OWNER/OPERATOR MANUAL
MANUAL DEL PROPIETARIO/OPERADOR
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING
Before using our products, please
read this manual carefully to
understand the proper use of your
unit.
APPLICABLE SERIAL NUMBERS: 300001 and up
BACKPACK BLOWER
SOPLADOR DE MOCHILA
EBZ5000Q
ADVERTENCIA
Los gases de escape del motor de
este producto contienen sustancias
químicas conocidas por el Estado de
California como causantes de cáncer,
malformaciones en recién nacidos y
otros problemas de reproducción.
ADVERTENCIA
Antes de usar nuestros productos,
lea detenidamente este manual a fin
de familiarizarse con el uso correcto
de este aparato.
NÚMEROS DE SERIE APLICABLES: 300001 y posteriores
848-L3D-93A2 (605)
Advertisement
Table of Contents
Related Manuals for RedMax EBZ5000Q
Summary of Contents for RedMax EBZ5000Q
- Page 1 APPLICABLE SERIAL NUMBERS: 300001 and up BACKPACK BLOWER EBZ5000Q Los gases de escape del motor de este producto contienen sustancias químicas conocidas por el Estado de California como causantes de cáncer, malformaciones en recién nacidos y...
-
Page 2: Safety First
@ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ soplador RedMax. Si no lee @ @ @ @ @ @ @ @ @ @ @ @ @ @ @ @... -
Page 3: Table Of Contents
English Contents SAFETY PRECAUTIONS …………………………………………4 OPERATOR USE OF BLOWER FUEL WORKING CONDITION AVOID NOISE PROBLEM AVOID CHANCES OF DAMAGE WARNING LABELS ON THE MACHINE …………………………8 SYMBOLS ON THE MACHINE ……………………………………9 PARTS LOCATION ………………………………………………10 SPECIFICATIONS …………………………………………………11 ASSEMBLY …………………………………………………………11 BLOWER TUBE FUEL…………………………………………………………………13... -
Page 4: Safety Precautions
? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ ■ OPERATOR • Refrain from operating the blower if you are tired, ill, or upset, or if you are under the influence of alcohol, drugs or medication. - Page 5 • Avoid using accessory attachment other than those bearing the RedMax mark for use with the blower. • Drain the fuel from the fuel tank before transporting or storing the blower. • When storing the blower, choose a space indoors free from moisture and out of the reach of children.
-
Page 6: Fuel
• Make sure the unit is properly assembled and in good operating condition. ■ WORKING CONDITION • Check the work area that the blower will be used in and remove or cover all valuables that may be damaged by the air blast or thrown debris. -
Page 7: Avoid Noise Problem
• Watch out for children, pets, open windows or freshly washed cars, and blow debris safely away. • Use the full blower nozzle extension so the air stream can work close to the ground. • After using blowers and other equipment, CLEAN UP! Dispose of debris in trash receptacles. -
Page 8: Warning Labels On The Machine
(3) Handling this machine improperly could result in accidents causing serious injury or death. Read this manual carefully and practice using the blower until you are fully acquainted with all operations and have learned to use it correctly. IMPORTANT If warning label peel off or become soiled... -
Page 9: Symbols On The Machine
IMPORTANT ENGINE INFORMATION THIS ENGINE MEETS U.S. EPA PH2 AND 2006 CALIFORNIA EMISSION REGULATIONS FOR SI SORE’s COMPLIANCE PERIOD : CATEGORY A ENGINE FAMILY : 6KZXS.0484HI ; EM ENGINE DISPLACEMENT : 48 cc REFER TO OWNER’S MANUAL FOR MAINTE- NANCE SPECIFICATIONS AND ADJUSTMENTS. MANUFACTURED: MADE IN JAPAN INFORMATION IMPORTANTE CONCERNANT LE MOTEUR... -
Page 10: Parts Location
English Parts Location 1. Frame 2. Shoulder Strap 3. Spark Plug Cap 4. Throttle Lever 5. Ignition Switch (behind) 6. Net 7. Choke Lever 8. Air Cleaner 9. Volute Case 10. “CAUTION” Label 11. “CAUTION” Net Label (behind) 12. Elbow 13. -
Page 11: Specifications
English Specifications MODEL EBZ5000Q Dimensions (L x W x H) mm (in) ...530 x 540 x 475 (20.9 x 21.3 x 18.7) Dry Weight kg (lbs) ...8.9 (19.6) Fuel Tank Capacity liter (fl. oz) ...2.0 (67.6) Engine Type ...Strato charged air cooled 2-cycle gasoline engine Piston Displacement cm (cu. - Page 12 English Fuel ■ FUEL WARNING • Gasoline is very flammable. Avoid smoking or bringing any flame or sparks near fuel. Make sure to stop the engine and allow it cool before refueling the unit. Select outdoor bare ground for fueling and move at least 3m (10ft) away from the fueling point before starting the engine.
-
Page 13: Fuel
English Fuel ■ HOW TO MIX FUEL IMPORTANT Pay attention to agitation. 1. Measure out the quantities of gasoline and oil to be mixed. 2. Put some of the gasoline into a clean, approved fuel container. 3. Pour in all of the oil and agitate well. 4. - Page 14 English Fuel of rubber and/or plastic parts and disruption of engine lubrication. 3. OIL FOR 4-CYCLE ENGINE USE – It can cause spark plug fouling, exhaust port blocking, or piston ring sticking. 4. Mixed fuels which have been left unused for a period of one month or more may clog the carburetor and result in the engine failing to operate properly.
-
Page 15: Operation
(1) Full Throttle (2) 1/3 Open (3) Idling (4) Ignition Switch 4. To start, hold the top of the blower firmly with your left hand. Pull the starter knob slowly until you feel it engage and then give it a vigorous strong pull. -
Page 16: Adjusting Idle Speed
“O” “I” English Operation 5. Once the engine is running, gradually open the choke if it was set closed, and let the engine run at idle speed for a minute to warm it up. NOTE When the engine fails to start after several attempts due to overchoking, open the choke and repeat pulling the rope. -
Page 17: Maintenance
■ AIR CLEANER • Never operate the blower without an air filter or with a deformed or broken filter element. • Check the air cleaner every 25 hours of use or more frequently if used under dusty conditions. -
Page 18: Fuel Filter
English Maintenance (1) Cover Cleaner (5) Packing (2) Screen (6) Yellow (3) Cleaner Body (7) Black (4) Element NOTE • Assure that the screen is securely fitted to the packing. Fit securely if it is loose. • Insufficient fixing of screws may cause fall off of the cover and insufficient sealing. -
Page 19: Muffler
• Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the blower and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire. -
Page 20: Shoulder Strap
(1) Net WARNING Never use the blower without the net of the blower. Before each use, check that the net is attached in place and is free from any damage. -
Page 21: Parts List
APPLICABLE SERIAL NUMBERS: 300001 and up PARTS LIST LISTA DE PIEZAS BACKPACK BLOWER SOPLADOR DE MOCHILA EBZ5000Q NOTA: 1. Para reparaciones o cambios, utilice piezas 2. KOMATSU ZENOAH no garantiza máquinas 3. Al solicitar piezas para reparación y/o 4. Las piezas incluidas en la lista de piezas 5. - Page 22 Parts List : EBZ5000Q Fig.1 BLOWER GROUP (S/N 300001 and up)
- Page 23 EBZ5000Q Fig.1 BLOWER GROUP Key# Part Number Description T4017-31110 VOLUTE CASE 2 848-L36-55B0 VOLUTE COVER T4970-52510 SCREW T4970-52510 SCREW T4030-31410 ELBOW 07000-02095 O-RING T4960-57030 SCREW 3310-53331 T4017-31310 FUNNEL 10 848-8K4-0010 CLAMP T4970-51410 SCREW 2750-31290 TUBE T4017-31510 T4950-63031 BOLT T4017-31600 ENGINE COVER ASSY...
- Page 24 Parts List : EBZ5000Q Fig.2 ENGINE GROUP (S/N 50100000 and up)
- Page 25 EBZ5000Q Fig.2 ENGINE GROUP Key# Part Number Description T1108-12110 CYLINDER T1108-12210 GASKET, BASE 4820-12130 BOLT T1108-12310 PLATE T4960-50810 SCREW T1108-13160 INSULATOR 848-815-2001 BOLT 8 848-GC0-14B2 GASKET, INSU T1108-13130 GASKET, CARB T1108-15110 MUFFLER T1108-15120 ARRESTER 1410-86130 CLIP T4950-67031 BOLT T4950-61431 BOLT T1108-15210 GASKET, MUFF T1108-21101 CRANKCASE COMP.
- Page 26 Parts List : EBZ5000Q Fig.3 CARBURETOR COMPONENTS Key# Part Number Description T1108-81450 Body assy ————— Screen ————— Valve ————— Spring ————— Screw ————— ————— Lever 1850-81490 Body 1850-81520 Cover 1751-81510 Pump 5500-81160 Washer 1881-81140 Swivel 1751-81130 Ring 4810-81410 Gasket 1065-81420...
- Page 27 Parts List : EBZ5000Q Fig.4 LEVER SET (S/N 300001 and up) Key# Part Number Description 848-L3D-3310 LEVER SET 2 848-L3D-33C0 • LEVER 3310-53331 • NUT 01642-20508 • WASHER T4012-25211 • ARM T4012-25311 • BRACKET 3495-25410 • BOLT 3495-25420 • SPRING 3495-25440 •...
- Page 28 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and KOMATSU ZENOAH are pleased to explain the emission control system warranty on your 1995 and later small off-road engine. In California, new small off-road engines must be designed, built and equipped to meet the state’s stringent anti-smog standards.
- Page 29 ENONCE DE GARANTIE DE CONTRÔLE DES EMISSIONS DE CALIFORNIE VOS DROITS ET OBLIGATIONS DE GARANTIE La Commission des ressources en air de Californie et KOMATSU ZENOAH sont heureux d'expliquer la garantie du système de contrôle des émissions de votre petit moteur hors route de 1995 et ultérieur.
- Page 30 DECLARACIÓN DE GARANTÍA DE CONTROL DE EMISIONES DE CALIFORNIA SUS DERECHOS Y OBLIGACIONES DE ACUERDO CON ESTA GARANTÍA La Comisión de Recursos del Aire de California y KOMATSU ZENOAH tienen el agrado de explicar la garantía del sistema de control de emisiones para motores “todo terreno” modelo 1995 y posteriores.
-
Page 31: Limited Warranty
ZENOAH AMERICA, INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE.PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOAH AMERICA WITHIN SEVEN (7) DAYS. BE SURE TO KEEP A COPY FOR YOUR RECORDS. - Page 32 Telles sont les limites de la garantie. Le coût du transport de l'unité jusqu'au revendeur RedMax et depuis celui-ci sera à la charge de l'acheteur. L'acheteur ne supportera pas le coût de main d'oeuvre du diagnostic qui amène à la conclusion qu'une pièce garantie est défectueuse, si ce diagnostic est effectué...
- Page 33 KOMATSU ZENOAH AMERICA, INC. LLAMANDO AL (770)-381-5147. IMPORTANTE: RECIBIRÁ UNA TARJETA DE REGISTRO DE GARANTÍA EN EL MOMENTO DE LA COMPRA. LLENE LA TARJETA Y ENVÍELA A RedMax / KOMATSU ZENOAH AMERICA DENTRO DE SIETE (7) DÍAS. ASEGÚRESE DE CONSERVAR UNA COPIA PARA SUS REGISTROS.
- Page 36 KOMATSU ZENOAH AMERICA INC. 4344 Shackleford Road Suite 500 Norcross, Georgia 30093...
