline is very flammable. Avoid smoking or bringing any flame or sparks near fuel. Make sure to stop the engine and allow it cool before refueling the unit. Select outdoor bare ground for fueling and move at least 3m(10ft) away from the fueling stop before starting the engine. -
Page 12: Operation
2. Stop the engine by the stop switch. [HT2300A/HT2300L] Press on the stop button until the engine stops completely. [CHT2300B/CHT2300L] Shift the ignition switch to the STOP position. NOTE • Except for an emergency, avoid stopping... -
Page 13: Adjusting Idling Speed
Operation ADJUSTING IDLING SPEED 1. When the engine tends to stop frequently at idling mode, turn the idle set screw clock-wise. 2.When the cutting blades keep moving after releasing the throttle trigger, turn the idle set screw counter-clockwise. NOTE • Warm up the engine before adjusting the idling speed. -
Page 14: Maintenance
Maintenance WARNING • Make sure that the engine has stopped and is cool before performing any service to the hedge-trimmer. Contact with moving cutting head or hot muffler may result in a personal injury. DAILY INSPECTION • Check all the fasteners for loose or missing ones. -
Page 15: Muffler
Maintenance MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the hedge-trimmer and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire. -
Page 16: Procedures To Be Performed After Every 100 Hours Of Use
Maintenance PROCEDURES TO BE PERFORMED AFTER EVERY 100 HOURS OF USE 1. Remove the muffler, insert a screwdriver into the vent, and wipe away any carbon buildup. Wipe away any carbon buildup on the muffler exhaust vent at the same time. 2. -
Page 17: Specifications
Blade size ··················································································· (29.5 [40] in)(750 [1000] mm) Dry weight ····························································································· (12 [13] lbs)(6 [6.5] kg) Engine Type··········································································· Air-cooled 2-stroke gasoline Model····························································································· Zenoah G23LH Displacement ···························································································· 22.5(cc) Fuel ·············································································· Mixture(Gasoline 32:Oil 1) Carburetor ········································································ Walbro Diaphragm type Spark plug ················································································· Champion RCJ6Y Fuel tank capacity ·····························································································... -
Page 19: Parts List
Parts List NOTE : 1. Use KOMATSU ZENOAH genuine parts as specified in the parts list for repair and/or replacement. 2. KOMATSU ZENOAH does not warrant the machines, which have been damaged by the use of any parts other than those specified by the company. - Page 20 Parts List Fig.1 CUTTER GROUP — HT2300A & HT2300L...
- Page 21 Parts List Fig.1 CUTTER GROUP — HT2300A & HT2300L Key# Description Part Number Right handle comp. 3883-12101 Washer 3883-12130 Reinforce 3880-11750 Reinforce 3885-11750 Guide plate 3883-11612 Guide plate 3927-11612 Upper blade 3880-11720 Upper blade 3927-11720 Lower blade 3880-11730 Lower blade 3927-11730 Washer 3880-11780...
- Page 22 Parts List Fig.2 ENGINE GROUP — HT2300A & HT2300L...
- Page 23 Parts List Fig.2 ENGINE GROUP — HT2300A & HT2300L Key# Description Part Number Q'ty Cylinder 5602-12110 Gasket, base 5500-12213 Bolt, M5x22 1850-12130 Insulator 5500-13163 Gasket, insulator 5500-13121 Gasket, carb 5500-13131 Screw, M5x20 0263-90520 Muffler ass'y 5603-15100 • Muffler 5603-15110 • Spark arrester 1601-15120 Bolt, M5x50 01252-30550...
- Page 24 Parts List Fig.3 CUTTER GROUP — CHT2300B & CHT2300L...
- Page 25 Parts List Fig.3 CUTTER GROUP — CHT2300B & CHT2300L Key# Description Part Number Rear handle ass’y 6845-13100 • Screw, M4x10 3873-13180 • Plate 3873-13170 • Cable end 3873-13210 • Switch ass’y 6845-13130 • Throttle lever 3873-13221 • Snap ring 3873-13230 •...
- Page 26 Parts List Fig.4 ENGINE GROUP — CHT2300B & CHT2300L...
- Page 27 Parts List Fig.4 ENGINE GROUP — CHT2300B & CHT2300L Key# Description Part Number Q'ty Cylinder 5602-12110 Gasket, base 5500-12213 Bolt, M5x22 1850-12130 Insulator 5500-13163 Gasket, insulator 5500-13121 Gasket, carb 5500-13131 Screw, M5x20 0263-90520 Muffler ass'y 5603-15100 • Muffler 5603-15110 • Spark arrester...
-
Page 28: California Emission Control Warranty Statement
MANUAL. KOMATSU ZENOAH Co. RECOMMENDS THAT YOU RETAIN ALL RECEIPTS COVERING MAINTENANCE ON YOUR LAWN AND GARDEN ENGINE, BUT KOMATSU ZENOAH Co. CAN NOT DENY WARRANTY SOLELY FOR THE LACK OF RECEIPTS OR FOR YOUR FAILURE TO ENSURE THE PERFORMANCE OF ALL SCHEDULED MAINTENANCE. - Page 29 ZENOAH AMERICA INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE. PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOAH AMERICA WITHIN SEVEN (7) DAYS. BE SURE TO KEEP A COPY FOR YOUR RECORDS.
- Page 30 ZENOAH AMERICA INC. au (770)-381-5147 Note importante: vous recevrez une carte d'enregistrement de garantie au moment de l'achat. Veuillez la remplir et l'adresser à RedMax / KOMATSU ZENOAH AMERICA sous sept (7) jours en prenant soin de conserver une copie pour vous.
-
Page 31: Emission Control Label
Emission Control Label IMPORTANT ENGINE INFORMATION THIS ENGINE CONFORMS TO U.S. EPA PH1 FOR SMALL OFF-ROAD ENGINES. ENGINE FAMILY : 1KZXS. 0254CD ; EM ENGINE DISPLACEMENT : 22.5cc REFER TO OWNER’S MANUMAL FOR MAINTE- NANCE SPECIFICATIONS AND ADJUSTMENTS. RedMax INFORMATION IMPORTANTE CONCERNANT LE MOTEUR Ce moteur conformc aux normcs U.S. - Page 32 KOMATSU ZENOAH AMERICA INC. 4344 Shackleford Road Suite 500 Norcross, Georgia 30093 © Printed in Japan...
