Daikin FTKB09AXVJU Service Manual page 76

Refrigerant Diagram
Table 2: Resistance R25 = 10 kΩ
Rmin
t°C t°F
(kΩ)
-10 14.0 44.20
-9 15.8 42.10
-8 17.6 40.20
-7 19.4 38.30
-6 21.2 36.60
-5 23.0 34.90
-4 24.8 33.30
-3 26.6 31.80
-2 28.4 30.40
-1 30.2 29.00
0 32.0 27.80
1 33.8 26.60
2 35.6 25.40
3 37.4 24.30
4 39.2 23.30
5 41.0 22.30
6 42.8 21.40
7 44.6 20.50
8 46.4 19.60
9 48.2 18.80
10 50.0 18.00
11 51.8 17.30
12 53.6 16.60
13 55.4 15.90
14 57.2 15.30
15 59.0 14.70
16 60.8 14.10
17 62.6 13.50
18 64.4 13.00
19 66.2 12.50
20 68.0 12.00
21 69.8 11.60
22 71.6 11.10
23 73.4 10.70
24 75.2 10.30
25 77.0 9.90
26 78.8 9.52
27 80.6 9.16
28 82.4 8.82
29 84.2 8.49
30 86.0 8.17
31 87.8 7.87
32 89.6 7.58
33 91.4 7.31
34 93.2 7.04
35 95.0 6.79
36 96.8 6.54
37 98.6 6.31
38 100.4 6.09
39 102.2 5.87
40 104.0 5.67
Remarks: At ambient temperature of 25ᵒC (77°F), nominal resistance value is 10.00kΩ.
Rnom Rmax
(kΩ) (kΩ)
45.30 46.50
43.20 44.30
41.20 42.20
39.20 40.20
37.40 38.30
35.70 36.50
34.10 34.90
32.60 33.30
31.10 31.80
29.70 30.30
28.40 29.00
27.10 27.70
25.90 26.50
24.80 25.30
23.70 24.20
22.70 23.10
21.80 22.10
20.80 21.20
20.00 20.30
19.10 19.40
18.30 18.60
17.60 17.80
16.90 17.10
16.20 16.40
15.50 15.70
14.90 15.10
14.30 14.50
13.70 13.90
13.20 13.30
12.70 12.80
12.20 12.30
11.70 11.80
11.20 11.40
10.80 10.90
10.40 10.50
10.00 10.10
9.62 9.72
9.26 9.36
8.92 9.02
8.59 8.69
8.27 8.37
7.97 8.07
7.68 7.78
7.40 7.50
7.14 7.23
6.88 6.98
6.64 6.73
6.40 6.50
6.18 6.27
5.96 6.05
5.75 5.84
Rmin
t°C t°F
(kΩ)
41 105.8 5.47
42 107.6 5.28
43 109.4 5.10
44 111.2 4.92
45 113.0 4.75
46 114.8 4.59
47 116.6 4.44
48 118.4 4.29
49 120.2 4.15
50 122.0 4.01
51 123.8 3.88
52 125.6 3.75
53 127.4 3.63
54 129.2 3.51
55 131.0 3.40
56 132.8 3.29
57 134.6 3.18
58 136.4 3.08
59 138.2 2.98
60 140.0 2.89
61 141.8 2.80
62 143.6 2.71
63 145.4 2.63
64 147.2 2.55
65 149.0 2.47
66 150.8 2.40
67 152.6 2.32
68 154.4 2.25
69 156.2 2.19
70 158.0 2.12
71 159.8 2.06
72 161.6 2.00
73 163.4 1.94
74 165.2 1.88
75 167.0 1.83
76 168.8 1.77
77 170.6 1.72
78 172.4 1.67
79 174.2 1.63
80 176.0 1.58
81 177.8 1.53
82 179.6 1.49
83 181.4 1.45
84 183.2 1.41
85 185.0 1.37
86 186.8 1.33
87 188.6 1.30
88 190.4 1.26
89 192.2 1.23
90 194.0 1.19
Rnom Rmax
(kΩ) (kΩ)
5.56 5.64
5.37 5.45
5.18 5.27
5.01 5.09
4.84 4.92
4.67 4.76
4.52 4.60
4.37 4.42
4.22 4.30
4.09 4.16
3.95 4.03
3.82 3.90
3.70 3.77
3.58 3.65
3.47 3.54
3.36 3.43
3.25 3.32
3.15 3.22
3.05 3.12
2.96 3.01
2.86 2.93
2.78 2.84
2.69 2.75
2.61 2.67
2.53 2.59
2.45 2.51
2.38 2.44
2.31 2.37
2.24 2.30
2.17 2.23
2.11 2.17
2.05 2.10
1.99 2.04
1.93 1.98
1.88 1.93
1.82 1.87
1.77 1.82
1.72 1.77
1.67 1.72
1.62 1.67
1.58 1.62
1.53 1.58
1.49 1.54
1.45 1.49
1.41 1.45
1.37 1.41
1.33 1.38
1.30 1.34
1.26 1.30
1.23 1.27
68
