OWNER'S/OPERATOR'S
MANUAL
BACKPACK BLOWER
EBZ8050
EBZ8050RH
WARNING
The engine exhaust from this
product contains chemicals
known to the State of California to
cause cancer, birth defects or
other reproductive harm.
WARNING
Before using our products,
please read this manual carefully
to understand the proper use of
your unit.
APPLICABLE SERIAL NUMBERS :
90100101 and up
MODE D'EMPLOI
SOUFFLANTE DORSALE SOPLADOR DE MOCHILA
AVERTISSEMENT
Les échappements du moteur de
ce produit contiennent des
produits chimiques connus par
l'Etat de Californie comme étant
responsables de cancers,
d'anomalies congénitales et
d'autres atteintes à l'appareil
reproducteur.
AVERTISSEMENT
Avant d'utiliser cette
ce produit
veuillez lire attentivement ce
manuel afin de bien comprendre le
bon fonctionnement de cet
appareil.
NUMEROS DE SERIE APPLICABLES :
90100101 et au-delà
848-L6K-93A0 (901)
MANUAL DE
INSTRUCCIONES
ADVERTENCIA
Los gases de escape del motor de
este producto contienen
sustancias químicas conocidas
por el Estado de California como
causantes de cáncer,
malformaciones en recién nacidos
y otros problemas de
reproducción.
ADVERTENCIA
,
Antes de usar nuestros productos,
lea detenidamente este manual a
fin de familiarizarse con el uso
correcto de este aparato.
NÚMEROS DE SERIE APLICABLES:
90100101 y superior
U
S
F
R
E
S
Advertisement
Chapters
Table of Contents
Related Manuals for RedMax EBZ8050
Summary of Contents for RedMax EBZ8050
- Page 1 OWNER'S/OPERATOR'S MANUAL BACKPACK BLOWER EBZ8050 EBZ8050RH WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products, please read this manual carefully to understand the proper use of your unit.
- Page 3 EBZ8050 EBZ8050RH EBZ8050/RH 848-L6K-93A0 (901) OWNER'S/OPERATOR'S MANUAL BACKPACK BLOWER WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products, please read this manual carefully to understand the proper use of your unit.
-
Page 4: Table Of Contents
Instructions contained in warnings within this manual and warning seals marked with a blower concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 5: Parts Location
1. Parts location [ EBZ8050RH ] 2. Specifications ■ MODEL EBZ8050/EBZ8050RH Dimensions (L x W x H) mm (in) EBZ8050·······································································································390x540x496 (15.4x21.3x19.5) EBZ8050RH ·································································································390x490x496 (15.4x19.3x19.5) Dry Weight kg (lbs) ····································································································································11.5 (25.4) Fuel Tank Capacity liter (fl. oz)····················································································································2.3 (77.7) Engine Type ··········································································································Air cooled 2-cycle gasoline engine Piston Displacement cm Air Filter ·······················································································································2-stage fresh flow filter system... -
Page 6: Warning Labels On The Machine
(2) Wear head, eye and ear protection. (3) Handling this machine improperly could result in accidents causing serious injury or death. Read this manual carefully and practice using the blower until you are fully acquainted with all operations and have learned to use it correctly. -
Page 7: For Safe Operation
If any damage is found in the fuel line, the exhaust line, or the ignition wiring, do not use the blower until it has been repaired. US-5... - Page 8 If cracked, be sure to replace without delay. 4. Check the work area that the blower will be used in and remove or cover all valuables that may be damaged by the air blast or thrown debris.
- Page 9 4. When replacing the any other part, or any lubricant, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax product. 5. In the event that any part must be replaced...
-
Page 10: Set Up
EBZ8050/RH 6. Set up ■ BLOWER TUBES 1. Connect the blower and swivel joint with flexible hose. Clamp both ends of the flexible hose securely with the hardware supplied with the unit. 2. Align the protrusion and the groove provided on the tube ends and twist the tube until connection is locked up. -
Page 11: Fuel
• Poor quality gasolines or oils may damage sealing rings, fuel lines or fuel tank of the engine. NOTE • Failures caused by operating engines on gasoline with octane rating lower than 89 are not covered by the RedMax Two- Stroke engine warranty. WARNING • Alternative Fuels (Not Gasoline) - Page 12 Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel stabilizer is added. RedMax Air-Cooled "Max Life" Synthetic blend Premium two-stroke engine oil "Contains fuel stabilizer" and will automatically extend your gasoline/oil mixture life up to 60 days.
-
Page 13: Operation
8. Operation ■ CONTROL ARM [EBZ8050] (F5) F5 [EBZ8050] • Hold the upper end of the control arm in hand and, while pulling it away from the unit, rotate arm forward (anti- clockwise as the arrow direction) until it clicks. (The first position) And if you want, you can rotate arm more forward until it clicks. - Page 14 (1) Idling Adjustment Screw US-12 ■ STOPPING ENGINE F15 [EBZ8050] [EBZ8050] • Move the throttle lever to the idling position and press the stop switch (red button). The machine has the...
-
Page 15: Maintenance
■ AIR CLEANER • Never operate the blower without an air filter or with a deformed or broken filter element because unfiltered dusty air will quickly ruin the engine. - Page 16 • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, do not use the blower and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire.
- Page 17 IMPORTANT Do not apply liquid type screw lock glue on screws or bolts used to fix plastics components. Adherence of this type of glue may cause cracks on plastics and end up with the breakage. EBZ8050/RH US-15...
-
Page 18: Storage
EBZ8050/RH 10. Storage BEFORE STORING THE BLOWER: 1. Drain a fuel tank and push the primer bulb until it becomes empty of fuel. 2 .Remove the spark plug and drop a spoonful of 2-cycle oil into the cylider. Crank the engine several time and install the spark plug. - Page 19 EBZ8050 EBZ8050RH EBZ8050/RH 848-L6K-93A0 (901) MODE D’EMPLOI SOUFFLANTE DORSALE AVERTISSEMENT Les échappements du moteur de ce produit contiennent des produits chimiques connus par l’Etat de Californie comme étant responsables de cancers, d’anomalies congénitales et d’autres atteintes à l’appareil reproducteur. AVERTISSEMENT Avant d’utiliser cette...
- Page 20 EBZ8050/RH SECURITE Les instructions contenues dans les mises en garde de ce mode d’emploi portant le symbole les points critiques qui doivent être pris en considération pour éviter les blessures graves, c’est pourquoi ces précautions doivent être rigoureusement suivies. Veuillez remarquer qu'il peut arriver que les mises en garde d'avertissement se déchirent ou se salissent et...
-
Page 21: Emplacement Des Pieces
1. Emplacement des pieces [ EBZ8050RH ] 2. Fiche technique ■ Model EBZ8050/EBZ8050RH Dimensions (LxLxH) mm EBZ8050···································································································································390x540x496 EBZ8050RH ·····························································································································390x490x496 Poids à sec kg ····················································································································································11,5 Capacité du réservoir à carburant litres ·················································································································2,3 Type de moteur ···························································································Moteur à essence, 2 temps, refroidi à air Déplacement cc ···················································································································································71,9... -
Page 22: Etiquettes D'avertissement Sur La Machine
EBZ8050/RH 3. Etiquettes d’avertissement sur la machine 4. Symboles utilises sur la machine Des symboles en relief ont été placés sur la machine pour assurer la sécurité à l’usage et faciliter l’entretien. Prendre soin d’observer les indications suivantes afin d’éviter les erreurs. -
Page 23: Consignes De Securite
Ne portez pas de vêtements larges, foulards, colliers et attachez vos EBZ8050/RH cheveux s’ils sont longs, etc. afin d’éviter le risque d’aspiration vers l’entrée d’air et les parties rotatives de l’appareil. - Page 24 EBZ8050/RH 5. Consignes de securite d’entretien ou de retirer une pièce mobile. ■ AVANT DE FAIRE DEMARRER LE MOTEUR 1. Chaque fois que vous utilisez l’appareil avant de faire démarrer le moteur vérifiez que tous les organes sont en bon état de marche et bien fixés.
- Page 25 4. En cas de remplacement d’une pièce quelconque ou du lubrifiant utilisez exclusivement des produits RedMax ou des produits dont RedMax a certifié l’utilisation pour ses machines. 5. En cas de remplacement, entretien ou réparation d’une pièce non décrits dans ce manuel, veuillez prendre contact avec l’atelier de réparation du distributeur...
-
Page 26: Assemblage
EBZ8050/RH 6. Assemblage ■ TUYAUX DE SOUFFLERIE 1. Connecter la soufflerie et le joint à rotule au flexible. Serrer fermement les deux extrémités du flexible avec le matériel fixé à l’appareil. 2. Aligner la partie en saillie et la rainure sur les extrémités du tuyau et tordre le... -
Page 27: Carburant
3 mètres avant de mettre le moteur de la tronçonneuse en marche. ■ TYPES DE CARBURANTS REQUIS • Tous les produits RedMax 2 temps disposent de moteurs 2 temps Zenoah de notre gamme professionnelle et commerciale, à hautes performances, RPM élevées et refroidis par air. - Page 28 • Tout dommage ou problème du moteur, dû à une lubrification inadéquate, suite à la non utilisation d’une huile certifiée ISO- LEGD et JASO FD, comme le "MaxLife", mélange synthétique RedMax Super et huile à 2 temps ENTRAÎNERA L’ANNULATION DE LA GARANTIE DU MOTEUR A DEUX TEMPS RedMax.
- Page 29 Also, be careful that, if the usage in the instruction manual is not observed as to the mixed gasoline, etc. described therein, it may not be covered by the warranty. EBZ8050/RH FR-11...
-
Page 30: Fonctionnement
EBZ8050/RH 8. Fonctionnement ■ BRAS DE COMMANDE [EBZ8050] (F5) F5 [EBZ8050] • Tenir en main l'extrémité supérieure du bras de commande et, tout en l'éloignant de l'appareil, tourner le bras vers l'avant (dans le sens anti-horaire comme indiqué par la flèche) jusqu'à... - Page 31 (1) Vis de reglage du ralenti ■ ARRET DU MOTEUR [EBZ8050] F15 [EBZ8050] • Placez le levier d'accélération en position neutre et appuyez sur le contacteur d'arrêt (bouton rouge). La machine est équipée d'un mécanisme qui empêche l'émission d'étincelles...
-
Page 32: Entretien
EBZ8050/RH 9. Entretien L’entretien, le remplacement ou la réparation du dispositif et des systèmes de lutte contre les émissions peuvent être effectués par toute société ou individu spécialisé dans la réparation des moteurs hors-route. Système/organe Filtre à air Pré Filtre Filtre à... - Page 33 (1) Boulon (2) Boulon (3) Pare-étincelles (4) Diffuseur ■ GRILLE D’ARRET D’ETINCELLES • Les moteurs RedMax sont équipés d’une grille d’arrêt d’étincelles à l’orifice d’échappement. La vérifier régulièrement et la maintenir en bon état. Dans l’état de Californie, la loi (section 4442 du Code des Ressources Public de la Californie) oblige d’équiper...
- Page 34 EBZ8050/RH 9. Entretien ■ INSPECTION DE L’ÉCARTEMENT DE LA BOUGIE D’ALLUMAGE • Réglez l’écartement entre la bobine d’allumage et le noyau de fer du rotor s’il n’est pas conforme aux spécifications ou en cas de pose de la bobine ou du rotor.
-
Page 35: Rangement
➞ ➞ dépôt de calamine ➞ ➞ colmaté de poussière ➞ colmaté de poussière EBZ8050/RH vidanger et remplacer le carburant nettoyer refaire le réglage nettoyer ou sécher régler le jeu (de 0,6 à 0,7 mm) resserrer ACTION vidanger et remplacer le carburant refaire le réglage... - Page 37 EBZ8050 EBZ8050RH EBZ8050/RH 848-L6K-93A0 (901) MANUAL DE INSTRUCCIONES SOPLADOR DE MOCHILA ADVERTENCIA Los gases de escape del motor de este producto contienen sustancias químicas conocidas por el Estado de California como causantes de cáncer, malformaciones en recién nacidos y otros problemas de reproducción.
-
Page 38: La Seguridad Primero
EBZ8050/RH LA SEGURIDAD PRIMERO Las instrucciones que se dan en las advertencias contenidas en este manual y en las etiquetas de advertencia marcadas con el símbolo hacen referencia a puntos críticos que se deben tomar en consideración para evitar posibles lesiones físicas graves y, por esta razón, le solicitamos que lea detenidamente... - Page 39 1. Situación de las piezas [ EBZ8050RH ] 2. Especificaciohes ■ MODELO EBZ8050/EBZ8050RH Dimensiones (largo x ancho x alto) mm (pulg.) EBZ8050·······································································································390x540x496 (15,4x21,3x19,5) EBZ8050RH ·································································································390x490x496 (15,4x19,3x19,5) Peso en seco kg (lbs.) ·······························································································································11,5 (25,4) Capacidad del depósito de combustible litros (fl. oz.) ·················································································2,3 (77,7) Tipo de motor ··········································································Motor de gasolina de 2 tiempos tipo enfriado por aire...
-
Page 40: Etiqueta De Advertencias En La Máquina
EBZ8050/RH 3. Etiqueta de advertencia en la máquina 4. Símbolos presentes en la máquina Para un uso y mantenimiento seguro, se han estampado símbolos en relieve en la máquina. Observe siempre estas indicaciones y tenga cuidado de no cometer un error. -
Page 41: Instrucciones De Seguridad
EBZ8050/RH El equipamiento de protección personal no elimina el riesgo de lesiones pero sí reduce el grado de las mismas. - Page 42 EBZ8050/RH 5. Instrucciones de seguridad giratorias, apague el motor antes de instalar o retirar accesorios. No use la máquina sin la malla instalada. Desconecte siempre la bujía antes de realizar labores de mantenimiento o acceder a piezas móviles. ■ ANTES DE ARRANCAR LA MÁQUINA 1.
- Page 43 4. En el caso de reemplazar cualquier otra parte, o cualquier lubricante, asegúrese siempre de usar sólo los productos RedMax o productos que hayan sido certificados por RedMax para el uso con ES-7...
- Page 44 RedMax más cercano en busca de ayuda. 6. No utilice ningún accesorio que no tenga la marca RedMax y recomendado para esta unidad.
-
Page 45: Montaje
• Si no utiliza la correa para la cintura, asegúrese de retirarla de la unidad y guárdela. • Existe el riesgo de que la correa quede atrapada, haciendo caer la unidad. • Existe el peligro de que la correa sea aspirada dentro del ventilador. EBZ8050/RH ES-9... -
Page 46: Combustible
■ Requerimientos de la Gasolina • Todos los productos RedMax de 2 tiempos cuentan con la potencia de los motores de 2 tiempos de uso comercial producidos por Zenoah Professional, que se enfrían por aire, de altas RPM y alto rendimiento. - Page 47 • Los problemas ocasionados en el motor debido a una lubricación inadecuada por no utilizar el aceite certificado por los estándares ISO-L-EGD y JASO - FD tales como el aceite de 2 tiempos Premium de mezcla sintética "MaxLife", RedMax ANULARÁ LAGARANTÍA DEL MOTOR DE DOS TIEMPOS RedMax.
- Page 48 EBZ8050/RH 7. Combustible vacíe del carburador el combustible compuesto. 6. En el caso de tener que desechar el depósito de aceite mezclado, hágalo solo en un sitio repositorio autorizado. NOTA • Para detalles sobre la garantía de calidad, lea cuidadosamente la descripción que está...
-
Page 49: Uso
8. Uso ■ BRAZO DE CONTROL [EBZ8050] F5 [EBZ8050] (F5) • Sostenga el extremo superior del brazo de control en la mano y, mientras tira de él, gire el brazo hacia adelante (en el sentido contrario a las agujas del reloj, en la dirección de la flecha) hasta... - Page 50 (1) Tornillo de Ajuste de Velocidad de Marcha Mínima ES-14 ■ CÓMO APAGAR EL MOTOR F15 [EBZ8050] [EBZ8050] • Mueva la palanca de admisión de gases a la posición de velocidad de marcha en vacío y pulse el interruptor de parada (botón rojo).
-
Page 51: Mantenimiento
Limpie los componentes con gasolina. (1) Tamiz (2) Elemento (3) Soporte (4) Retenedor EBZ8050/RH Después Después Después de cada de cada de cada 25 horas 50 horas 100 horas ✔... - Page 52 EBZ8050/RH 9. Mantenimiento ■ BUJÍA • En el extremo de encendido de la bujía pueden acumularse depósitos de carbón con el uso normal del aparato. Retire e inspeccione la bujía cada 25 horas de uso y limpie los electrodos según sea necesario con un cepillo de alambre.
- Page 53 IMPORTANTE No aplique adhesivo de fijación de rosca líquido a los tornillos o pernos usados para asegurar los componentes plásticos. La adherencia de este tipo de adhesivos puede causar grietas en los plásticos, y su posterior ruptura. EBZ8050/RH ES-17...
-
Page 54: Almacenamiento
EBZ8050/RH 10. Almacenamiento ANTES DE ALMACENAR EL SOPLADOR: 1. Vacíe el depósito de combustible y presione la pera de cebado hasta que quede sin combustible. 2. Retire la bujía y vierta una cucharada de aceite para motores de 2 tiempos en el cilindro. -
Page 55: Parts List
1. Pour toute réparation et/ou remplacement, utiliser uniquement les pièces de marque RedMax/ZENOAH comme précisé dans la liste des pièces. 2. RedMax/ZENOAH ne garantit pas les machines qui ont été endommagées suite à l’utilisation de pièces autres que celles spécifiées par la société. -
Page 56: Parts List
EBZ8050/RH 13. Parts list Fig.1 BLOWER GROUP EBZ8050/EBZ8050RH (S/N 90100101 and up) P/L-2... - Page 57 13. Parts list Fig.1 BLOWER GROUP EBZ8050/EBZ8050RH Key# Part Number Description 848-L58-55A4 VOLUTE CASE 848-L58-55Z0 VOLUTE COVER 848-L58-55G0 BRACKET 2750-72230 CLAMP (RH Only) T4970-52510 SCREW TORX T4970-51410 SCREW TORX 848-L58-55C2 ELBOW 07000-12100 O-RING T4960-57030 SCREW TORX 3310-53331 848-L58-55D4 COVER INLET...
-
Page 58: Engine Group
EBZ8050/RH 13. Parts list Fig.2 ENGINE GROUP EBZ8050/EBZ8050RH (S/N 90100101 and up) P/L-4... - Page 59 13. Parts list Fig.2 ENGINE GROUP EBZ8050/EBZ8050RH Key# Part Number Description 848-H00-12A3 CYLINDER 848-H00-12B1 GASKET, BASE 4820-12130 BOLT TORX 848-H00-12G0 PLATE, CYL T4960-50810 SCREW TORX 848-H00-14A1 INSULATOR 848-815-2002 BOLT TORX 848-H00-14B2 GASKET, INSU 848-H00-14C1 GASKET, CARB 848-H00-12C0 COVER, TR-S 848-H00-12D0...
-
Page 60: Carburetor Components
EBZ8050/RH 13. Parts list Fig.3 CARBURETOR COMPONENTS EBZ8050/EBZ8050RH Key# Part Number Description T1108-81450 Body assy – Screen – Valve – Spring – Screw – – Lever 1850-81490 Body 1850-81520 Cover 1751-81510 Pump 5500-81160 Washer 1881-81140 Swivel 1751-81130 Ring 4810-81410 Gasket... -
Page 61: Lever Set
13. Parts list Fig.4 LEVER SET EBZ8050 (S/N 90100101 and up) Key# Part Number Description 848-L58-3301 LEVER SET T4012-25100 • LEVER 3310-53331 • NUT 01642-20508 • WASHER T4012-25211 • ARM T4012-25311 • BRACKET 3495-25410 • BOLT 3495-25420 • SPRING 3495-25440 •... - Page 64 ZENOAH AMERICA, INC. 1100 Laval Blvd. Suite 110 Lawrenceville, Georgia 30043 Printed in U.S.A.
