DT Research DT168 Basic Operation Manual

DT168

SPECIFICATIONS

System
Processor
GPU
Memory (RAM)
Storage
Operating Systems
Display Resolution
Network Interface
Expansion
Input/Output Ports
Power
AC/DC Adapter
Mechanical
Enclosure
Dimensions
(H x W x D)
Weight
Environmental
Regulatory
Temperature
Humidity
* Specifications subject to change without notice.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2012, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
BOG030512DT168ENG
signage dtri com
4
ENGLISH
AMD Geode™ LX 800
Integrated in the CPU
128MB or 512MB
64MB to 1GB Flash; 160GB HDD
Microsoft® Windows® CE, Windows® XP Embedded, or
Windows® XP Pro for Embedded Systems
Up to 1280 x 1024
10/ 100MB BaseT LAN; Wi-Fi 802.11a/b/g (optional)
Mini PCI
1 VGA port; 12V DC-in jack; 2 Audio jacks (Microphone-in
Headphone-Out jacks); 4 USB 2.0 ports; 2 Serial/ COM ports;
1 Parallel port; RJ45 connector for Ethernet;
Wi-Fi dipole antenna (optional)
Input: 100 – 240V AC; Output: 12V DC
Aluminum chassis; ABS plastics end-caps
1.8 x 5.7 x 5.1 in/ 46 x 144 x 130 mm
1.45 lbs/ 660 g
FCC Class B, CE, C-Tick, UL, RoHS compliant
Operation: 0°C - 40°C; Storage: -20°C - 60°C
0% - 90% non-condensing
http://www.dtresearch.com
Embedded Controller/
System
DT168
BASIC OPERATION GUIDE
ENGLISH

INTRODUCTION

Thank you for acquiring the latest addition to DT Research's line of Embedded Controller/ System
devices—the WebDT 168, featuring a compact and robust design powered by the AMD Geode™
processor and providing effective solutions for a broad range of computing needs. The WebDT 168
supports major embedded operating systems as well as Windows XP. The user is offered a choice
of software solutions on a platform characterized by the following:
• High-integration and energy-efficient processor technology
• Robust, fanless construction for reliable operation
• Cost-effective computing in compact and versatile packaging
1
Note: The actual package contents may vary depending on the configuration acquired.
Package Contents
2
1
DT168
2
AC/DC Power Adapter
3
Base/Stand
4 Basic Operation Guide
3
