Dynojet Power Commander V Installation Instructions Manual page 3

FIG.A
FIG.B
PCV harness
FIG.C
24-004 www.powercommander.com
1
2
3
4
PCV Ground 5
Ground wire
6
Remove the seat.
Remove the fuel tank and the lower right side panel.
Secure the PCV in the tail section using the supplied velcro.
Route the wiring harness from the PCV along the left side of the tail and go
towards the engine.
Attach the ground wire from the PCV to the negative side of the battery
(Fig. B).
Route the PCV harness along the left side of the frame. Use the stock wire
ties to secure the PCV harness in place.
2010 Brutale 990 PCV - 3
