Advent AW820 Installation And Operating Instructions Manual page 15

A. Tuning Indicator Light
B. Tuning Control Wheel
C. Left/Monaural/Right Switch
D. Power ON-OFF/Volume Control Wheel
E. Battery Compartment Cover
F. Speaker Power Input Jack
G. Mounting Bracket Bolt Hole - see (S)
H. Audio Level Indicator Light
I. Charge Output Jack – for use with
Advent AW770 and AW720 Wireless
Headphones only
J. Transmitter Power Input Jack
K. Output Level Control Wheel
L. Audio Input Cable
M. Frequency Control Wheel
N. Antenna
O. Transmitter AC Adapter - 12V DC
P. Speaker AC Adapter (x2) - 15V DC
Q. "Y" Cable Adapter
R. Headphone Adapter Plug
S. Speaker Mounting Bracket –
optional, not included
Front
A
L R
MONO
TUNING
B C D
H
P
O
R
3
Back
OFF
POWER/VOLUME
E F
G
Bottom
N
M
DC 12V
FREQ.
CHARGE LEVEL ADJUST
I J
K L
Q
S
